FELIX STORCH, INC.

770 Garrison Avenue

Bronx, New York 10474

www.summitappliance.com

TWO-DOOR REFRIGERATOR

with BOTTOM FREEZER

Models FFBF240W FFBF245SS

FFBF280W FFBF285SS

User's Manual

IMPORTANT SAFEGUARDS

Thank you for purchasing our SUMMIT

product. This easy-to-use manual will

guide you in getting the best use of your

refrigerator.

Please record the model and serial

numbers, which are found on a label

inside the refrigerator.

Staple your receipt to this manual. You will need it to obtain warranty service.

____________________________

Model number

____________________________

Serial number

____________________________

Date of purchase

IMPORTANT SAFEGUARDS

Read all of the instructions before using this appliance. If instructions are not

followed, you may lose your right to free service during the warranty period.

Please keep this manual in a safe place and pass it on to later users if

applicable.

This unit is not designed to operate in enclosed spaces. When placing your

unit, make sure you allow adequate airflow on all sides.

When using this appliance, always exercise basic safety precautions, including

the following:

1. Do not connect your appliance to the power supply until all packing and

transit protectors have been removed.

2. Let it stand upright for at least 4 hours before switching it on to allow the

refrigerant system to settle if transported horizontally.

3. This appliance should not be used in a cold, unheated room such as a garage

or shed, or on an outdoor patio.

4. Upon delivery, check to make sure that the product is not damaged and that

all the parts and accessories are in perfect condition. Do not operate a

damaged appliance.

5. Use this appliance only for its intended purpose, that is, the storing and

freezing of edible foodstuffs.

6. This refrigerator must be properly installed in accordance with the Installation

instructions before it is used. See “Electrical Requirements” in the Installation

section.

7. Repair or replace immediately all electrical service cords that have become

frayed or otherwise damaged. Do not use a cord that shows cracks or

abrasion damage along its length or at the plug or connector end.

8. Unplug your refrigerator before cleaning or making any repairs.

NOTE: If for any reason this product requires service, we strongly

recommend that a certified technician perform the service.

9. Never unplug your refrigerator by pulling on the power cord. Always grasp the

plug firmly and pull straight out from the outlet.

10.Do not use any electrical device or any sharp instrument in defrosting your

refrigerator.

11.If your old refrigerator is not being used, we recommend that you remove the

doors and leave the shelves in place. This will reduce the possibility of danger

to children.

12.After your refrigerator is in operation, do not touch the cold surfaces in the

freezer compartment, particularly when hands are damp or wet. Skin may

adhere to these extremely cold surfaces.

13.Do not refreeze foods which have been thawed completely. The United

States Department of Agriculture in Home and Garden Bulletin No. 69 reads:

"...You may safely refreeze frozen foods that have thawed if they still contain

ice crystals or if they are still cold –below 40°F.

"...Thawed ground meats, poultry or fish that have any off-odor or off-color

should not be refrozen and should not be eaten. Thawed ice cream should be

discarded. If the odor or color of any food is poor or questionable, discard it.

The food may be dangerous to eat.

"...Even partial thawing and re-freezing reduce the eating quality of foods,

particularly fruits, vegetables and prepared foods. The eating quality of red

meats is affected less than that of many other foods. Use refrozen foods as

soon as possible, to save as much of their eating quality as you can."

14.This refrigerator should not be recessed or built into an enclosed cabinet. It is

designed for freestanding installation only. See Installation instructions.

15.Do not operate your refrigerator in the presence of explosive fumes.

16.Do not allow children to play with the appliance, or to sit or stand on the

appliance or on pull-out parts.

17.Do not hang on the appliance doors.

18.Do not dispose of the appliance in a fire. The appliance contains substances

in the insulation which are flammable.

19.Avoid touching the metal condenser wiring on the back of the appliance.

There is a risk of injury.

20.In the event of a possible malfunction, disconnect the appliance from the

power supply first.

21.Prior to cleaning, always unplug the appliance or switch off the circuit breaker.

DANGER! Risk of child entrapment!

Before you throw away your old refrigerator or freezer, take off

the doors. Leave the shelves in place so that children may not

easily climb inside.

!WARNING!

Keep ventilation openings on the appliance enclosure clear of obstruction.

Do not use mechanical devices or other means to accelerate the defrosting

process, other than those recommended by the manufacturer.

Do not damage the refrigerant circuit.

Do not use electrical devices inside the food storage compartments of the

appliance, unless they are of the type recommended by the manufacturer.

