D1 PRO 11-2011 Operators manual for D1 PRO Drilling Machine - 5 -
2. GENERAL SAFETY ADVICE
Drilling machine must not be used when:
1. The operator has not read the Operator’s Manual.
2. The work to be done is not in agreement with these recommendations.
3. Drilling machine is not complete or has been repaired with non-original parts.
4. Power supply parameters do not conform to those stated on the motor’s plate.
5. Machines operator has not checked condition of the drilling machine, condition of
power cable, control panel or cutter.
6. Power supply socket is not equipped with a protection circuit.
7. Machine is not secured with safety chain as a protection from dropping from
power loss especially when used at heights or in vertical or upside-down
positions.
8. Bystanders are present in the immediate vicinity of machine.
Warning!
Read and save all instruction for future reference!
Important rules of safe use of drilling machine
1) Before attempting to work with the machine check condition of electrics
including power cord and plug.
2) The drilling machine should be connected to an installation equipped with
protection circuit (neutral or ground) and protected with a 16 A fuse for 220V
and 32 A fuse for 120V.
When used on building sites, it must be supplied
through a separation transformer made in the second class of protection
3) Machine can be used outdoors, but is not weatherproof. Do not expose to rain,
snow or frost.
4) Machine should not be used on: rusty surfaces, steel plates covered with thick
paint, uneven surfaces or next to a welding machine. When the machine is
attached to any metal surface, that surface should not be welded. Remove the
drill from the steel before beginning welding. This can cause damage to the
machine and will void the warranty
.
5) In all cases always use a safety chain/strap (see drawing 1). The safety chain
mustn't be loose! To avoid this situation the safety chain should be wrapped
around the element it is hooked to.
