Studio Experience CINEMA 17SF Manuel utilisateur
English
1
Usage Notice
Precautions ........................................................................................... 2
Introduction
Product Features ................................................................................... 3
Package Overview ................................................................................ 4
Product Overview .................................................................................. 5
Main Unit ..........................................................................................5
Panel Control ....................................................................................6
Connection Ports..............................................................................6
Full function wireless remote controller.............................................
Installation
Connecting the Projector ....................................................................... 8
Powering On/Off the Projector ............................................................... 9
Power On the Projector ....................................................................9
Power Off the Projector ....................................................................10
Adjusting the Projected Image ...............................................................11
Adjusting the Projector Height ..........................................................11
Adjusting the Projector Zoom/Focus................................................. 12
Adjusting Projection Image Size ....................................................... 12
User Controls
Panel Control & Remote Control ............................................................ 13
On-Screen Display Menus .................................................................... 16
How to Operate ................................................................................16
Image-I (Computer mode) ................................................................ 1
Image-I (Video mode) ....................................................................... 18
Image-II (Computer mode) ............................................................... 19
Image-II (Video mode) ...................................................................... 20
Audio ................................................................................................ 21
Language ......................................................................................... 21
Management..................................................................................... 22
Appendices
Troubleshooting ..................................................................................... 23
Changing the Lamp ............................................................................... 25
Specifications ........................................................................................ 26
Compatibility Modes .............................................................................. 2
Table of Contents
English
2
Usage Notice
Precautions
Follow all warnings, precautions and maintenance as recommended in this
users guide to maximize the life of your unit.
Warning- Do not look into the lens. The bright light may hurt your eyes.
Warning- To reduce the risk of fire or electric shock, do not expose this
product to rain or moisture.
Warning- Please do not open or disassemble the product as this may cause
electric shock.
Warning- When changing the lamp, please allow unit to cool down, and follow
all changing instructions.
Warning- This product will detect the life of the lamp itself. Please be sure to
change the lamp when it shows warning messages.
Warning- After changing a new lamp, please reset the lamp life from O D
menu.
Warning- Before switching off the product, please keep the cooling fan
running for a few minutes.
Warning- When connecting the projector to computer, please turn on the
projector first.
Warning- When the lamp reaches the end of its life, it will burn out and may
make a loud popping sound. If this happens, the projector will not
turn back on until the lamp module has been replaced. To replace the
lamp, follow the procedures listed under Changing the Lamp.
Do:
vTurn off the product before cleaning.
vUse a soft cloth moistened with mild detergent to clean the display
housing.
vDisconnect the power plug from AC outlet if the product is not being
used for a long period of time.
Dont:
vBlock the slots and openings on the unit provided for ventilation.
vUse abrasive cleaners, waxes or solvents to clean the unit.
vUse under the following conditions:
- Extremely hot, cold or humid environment.
- In areas susceptible to excessive dust and dirt.
- Near any appliance generating a strong magnetic field.
- Place in direct sunlight.
English
3
Product Features
This product is an XGA single chip 0. DLPTM projector. The
outstanding features of it are listed as follows:
uTrue XGA, 1024 x 768 addressable pixels
u6.4 lbs (2.9 kgs) compact design
u1000 AN I Lumens high brightness
uHigh contrast ratio 1000 : 1
uingle chip DLPTM technology
uPureProgressiveTM processing technology for artifact-free film
materials.
uHDTV compatible (480P,1080i,720P)
uNT C/NT C4.43/PAL/PAL-M/PAL-N/ ECAM and
HDTV compatible
uHigh-tech DVI connection for digital and analog video
connectivity
uFull function wireless remote controller
uMultimedia audio integration
uUser friendly multilingual on-screen display menu
uAdvanced electronic keystone correction
uUser friendly control panel
uLuxurious carrying case included
uXGA compression and VGA, VGA re-sizing
u200 Watts user replaceable UHP lamp
uMac compatible
Introduction
English
4
Package Overview
This projector comes with all the items shown below. Check to make sure
your unit is complete. Contact your dealer immediately if anything is
missing.
