Sumner Southwire ST-882 Mode d’emploi

OPERATOR’S SAFETY MANUAL

Sumner Pipe Jacks

USA

7514 Alabonson Rd.

Houston, TX 77088

p: 281-999-6900

f: 281-999-6966

Rev. 1, 03/23

Owner’s Reponsibilities

NOTICE: Throughout this publication, the words

WARNING, CAUTION, and IMPORTANT

will be used to alert the user to special

instructions concerning a particular

operation that may be hazardous if

performed incorrectly or carelessly.

OBSERVE THEM CAREFULLY!

These “Safety Alerts” alone cannot eliminate the

hazards that they signal. Strict compliance to these

special instructions while performing the service plus

“common sense” operation are major accident

prevention measures.

WARNING Hazards or unsafe practices which

could result in severe personal injury

or death.

CAUTION Hazards or unsafe practices which

could result in minor personal injury,

product or property damage.

IMPORTANT Indicates information or instructions

that are necessary for proper

operation and/or maintenance.

of this book may be reproduced or utilized in any form or by any means, electronic

or mechanical, including photocopying, recording or by any information storage and

retrieval system, without permission in writing from Sumner Manufacturing Co., LLC,

7514 Alabonson Road, Houston, TX 77088.

SUMNER PIPE JACKS 1

Operator Safety Instructions

To operate jacks safely requires dexterity, mechanical skills

and sound safety habits.

Although Sumner jacks are manufactured for safe,

dependable operation, it is impossible to anticipate those

combinations of circumstances which could result in an

accident. The following instructions are recommended for

safe operation of this unit:

Read and understand the instructions for safe

operation. Before working with a Sumner jack,

understand the correct operation, applications and

limitations. Always contact Sumner when in doubt. Be

manual in a clean area and always at a readily

available location. Additional copies are available for

download from www. .com.

Inspect the equipment. Prior to using Sumner jacks,

check all parts to ensure that they are in proper

operating condition. Inspect legs for bends, breaks or

metal deformation.

SUMNER PIPE JACKS

CAUTION In the event of any jack stand leg

deformation, discontinue use

immediately.

IMPORTANT Make any necessary repairs before

attempting to use the jack.

3. Wear proper clothing. Hard hat or welding helmet,

safety shoes and welding gloves should be worn as a

precaution while operating this equipment.

4. Keep work area clean.

area clear of clutter for unobstructed movement around

the jack.

5. Operate from proper position. Keep balance and

proper footing at all times.

6. Keep alert. Avoid horseplay around equipment and

keep bystanders at a safe distance. Do not allow

children to operate jacks and always keep them out of

work areas.

CAUTION Never allow anyone under jack stand

with load.

7. Do not misuse unit. Perform only the functions for

which the jacks are designed. Never attempt to

operate the equipment at more than the recommended

capacity.

WARNING Modifying the jack stand can result in

injury or death.

Commonly Found Issues

If found, REMOVE FROM SERVICE.

Damaged / Bent Legs Cracked Tube

Wrong Washer in

Jack Stand

Jack without

ID Tube

Wrong ID Tube in Jack Stand

SUMNER PIPE JACKS 3

SUMNER PIPE JACKS

8. Operate only on level surfaces. Use the jack only

on smooth and level surfaces to avoid tipping and

the possibility of operator injury.

9. Hold both jack head and jack leg or carrying

handle when transporting. To prevent foot injury,

always carry jack by both the head and the jack leg

or carrying handle.

10. Use only Sumner parts. Mixing other manufactured

jack stand parts on Sumner jacks can result in

operator injury.

ADJUSTING

SCREW

SPANNER

NUT

LOCK

WASHER

LOCK

WASHER

POST

JACK LEG

STRUT

JACK HEAD

ASSEMBLY

I.D. BARREL

SET SCREW

JACK LEG

Maximum

36"

89 cm

Minimum

21"

51 cm

Maximum

49"

125 cm

Minimum

28"

71 cm

LO JACK STAND HI JACK STAND

Heavy Duty Jacks,

Fold-A-Jacks, Hi Heavy Duty Plus Jack and Hi Pro

Jacks. The adjustable height range for other jacks

varies by type. Consult the latest Sumner Welding

NOTE: Do not mix and match heads.

SUMNER PIPE JACKS 5

SUMNER PIPE JACKS6

1. Read and understand these instructions prior to

operating.

2. Always inspect the equipment for damage and make

any needed repairs before using.

