Summit Professional FFBF181ESLHD Manuel technique

DETAILED

INSTRUCTIONS FOR

USE OF UPRIGHT

REFRIGERATOR AND

FREEZER

FFBF181ES

FELIX STORCH, INC.

Summit Appliance Division

770 Garrison Avenue

Bronx, New York 10474

www.summitappliance.com

545433

We thank you for the

confidence you have shown by purchasing

our appliance.

We wish you much pleasure in its use.

The appliance is intended solely for

household use.

Refrigerator freezer (hereinafter: the

appliance) consists of two parts: the upper

part is the refrigerator and the lower part is

the freezer.

The refrigerator is intended for storing fresh

food at temperatures above 0°C (32°F).

The freezer is intended for freezing fresh

food and for long-term storage of frozen

food (up to one year, depending on the

type of food).

TABLE OF CONTENTS

545433

INTRODUCTION

APPLIANCE

DESCRIPTION

DEFROSTING

AND CLEANING

THE APPLIANCE

OTHER

STORING AND

FREEZING FOOD

4 IMPORTANT NOTES AND WARNINGS

8 ADVICE FOR SAVING POWER WITH REFRIGERATION

APPLIANCES

9 APPLIANCE DESCRIPTION

10 INSTALLATION AND CONNECTION

12 CHANGING THE DIRECTION OF DOOR OPENING

14 OPERATING THE APPLIANCE

19 APPLIANCE INTERIOR EQUIPMENT

23 RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE

24 STORING FOOD IN THE REFRIGERATOR

25 STORING FOOD IN THE ZEROZONE DRAWER

27 FREEZING AND STORING FROZEN FOOD

27 Freezing process

28 Important warnings on freezing fresh food

28 Storage of industrially frozen food

29 Frozen food storage time

29 Defrosting frozen food

30 DEFROSTING THE APPLIANCE

31 CLEANING THE APPLIANCE

32 TROUBLESHOOTING

34 INFORMATION ABOUT APPLIANCE NOISE

35 LIMITED WARRANTY

IMPORTANT

NOTES AND WARNINGS

545433

This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or metal capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

Before connecting the appliance to the power line,

please read carefully the instructions for use which

describe the appliance and its correct and safe use. The

instructions apply for several appliance types/models;

thus, settings or equipment may be described herein

which is not available in your appliance. The instruction

manual includes the NO FROST version/model of

the freezer which is fitted with a fan and in which the

defrosting process is automatic.

Remove the packaging intended for protecting the

appliance or particular parts during transport.

Spacers are fitted on the

corners of the doors.

Remove them and insert

the supplied plugs into

their slots (only in some

models).

545433

Before connecting the appliance to the power

mains, let the appliance rest in a vertical position for

approximately 2 hours. This will reduce the possibility

of operation faults due to the effect of transport on the

cooling system.

The appliance must be connected to the power

line and grounded in compliance with the effective

standards and regulations.

The appliance may not be used outdoors and it may

not be exposed to rain.

Do not store explosive substances such as aerosol cans

with a flammable propellant in this appliance.

Before cleaning the appliance, unplug the appliance

from the power line (unplug the power cord from the

wall outlet).

If the power cord is damaged, it must be replaced by a

service technician or other adequately trained person.

If the appliance will be out of use for a prolonged

period of time, switch it off using the relevant button,

and unplug the appliance from the power line. Empty

the appliance, defrost it, clean it, and leave the door

ajar.

If LED lighting does not work, call a service technician.

Do not attempt a repair of the LED lighting yourself, as

there is danger of contact with high voltage!

545433

To protect the environment, take the obsolete

appliance to an authorized home appliance collection

center.

Packaging is made of environmentally friendly materials

that can be recycled, disposed of, or destroyed without

any hazard to the environment.

Rating plate can be found in the appliance interior. If

the language on the rating plate is not the language of

your choice or the language of your country, replace it

with the one supplied.

DANGER: Risk of child entrapment! Before you throw

away your old refrigerator or freezer: take off the

doors and leave the shelves in place so that children

may not easily climb inside.

WARNING! Keep ventilation openings, in the

appliance enclosure or in the built-in structure, clear of

obstruction.

WARNING! Do not use mechanical devices or other

means to accelerate the defrosting process, other than

those recommended by the manufacturer.

WARNING! Do not damage the refrigerant circuit.

WARNING! Do not use electrical appliances inside

the food storage compartments of the appliance,

unless they are of the type recommended by the

manufacturer.

545433

The symbol on the product or its packaging indicates that the product should not

be treated as normal household waste. The product should be taken to an

authorized collection center for waste electric and electronic equipment

processing. Correct disposal of the product will help prevent any negative effects

on the environment and health of people which could occur in case of incorrect product

removal. For detailed information on removal and processing of the product, please

contact the relevant municipal body in charge of waste management, your waste

disposal service, or the store where you bought the product.