SAVE THESE INSTRUCTIONS 

Table of Contents

Important Safeguards .............................................................................. 1 - 2

Parts and Features .........................................................................................4

Installation ................................................................................................ 5 - 8

Transporting your appliance ..................................................................5

Setting up the appliance ........................................................................5

Location ........................................................................................... 5 - 6

Electrical requirements ..........................................................................6

Reversing the Door Swing ...............................................................6 – 8

Before starting up the appliance ............................................................8

Operation ................................................................................................ 8 - 10

Setting the operating temperature ................................................... 8 - 9

Refrigerator compartment .....................................................................9

Freezer compartment ..........................................................................10

Food Storage Information ...................................................................11 – 12

Fresh food ...........................................................................................11

Frozen food .........................................................................................11

Examples of proper food storage ........................................................12

Cleaning and Care ............................................................................... 12 - 14

Interior and exterior surfaces ...............................................................12

Cleaning the accessories ....................................................................13

Replacing the interior light bulb ................................................... 13 - 14

If there is a power failure .....................................................................14

Normal Operating Noises ............................................................................14

Troubleshooting ...........................................................................................15

Limited Warranty .................................................................................. 16 - 17

Parts and Features

1. Front panel 10. Fast-freeze compartment

2. Interior light 11. Freezer fan

3. Thermostat knob 12. Freezer compartment

4. Movable shelves 13. Ventilation grille

5. Wine rack 14. Adjustable front feet

6. Defrost water drain channel 15. Adjustable door shelves

7. Crisper cover 16. Egg tray

8. Crisper 17. Sliding storage boxes (optional)

9. Ice bank

Note: Not every feature is on all models.

Installation

Transporting your appliance

1. The appliance should only be transported in the upright position.

2. The packaging as supplied must remain intact during transportation.

3. If the unit has been transported or carried in the horizontal position, it may only

be plugged in after standing in the vertical position for 4 hours. Plugging in the

appliance any sooner may result in damage to the refrigerator-freezer and

affect your warranty.

Setting up the appliance

Do not operate your appliance in a room where the temperature is likely to fall

below 50F at night and especially in winter. At lower temperatures the

appliance may not operate, resulting in a reduction in the storage life of the

food.

The climate class rating of your appliance is given on the rating label located

inside the appliance. It specifies the appropriate operating ambient

temperatures as shown below:

Climatic class Ambient temperatures

SN 50.0F to 89.6F

N 60.8F to 89.6F

ST 64.4F to 100.4F

T 64.4F to 109.4F

SN-ST 50.0F to 100.4F

SN-T 50.0F to 109.4F

Location

The unit should be placed in a dry room which can be aired.

Avoid direct sunlight or direct heat sources such as a stove or radiator.

To make sure that sufficient room is provided around the appliance to ensure

free air circulation, allow at least 1” at the back and top, and ¾” at the sides.

Fit the two plastic wall spacers supplied with the appliance, to the condenser

at the back of the appliance, rotating 1/4 turn. See illustration below.

The appliance should be located on a smooth surface. The two leveling legs at

the front corners of the appliance can be adjusted as required.

Leveling legs can be adjusted by turning them counter-clockwise to raise the

refrigerator or clockwise to lower it. Correct adjustment of the feet avoids

excessive vibration and noise.

Electrical requirements

!WARNING! This appliance must be grounded!

Make sure there is a suitable power outlet (115V AC, 60Hz, 15 amps) with

proper grounding to power the refrigerator-freezer.

The electrical safety of the appliance is only assured when the grounding

system in the house is installed in accordance with regulations.

When positioning the appliance, do not let the power cable get stuck under it;

otherwise, the cable will be damaged.

Ensure that the plug remains easily accessible. Do not use a multiple adapter

bar or an extension cord.

Avoid the use of three-to-two prong adapters or cutting off the third grounding

prong in order to accommodate a two-prong outlet. This is a dangerous

practice since it provides no effective grounding for the refrigerator and may

result in shock hazard.

Reversing the door swing

This appliance allows you to reverse the door opening from left to right and back.

You can select your preference of door opening by following this procedure to

make the change.

1. Disconnect the appliance from the power supply.

2. Remove all food, loose items and fittings from the appliance and door

shelves.

3. Unscrew the bolts and remove the middle hinge while holding the doors. (1)

4. Remove the fresh food (refrigerator) compartment door from the top hinge by

sliding down and pulling forward. (2)

5. Remove the freezer compartment door by pulling up. (3)

6. Remove the plastic covers on the front top trim. (4)

7. Unscrew the bolts of the top hinge and remove top hinge. (5)

8. Reposition plugs on the opposite side. (6)

9. Remove the front bottom trim. (7)

10. Carefully lay the appliance on its back. (8) (Get someone to help you.)

11. Unscrew and remove the left-hand side front feet. (9)

12. Unscrew and remove the bottom hinge. (10)

13. Reposition the plastic covers on top of the fresh food door on the opposite

side. (11)

14. Unscrew and remove the middle hinge bushing from the fresh food door. (12)

15.

Screw in and fix the new middle hinge bushing (supplied) to the other side.