3. Wear hard hat or welding helmet and safety shoes.

5. Stay alert and always avoid horseplay.

6. Use on level and solid surfaces only.

7. Secure set screw after adjustment of I.D. barrel.

8. Always transport with jack head up.

9. Adjust I.D. barrel to desired work height before placing

load on jack.

10. Center load on jack head.

DON’T

1. Never attempt to lift more than the jack’s

recommended capacity.

2. Do not work under a load.

3. Never operate jack on an unstable foundation.

4. Do not force unit if operation is restricted.

5. Never modify jacks.

6. Do not pull or push loads when mounted on jacks.

Operating Instructions

Select the right head style:

SUMNER PIPE JACKS 7

HEAD STYLES FO R SUMNER'S PRO JACK™, HEAVY DUTY JACKS AND F OLD-A-JACKS™

Standard Vee Head Ball

Transfer Set

Part # 780551 (standard)

Part # 780274 (stainless steel)

Attachments slide over

standard vee head.

Accommodates 3/8" - 12"

(10 - 300 mm) pipe sizes.

1,000 lb (450 kg) capacity.

Stainless Steel

Vee Head Attachment

Part # 780502

Fits over vee and secures with

two bolts – no tools required!

780518

780498

Part #Head Style Description Cacpacity Pipe Size Minimum

2,500 lb

(1,135 kg)

Standard Vee Head

Standard Vee Head w/SS Sleeve

Pipe Size Maximum

1/8"

(3 mm)

24"

(600 mm)

780518 &

780551

780518 &

780274

Ball Transfer Head

Ball Transfer Head (Stainless Steel)

1,000 lb

(450 kg)

3/8"

(10 mm)

12"

(300 mm)

780514

780517

785220

Roller Head Assy. w/Aluminum Wheels

Roller Head Assy. w/SS Wheels

Aluminum Roller Head

2,500 lb

(1,135 kg)

1 1/4"

(30 mm)

24"

(600 mm)

Rubber Wheel Head

780499 1,000 lb

(450 kg)

1 1/2"

(40 mm)

24"

(600 mm)

Bar Stock Head 2,000 lb

(900 kg)

1/8"

(3 mm)

24"

(600 mm)

780519 (Hi)

780944 (Lo)

HEAD STYLES FO R SUMNER'S PRO JACK™, HEAVY DUTY JACKS AND F OLD-A-JACKS™

Standard Vee Head Ball

Transfer Set

Part # 780551 (standard)

Part # 780274 (stainless steel)

Attachments slide over

standard vee head.

Accommodates 3/8" - 12"

(10 - 300 mm) pipe sizes.

1,000 lb (450 kg) capacity.

Stainless Steel

Vee Head Attachment

Part # 780502

Fits over vee and secures with

two bolts – no tools required!

780518

780498

Part #Head Style Description Cacpacity Pipe Size Minimum

2,500 lb

(1,135 kg)

Standard Vee Head

Standard Vee Head w/SS Sleeve

Pipe Size Maximum

1/8"

(3 mm)

24"

(600 mm)

780518 &

780551

780518 &

780274

Ball Transfer Head

Ball Transfer Head (Stainless Steel)

1,000 lb

(450 kg)

3/8"

(10 mm)

12"

(300 mm)

780514

780517

785220

Roller Head Assy. w/Aluminum Wheels

Roller Head Assy. w/SS Wheels

Aluminum Roller Head

2,500 lb

(1,135 kg)

1 1/4"

(30 mm)

24"

(600 mm)

Rubber Wheel Head

780499 1,000 lb

(450 kg)

1 1/2"

(40 mm)

24"

(600 mm)

Bar Stock Head 2,000 lb

(900 kg)

1/8"

(3 mm)

24"

(600 mm)

780519 (Hi)

780944 (Lo)

Head capacity equals max capacity of jack.

SUMNER PIPE JACKS8

Proper Operation:

1. Sumner offers two different jack heights (hi and lo),

that allow welders to work at a comfortable height,

depending upon the diamter of the pipe or load.

Based on the size of the material to be welded,

select the correct jack for the job (see page 8 on

jack height).

Correct Jack Height

Operator work level is at

comfortable position.

Incorrect Jack Height

Work too low for operator

can result in back injury.

IMPORTANT Inspect jack prior to each use to

ensure legs are free of bends,

breaks or metal deformation and

that spanner nut rotates freely.