– Save these instructions –

ADVICE FOR SAVING POWER

WITH REFRIGERATION

APPLIANCES

545433

• Install the appliance as speciﬁed in the instruction manual.

• Do not open the door more often than necessary.

• Occasionally make sure air circulation underneath the appliance is unobstructed.

• Condenser unit on the rear wall should be kept clean (see chapter Cleaning the

appliance).

• If the gasket is damaged or does not provide a perfect seal for other reasons, have it

replaced as soon as possible.

• Store the food in tightly sealed containers or appropriate packaging.

• Before placing the food in the appliance, cool it to room temperature.

• Defrost frozen food in the refrigerator compartment.

• Remove the drawers from the freezer compartment as described in the instruction

manual, in order to make use of the entire interior.

• Defrost your conventional freezer when an approximately 3-5 milimeter (1/8 to 1/4 inch)

layer of frost or ice has built up on the refrigerated surfaces.

• Make sure the layout of shelves in the compartment is uniform and that the food

is placed so that the air can freely circulate in the appliance interior (observe the

recommended placement of food as described in the instructions).

• In appliances with a fan, do not block the fan slots.

• If you do not need the fan or the ionizer, switch them o to reduce power consumption.

APPLIANCE DESCRIPTION

545433

• Appliance interior equipment may change according to the appliance model.

• The drawers are protected against pulling out. To remove a drawer from the appliance,

open it, then lift the front part and pull it out.

* Only in some models

10 11

A Refrigerator

1 Control unit

2 Led lighting of refrigerator

interior

3IonAir air ionizer (+ on/off

switch)*

4 Pull-out glass shelf (height

adjustable)

5 Bottle rack

6 ZeroZone drawer

7 CrispZone fruit and

vegetables drawer with

humidity control

8 SimpleSlide

heightadjustable door bin

9 Bottle bin

B Freezer

10 Freezer drawers

11 Glass shelves

INSTALLATION AND

CONNECTION

545433

SELECTING THE ROOM

• Do not install the refrigerator where temperatures will be below 55°F or above 110°F,

because it will not maintain proper temperatures, and the refrigerator could develop

high internal humidity.

Warning: Make sure the room where the appliance is installed is large enough. There

should be at least 1 m3of space per 8 grams of refrigerant. Amount of refrigerant is stated

on the rating plate in the appliance interior.

INSTALLING THE APPLIANCE

Appliance installation should be carried

out by at least two persons to avoid

any physical injury or damage to the

appliance.

• The appliance must stand level or tilted

slightly to the back, stable on a solid

base. At the front, the appliance is ﬁtted

with two adjustable legs that can be used

to level the appliance. At the rear side,

casters allow for easier installation of the

appliance (only with some models).

• There should be a clearance of at least 5

cm (2 ) between the appliance and any

cupboard installed above it, in order to

allow adequate cooling of the condenser

unit.

• The appliance is supplied with two

spacers which should be installed on the

lower part of the housing to prevent the

installer from pushing the appliance too

close to the wall. Appliance may also be

installed without the spacers; however,

this may increase power consumption.

• Do not expose the appliance to direct

sunlight and do not place it near any

source of heat. If this cannot be avoided,

install an insulation panel.

max

30 mm

> 90°

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Summit Professional Réfrigérateur

Summit Professional

Summit Professional FF1532X Manuel utilisateur

Summit Professional

Summit Professional SP5DS2DBLK Manuel utilisateur

Summit Professional

Summit Professional AL54 Manuel utilisateur

Summit Professional

Summit Professional FFBF181ES Manuel d'utilisation et d'entretien

Summit Professional

Summit Professional SPR316OS Manuel utilisateur

Summit Professional

Summit Professional FF64B Manuel utilisateur

Summit Professional

Summit Professional FFBF240W Manuel utilisateur

Summit Professional

Summit Professional ALB651 Series Manuel utilisateur

Summit Professional

Summit Professional FF1532B Manuel utilisateur

Summit Professional

Summit Professional FFBF181ESBIIM Manuel technique

Summit Professional

Summit Professional FFBF181ESBI Manuel technique

Summit Professional

Summit Professional FFBF181SS Manuel utilisateur

Summit Professional

Summit Professional FF1078B Manuel utilisateur

Summit Professional

Summit Professional SPR628BCSS Manuel utilisateur

Summit Professional

Summit Professional ASDS1523 Manuel utilisateur

Summit Professional

Summit Professional SPR315OS Manuel utilisateur

Summit Professional

Summit Professional FF1074 Manuel utilisateur

Summit Professional

Summit Professional AL54SSTB Manuel utilisateur

Summit Professional

Summit Professional FF1538B Manuel utilisateur

Summit Professional

Summit Professional FFBF249SSIM Manuel technique

Summit Professional

Summit Professional FFBF181SSBI Manuel utilisateur

Summit Professional

Summit Professional FFRF3070B Manuel utilisateur

Summit Professional

Summit Professional FF874 Manuel utilisateur

Summit Professional

Summit Professional SPFF51OS Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