R 232 Cable
-Video Cable
VGA Cable
Wireless Remote Controller
Carrying Case
Audio Cable Jack/RCA
DVI to D- ub Cable
Battery x 2Users Guide
Introduction
Composite Video Cable
2
34 5
6
Projector with lens cap
D- ub to RCA Cable for
HDTV/Component
7
1
Users Manual Power Cord
(According to Country)
English
5
Main Unit
Product Overview
Introduction
1. Panel Control
2. Power Connector & Power witch
3. Connection Ports
4. Focus Ring
5. Zoom Lens
6. Zoom Ring
7. peaker
8. Remote Control Receiver
9. Elevator Button
10. Elevator Foot
1
2
3
4
5
8
6
7
10
English
6
Introduction
Panel Control
Connection Ports
1 R 232 Input Connector
2. Audio Input for Video
3. Composite Video Input Connector
4. -Video Input Connector
5. Audio Input for DVI
6. DVI Input Connector
7. Audio Input for Computer
8. PC Analog ignal/HDTV/Component Video Connector
9. Audio Output Connector
10. 12V Relay Connector
11. Power witch
12. Power Connector
2
3
4
5
6
7
810
11
12
1. Lamp Warning LED
2. Temperature Warning LED
3. Volume
4. Mute
5. Menu (On/Off)
6. Four Directional elect Keys
7. Enter
8. Zoom
9. Re-sync
10. ource
11. Power / tandby
1
2
3
4
5
8
6
7
10
11
1
English
7
Full Function Wireless Remote Controller
Re-sync
Video ource
Menu
Four Directional elect
Keys
-Video ource
16:9/4:3 Aspect Ratio
Backlight
Introduction
Power
Computer ource
HDTV ource
Freeze
Color Temperature
Brightness
Contrast
Mute
Volume
Keystone Correction
Zoom
Enter
English
8
1. R 232 Cable
2. VGA Cable
3. -Video Cable
4. Audio Cable Jack/RCA
5. Composite Video Cable
6. DVI to D- ub Cable
7. D- ub to RCA Cable for HDTV/
Component
Connecting the Projector
Installation
vTo ensure the projector works well with your computer, please configure the
display mode of your graphic card to make it less than or equal to 1024 X 68
resolution. Make sure timing of the display mode is compatible with the
projector. Refer to the Compatibility Modes section on page 2 .
-Video Output
Video Output 1
2
3
4
7
6
Digital Tuner Output
Digital Tuner Output
Antenna
RS232
AUDIO
VIDEO
S-VIDEO
AUDIO AUDIO AUDIO
DVI
COMPUTER
+12V RELA
INPUT OUTPUT
RGB
R 232
5
English
9
Lens cap
Power / tandby
Installation
Powering On the Projector
1. Remove the lens cap.
2. Ensure that the power cord and signal cable are securely connected.
3. Turn on the main power switch on the side of the projector and allow the
projector to warm up for 1-2 minutes.
4. Turn on the lamp by pressing Power/ tandby button on the control
panel.
The startup screen will display and count down for 20 seconds and the
Power/ tandby indicator will light solid amber.
The LAMP LED indicator will light solid green.
5. Turn on your source (computer, notebook, or video player ,etc...) The
projector will detect your source automatically.
vIf the screen displays No Signal , please make sure the signal cables are
securely connected.
vIf you connect multiple sources at the same time, use the Source button on the
Remote Control or Panel Control to switch.
Power On/Off the Projector
vTurn on the projector first and
then the computer.
Power witch
1
2
3
English
10
Installation
Powering Off the Projector
1. Press the Power/ tandby button to turn off the projector lamp.
2. After pressing the Power/ tandby button, you will see a message
Power off the lamp? on the on-screen display. Press the Power/
tandby button again to confirm. Otherwise the message will disappear
after 5 seconds.
3. Power/ tandby LED indicator will light solid amber for about 30
seconds. After the Power/ tandby indicator starts flashing, you can
turn off the main power switch on the side of the projector.
If you want to turn on the projector, you must press the Power/
tandbybutton within 90 seconds of the start of the indicator flashing.
4. Do not turn on the projector immediately following a power off
procedure.
vWhen the LAMP indicator flashs green for about 10 seconds, you will see a
message Fan Fail on the on-screen display. Please contact your local reseller
or H55 service center.
vWhen the TEMP indicator lights solid orange, it indicates the projector
has been overheated. You will see a message Over Temperature on the on-
screen display. The projector will automatically shut itself down.
Under normal conditions, the projector can be switched on again for your
presentation. If the problem persists, you should contact your local reseller or
H55 service center.
