StarTech.com PEXUSB3S2E2I Manuel utilisateur

Manual Revision: 02/17/2012

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

PEXUSB3S2E2I

4 Port USB 3.0 PCI Express Card - 2 External,

2 Internal Header w/ SATA Power

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Hardware Installation .............................................................................................................................. 2

Driver Installation...................................................................................................................................... 3

Specications..........................................................................................4

Technical Support ..................................................................................5

Warranty Information............................................................................5

Instruction Manual

Introduction

The PEXUSB3S2E2I 4 Port PCI Express USB 3.0 Controller Card adds 2 external USB

3.0 ports and two internal USB 3.0 motherboard headers to a PCI Express enabled

computer system. SuperSpeed USB 3.0 supports transfer rates up to 5 Gbps while still

working with older USB 2.0/1.x devices.

An onboard USB 3.0 motherboard header allows for connecting internal or front panel

mounted USB 3.0 devices (i.e. card readers or hubs) without a special adapter or cable.

With a built-in SATA power connector, each USB port can deliver up to 900mA of power

to USB 3.0 devices (500mA for USB 2.0), by connecting to your computer power supply.

Compatible with both Full Prole or Low prole/half-height computer cases

Packaging Contents

• 1 x PCI Express USB 3.0 Card

• 1 x Low Prole Bracket

• 1 x Driver CD

• 1 x Instruction Manual

System Requirements

• PCI Express enabled computer system with available PCI Express slot

• Microsoft® Windows® XP/ Server 2003/ Vista/ Server 2008 R2/ 7 (32/64-bit)

Instruction Manual

Installation

WARNING! PCI Express cards, like all computer equipment, can be severely damaged by

static electricity. Be sure that you are properly grounded before opening your computer case

or touching your PCI Express card. StarTech.com recommends that you wear an anti-static

strap when installing any computer component. If an anti-static strap is unavailable, discharge

yourself of any static electricity build-up by touching a large grounded metal surface (such as

the computer case) for several seconds. Also be careful to handle the PCI Express card by its

edges and not the gold connectors.

Hardware Installation

NOTE: This card features an optional 15-pin SATA power connector. This is only

required if using the USB ports with bus-powered USB devices (no external power

adapter) or if experiencing connectivity issues. To use this connection, make sure the

computer power supply has an available SATA power connector, otherwise an adapter

cable and/or splitter cable may be required.

1. Turn your computer o and any peripherals connected to the computer (i.e. Printers,

external hard drives, etc.). Unplug the power cable from the rear of the power

supply on the back of the computer and disconnect all peripheral devices.

2. Remove the cover from the computer case. See documentation for your computer

system for details.

3. Locate an open PCI Express slot and remove the metal cover plate on the rear of the

computer case (Refer to documentation for your computer system for details.). Note

that this card will work in PCI Express slots of additional lanes (i.e. x4, x8 or x16 slots).

4. Insert the card into the open PCI Express slot and fasten the bracket to the rear of

the case.

NOTE: If installing the card into a small form factor/low prole system, replacing the

pre-installed full prole bracket with the included low prole installation bracket may

be necessary.

5. If connecting an internal or front panel mounted USB 3.0 device(s) connect the

internal motherboard header cable (included with the device) to the internal

connector on the card. The cable and connector are keyed, so will only t one way.

6. Place the cover back onto the computer case.

7. Insert the power cable into the socket on the power supply and reconnect all other

connectors removed in Step 1.

Instruction Manual

Driver Installation

Windows XP/ Server 2003/ Vista/ Server 2008 R2/ 7

1. Once the computer has started and the operating system is fully loaded, insert the

provided Driver CD into the computer’s CD/ DVD drive.

2. Autorun should give you the option to browse the les on the CD or automatically

open the CD.

If Autorun does not start, Go into“My Computer” and access the CD/DVD drive that

the CD is in.

3. Run the “setup.exe” le on the CD to launch the driver installation program. Follow

the on screen instructions to complete the driver installation.

Instruction Manual

Specications

Host Interface PCI Express 2.0 (x1 slot connector)

Form Factor Full/ Low Prole

Chipset ID VLI VL800

External Connectors 2 x USB 3.0 type A female

Internal Connectors 2 x 10-pin IDC header male

1 x 15-pin SATA Power

Supported Standards USB 3.0

Maximum Data Transfer Rate USB 3.0: 5 Gbps

LBA Support 48-bit

Operating Temperature 0°C ~ 60°C (32°F ~ 140°F)

Storage Temperature 0°C ~ 80°C (32°F ~ 176°F)

Humidity 10% ~ 90% RH

Dimensions 83.0mm x 120.0mm x 20.0mm

Weight 45g

Compatible Operating Systems Windows XP/ Server 2003/ Vista/

Server 2008 R2/ 7 (32/64-bit)

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
