Epson Stylus Pro 7700 / 9700
Print Setup Guide - CorelDRAW X5
PAGE 2 of 5 >>
2. Now congure the settings in the Color Management window need to be congured.
The green arrows and numbers correspond to each phase of the setup process.
Select Adobe RGB (1998) from RGB: under Default color settings: (see FIGURE 1).
Select RGB from Primary color mode: under Default color settings: (see FIGURE 1).
Select Perceptual from Rendering Intent under Default color settings: (see FIGURE 1).
Select Microsoft ICM CMM from Color engine: under Color conversion settings (see FIGURE 1).
Check Preserve pure black under Color conversion settings (see FIGURE 1).
Select RGB values from Spot color denition (see FIGURE 1).
Select Assign default color prole from Open, RGB: under Color management policies (see FIGURE 1).
Select Convert to document color prole from Import and paste:, RGB: under
Color management policies (see FIGURE 1).
Click the save icon (see FIGURE 1) and enter an appropriate name e.g. Sublimation (see FIGURE 2).
1
2
3
4
5
6
7
FIGURE 2
8
9
Corel’s color space is now set to use the same space in which the sublimation ICC proles were created.
You can now work with an image as normal.
Note: The ‘CMYK’ and ‘Grayscale’ options should be left as the default options. This will not affect the output as the ICC proles
are created in RGB mode.