(13)

16. Reposition the hinge bushing and the tap on the freezer door. (14)

17. Unscrew and reposition the bottom hinge bushing. (15)

18. Unscrew bolt of the pin of the bottom hinge. Fit the pin to the other hole on

the hinge and tighten the bolt on the new position. (16)

19. Fit the bottom hinge and other feet, and tighten the screws. (17)

20. Remove the plastic tap to the opposite side on the front bottom trim. (18)

21. Fit the front bottom trim to the bottom hinge and other feet. (19)

22. Rotate the top hinge 180. Unscrew the hinge pin and re-tighten it to the

opposite side. (20)

23. Fit the top hinge and tighten the bolts. (21)

24. Fit the plastic cover on the front top trim. (22)

25. Locate the freezer door to the bottom hinge and attach to the cabinet. (23)

26. Locate the middle hinge on the freezer door (24) and put the fresh food door

between the top and middle hinge carefully. (25)

27. Fit the middle hinge. Adjust the doors and tighten the bolts. (26)

28. Carefully stand the appliance up (with someone’s help) and adjust the front

feet.

29. Remove the plastic plugs on the doors. Unscrew the door handles.

Reposition the door handles on the other side. Tighten the screws and fit the

plastic plugs. (27)

30. Put back all loose items and fittings.

31. Wait for at least 4 hours to allow the system to settle before switching on.

Before starting up the appliance

Before you begin operating your refrigerator-freezer, check the following points

for safety:

Is the appliance standing firmly on the floor?

Is there sufficient space for good air circulation?

Is the interior clean? (See Cleaning and Care.)

Set the thermostat knob halfway between 1and 5, or Min and Max.

Now connect the appliance to the power supply.

Operation

Setting the operating temperature

The operating temperature is regulated by the temperature control, or thermostat.

1 = Lowest cooling setting (warmest setting)

5 = Highest cooling setting (coldest setting), or

Min. = Lowest cooling setting (warmest setting)

Max. = Highest cooling setting (coldest setting)

The average temperature inside the refrigerator should be about 41F (5C).

Choose the thermostat setting according to the desired temperature.

You can stop operation of your appliance by adjusting the thermostat knob to the

0position.

Please note that there will be different temperatures in the cooling area. The

coldest region is immediately above the vegetable crisper.

The interior temperature also depends on ambient temperature, the frequency

with which the door is opened and the amount of food kept inside.

Frequently opening the door causes the interior temperature to rise. For this

reason, it is recommended to close the door again as soon as possible after use.

Refrigerator compartment

Food storage:

The refrigerator compartment is for the short-term storage of fresh food and

drinks.

Raw meat is best kept wrapped or in a sealed plastic bag near the bottom of the

refrigerator compartment.

Allow hot foods and beverages to cool to room temperature prior to placing them

in the refrigerator.

Defrosting:

The refrigerator compartment defrosts automatically. The thawing water flows

through the drain channel into a collection container at the rear of the appliance.

If the fresh food section goes through a cycle defrost it is normal to see the

formation of frozen water droplets on the evaporator if the water has not

completely fallen off the evaporator.

Check the flow of the thawed water from time to time. The drain hole may

become plugged occasionally. Clean it with a Q-tip or similar item. See figure

below.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Summit Professional Réfrigérateur

Summit Professional

Summit Professional FF1075W Manuel utilisateur

Summit Professional

Summit Professional FF1078B Manuel utilisateur

Summit Professional

Summit Professional FF1532B Manuel utilisateur

Summit Professional

Summit Professional SPR628BCSS Manuel utilisateur

Summit Professional

Summit Professional FF1074 Manuel utilisateur

Summit Professional

Summit Professional FFBF240W Manuel utilisateur

Summit Professional

Summit Professional FFBF249SSIM Manuel technique

Summit Professional

Summit Professional SPR315OS Manuel utilisateur

Summit Professional

Summit Professional SP5DS2DBLK Manuel utilisateur

Summit Professional

Summit Professional ASDS1523 Manuel utilisateur

Summit Professional

Summit Professional FFBF181SSBI Manuel utilisateur

Summit Professional

Summit Professional FF1532X Manuel utilisateur

Summit Professional

Summit Professional FF1538B Manuel utilisateur

Summit Professional

Summit Professional AL54SSTB Manuel utilisateur

Summit Professional

Summit Professional FFBF181ES Manuel d'utilisation et d'entretien

Summit Professional

Summit Professional AL54 Manuel utilisateur

Summit Professional

Summit Professional ALR15B Manuel utilisateur

Summit Professional

Summit Professional FF874 Manuel utilisateur

Summit Professional

Summit Professional FFBF249SS Manuel d'utilisation et d'entretien

Summit Professional

Summit Professional FFBF181ESLHD Manuel technique

Summit Professional

Summit Professional FFBF181ESBI Manuel technique

Summit Professional

Summit Professional SPFF51OS Manuel utilisateur

Summit Professional

Summit Professional FFBF181ESBIIM Manuel technique

Summit Professional

Summit Professional ALB651 Series Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
