storXtreme Network Adapter SX-18D Manuel utilisateur
USER MANUAL
Model : SX-18D
(Version 1.0)
Table of Content
Introduction
1. FUNCTIONAL DESCRIPTION 2
1.1 Buttons 2
1.2 LED Indication 2
1.3 LCD Display
1.4 Connectors 2
2. PRODUCT SPECIFICATIONS
2.1 Technical Specification 3
2.2 Electrical Specification 3
2.3 Product Specification 3
2.4 inimum PC system requirement 3
2.5 Accessories Bundling 4
. USER INTERFACE DESCRIPTION 5
3.1 Buttons Description 5
3.2 LED and LCD Description 5
3.3 Connectors Description 6
3.3.1 ini USB connector 6
3.3.2 SD/ C/ S/S C/XD emory card slot 6
3.3.3 Compact Flash memory card slot 6
3.3.4 44 pins connector 7
3.3.5 Battery Compartment 7
4. DEVICE OPERATION 8
4.1 Copy (standalone) mode 8
4.2 USB mode 9
5. WINDOWS 98SE / ME INSTALLATION 10
5.1 Operating System Supported 10
5.2 Install device driver on Windows 98SE / E 10
5.3 Verify windows98SE has properly installed the device driver 12
5.4 Troubleshoot 12
5.5 Installing new hard disk on Win98SE / E 13
5.6 Configure new hard disk in Win98SE / E 13
5.7 Format new hard disk in Win98SE / E 18
6. WINDOES 200X / XP INSTALLATION 20
6.1 Operating System Supported 20
6.2 Verify windows has properly installed the device driver 20
6.3 Troubleshoot 20
6.4 Create aster Boot Record on the new hard disk. 21
6.5 Create Primary Partition Record on the new hard disk. 23
INTRODU TION
STORXtreme is an integrated solution that provides external hard disk drive, card reader and
memory card backup functions. As a portable external storage device, STORXtreme is a perfect
choice for active mobile users providing a light and optimal solution for personal information
storage and transfer. Any C with a USB port is enough for user to access documents, music,
images, or any other data stored in the internal hard disk drive. In addition, STORXtreme also acts
as an all-in-one card reader supporting all major memory card types. More importantly,
STORXtreme enhances the mobile users by enabling them to copy the content of a memory card
into the internal hard disk drive without a C or notebook. This function allows the users to easily
free up more expensive memory cards for re-use in the field.
STORXtreme supports Compact Flash (CF), MicroDrives, Secure Digital Card (SD), Multimedia
Card (MMC), Memory Stick (MS), Memory Stick RO/DUO. USB connection to C is achieved
using USB 2.0 High Speed (480Mbps) link.
STORXtreme is powered by 2 x AA batteries, either Alakine or NiMH rechargeable battery, which
is easily available.
User Manual
1
Chapter 1 : FUNCTIONAL DESCRIPTION
This section describe the various parts and functions of the device. You may refer to Chapter 3 :
User Interface Description for detail description.
1.1 Buttons
Button Activation Operation
[POWER/SELECT
Press & Hold
Press & Hold
Press
Power On
Power Off
To select the the device operations
[ENTER Press To execute the selected operation
[RESET Press Reset the device
1.2 LED Indication
LED # Definition Indication
1 [HDD Hard disk is accessed
2 [CARD Memory card is accessed
1.3 L D Display
1.4 onnectors
No. Definition Purpose
CON 1Mini USB
connector
Connect to PC USB 1.0 or 2.0
port
CON 2 Memory Card
connector # 1
Memory Card slot for SD /
MMC / MS
CON 3 Memory Card
connector # 2
Memory card slot for Compact
Flash / Micro Drive
CON 4 HDD connector For 1.8” Hard disk drive
User Manual
2
Chapter 2 : PRODUCT SPECIFICATIONS
2.1 Technical Specification
Copy mode
Data Transfer
Rate
CF to HDD : 3MBps
SD to HDD : 2.5MBps (2x) ,
3.4MBps (ultra speed)
MMC to HDD : 1 MBps
MS to HDD : 0.5 MBps
MS Pro to HDD : 3.5 MBps
USB Transfer
Rate
This is a high speed USB device. Hard disk
operates in UDMA mode
Operating OS Windows 98SE, ME, XP, 2K, Mac X (above)
Features
File System: FAT12, FAT16 or FAT32
Long Filename: Max 256 character, Support
Unicode character
Auto sleep: 30seconds (copy)
Card reader cum external hard disk storage
USB
compliance USB 1.0, 2.0
2.2 Electrical Specifications
Operating
Condition
Temperature : 0OC ~ 70OC,
Relative Humidity : 90% (max)
Power Input 2 x AA Batteries (Alakine or NiMH
Rechargeable)
Operating
Current
80mA (Idling)
100uA (shutdown)
800mA (depend on hard disk startup)
500mA (depend on hard disk read/write)
480mA (charge through USB)
820mA (charge through DC)
2.3 Product Dimension
Weight 100gm / 200gm (with HDD)
Size 68 x 88 x 28 mm
2.4 Minimum System Requirement
PC IBM Compatible PC
CPU Pentium III (and above)
RAM 128 MB
USB Port USB1.0 or 2.0
HDD space 20MB available
OS Microsoft Windows 98SE / ME / XP / 2000
Mac OS X
User Manual
3
2.5 Bundled Accessories
USB cable Installation CD Quick Installation Guide
User Manual
4
Chapter 3 : USER INTERFACE DESCRIPTION
3.1 Button Description
Button Activation Operation Mode Description
[POWER/
SELECT
Press
Hold Standalone Press and hold this button for 3 seconds to
power ON/OFF the device.
[POWER/
SELECT Press Standalone Press to select the operations (eg. COPY,
DELETE)
[ENTER Press Standalone Press this button to execute the selected
operation (eg. COPY, DELETE)
[RESET Press Standalone Press this button once to reset the device
3. 2 LED and L D Display
LED Indication Operation Mode Description
1 [HDD USB / Standalone (1) LED blinking indicates Hard disk is
accessing
2 [CARD USB / Standalone
(1) LED blinking consistently indicates
memory card is detected and prompt user for
copy.
(2) LED blink inconsistently indicates the
memory card is being accessed, and copy is
in progress.
On the left is the full display of the LCD, which show various
status mode :
- type of memory cards inserted,
- available HDD space, and data size of the memory cards,
- copy status in percentage,
- battery power level, etc ...
User Manual
5
3.3 onnectors Description
3.3.1 Mini USB connector
lug in the mini USB cable into this connector and the other end of the cable to the C or the
notebook’s USB port. Use the mini USB cable that bundle with this device. The device is
compliance to USB 2.0 as well as USB1.0 specification.
Notebook connector view
3.3.2 SD/MM /MS/SM Memory ard Slot (Slot #1)
This slot supports memory card such as Secure Digital card, Multimedia card, Memory Stick,
Memory stick RO. The device also functions as a memory card reader when connected to the C
via USB connection. It also supports other mini-sized memory cards such as Memory Stick DUO,
Memory Stick RO DUO, RS MMC, MMC mobile and mini Secure Digital card through a memory
card adaptor.
3.3.3 ompact Flash Memory ard Slot (Slot #2)
This slot supports Compact Flash Type I and II, as well as MicroDrive card.
User Manual
6
