CONTENTS Introduction
……………………………..………………………1
Applications …………………………….……………………….1
Functions and controls …………….……………….………….1
Accessories…………………………….……….……………….1
Hazards and risks …………………..………………………..1-2
Operation ……………………………….……………………….2
Care and preventive maintenance ..………………………..3-4
Specifications………………………………...………………….5
Transportation…………………………..………………,,,,,,,,,,,6
Trouble shooting……………………………..…………,,,,,,,,,,,6
Explosive Diagram & Part List……………...…………,,,,,,8-13
INTRODUCTION Thank you for your
selection of our equipment.
We have taken care in the design, manufacture and testing of
this product.It is covered by a sixmonthwarranty. Shouldservice
or spare parts be required, prompt and efficient service is
available from our companyor our agent.
General Safety instruction for the Operation of
Power Equipment.
The goal of our company is to produce power equipment that
helps the operatorwork safetyand efficiently. The mostimportant
safety device for this or any tool is the operator. Care and good
judgement are the best protection against injury. All possible
hazards cannot be covered here, but we have tried to highlight
some ofthe importantitems,individualsshouldlook for and obey
caution, Warning and Danger signs placed on equipment, and
displayed in the workplace. Operators should read and follow
safetyinstructions packed with each product.
Learn how each machine works. Even if you have previously
used similarmachines, carefullycheck out each machine before
you use it .Get the ―feel‖ of it and know its capabilities, limitations,
potential hazards, how it operates, and how it stops.
APPLICATIONS
Trench compaction Earth works
Road maintenance Landscaping
Brick paving Driveway toppings
FUNCTIONS AND CONTROLS
The motor is controlled by an ON/OFF switch or push button
which is mounted on the motor below the fuel tank.
Tension of the drive belt is adjustable. Loosen the four nuts on
the bolts which secure the motor to the base plate,Adjust the set
screws which bear against the motor crankcase to achieve the
requiredbelttension.Ensurethatthe four nuts and the set screw
locknuts are tightened after adjustment.
ACCESSORIES
Transportation Trolley; Protective Frame; Rubber Mat etc.
HAZARDS AND RISKS
NEVER allow any person to operate the machine without
adequate instruction.
ENSUREall operators read,understandand followthe operating
instructions;
SERIOUS INJURY couldresultfrom improper or careless use of
this machine;
Plates compactors are heavyunits and should be positioned by
two people of appropriate strength. Using
The lifting handles provided on the machine, along with correct
lifting techniques.
！MECHANICAL HAZARDS
DO NOToperatethe machine unlessall protective guards are in
place.
KEEP handles andfeetclear of rotatingand movingparts as they
will cause injuryif contacted.
ENSURE that the motor operation switch is in the OFFposition
andthe sparkplugignitionleadis disconnected before removing
the guards or making adjustments.
ENSUREboth the machineandtheoperatorare stablebysetting
up on level terrain and the machine will not tip over, slide of fall
while in operation or unattended.
DO NOT leave the machine in operation while it is unattended.
ENSURE that the walls of a trench are stable and will not
collapse due to the action of the vibration, prior to commencing
compaction.
EUSURE that the area to be compacted does not contain any
―live‖electrical cables, gas, water or communication services
which manybe damaged bythe action of vibration.
EXERCISE CARE when operating unit. Exposure to vibration or
repetitive work actions maybe harmful to hands and arms.
NEVER stand on the unit while it is operating.
DO NOT increase the governed no-load motor speed above
3,500 r/min. Any increase may result in personal injury and
damage to the machine.
BE CAREFUL not to come in contact with the muffler when the
engine is hot, since it can cause severe burns.
ENSURE that the repairs to the motor and machine are carried
out by COMPETENT personnel.
！FIRE & EXPLOSION HAZARDS
PETROL is extremely flammable and explosive under certain
conditions;
