StarTech.com PEX1P Manuel utilisateur

Manual Revision: 02/01/2012

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

For the most up-to-date information, please visit: www.startech.com

PEX1P

PEX1PLP

1 Port PCI Express Parallel Adapter Card

- SPP/EPP/ECP

*actual product may vary from photos

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com.

Where they occur these references are for illustrative purposes only and do not represent an

endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to

which this manual applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges

that all trademarks, registered trademarks, service marks, and other protected names and/or

symbols contained in this manual and related documents are the property of their respective

holders.

Instruction Manual i

Table of Contents

Introduction .......................................................................................................................................................1

Features...........................................................................................................................................................1

Package Contents.....................................................................................................................................1

System Requirements ............................................................................................................................1

Installation............................................................................................................................................................2

Hardware Installation..............................................................................................................................2

Software Installation ...............................................................................................................................2

For Windows® 2000..................................................................................................................................2

For Windows® XP/Server 2003/XP-x64/Server 2003-x64..................................................2

For Windows® Vista/Vista-x64............................................................................................................3

To Verify Windows® Driver Installation.........................................................................................3

Specications.....................................................................................................................................................4

Technical Support...........................................................................................................................................5

Warranty Information....................................................................................................................................5

Instruction Manual 1

Introduction

Thank you for purchasing a StarTech.com PCI Express Parallel Card. This card will allow you to add

DB25 connectivity for optimized performance from your parallel devices, while taking advantage

of the speed and power of PCI Express with plug and play connections to devices such as

printers, scanners and more.

Features

• Maximum data transfer rate of 1.5 Mbps

• PCI 2.2 and PCI Power Management 1.0 compliant

• SPP/EPP/ECP Parallel port fully supports existing Centronics interface

Package Contents

• 1 x PCI Express Parallel Card

• 1 x Driver CD

• 1 x Instruction Manual

System Requirements

• Windows 95/NT4/98/98SE/ME/2000/XP/Server 2003/Vista, DOS, or Linux

• PC with an available PCI Express slot

Instruction Manual 2

Installation

WARNING! PCI Express cards, like all computer equipment, can be severely damaged by static

electricity. Be sure that you are properly grounded before opening your computer case or

touching your card. StarTech.com recommends that you wear an anti-static strap when installing

any computer component. If an anti-static strap is unavailable, discharge yourself of any static

electricity build-up by touching a large grounded metal surface (such as the computer case) for

several seconds. Also be careful to handle the card by its edges and not the gold connectors.

Hardware Installation

1. Remove the computer cover. For more detailed instruction on how to perform this step,

please refer to the documentation that was included with your computer at the time of

purchase.

2. Locate an empty PCI Express slot, removing the metal bracket covering the accompanying

empty port/socket.

3. Position the card above the open PCI Express slot, ensuring that the card is properly aligned

with the slot. Insert the card rmly into the slot, distributing force evenly across the length

of the board. Once inserted, secure the card into the adjoining socket (previously covered by

metal bracket), using the correct size screw.

4. Replace the computer cover and re-connect all power to the computer.

Software Installation

For Windows® 2000

1. Insert the Driver CD into the CD-ROM drive.

2. When the Found New Hardware Wizard appears , click Next.

3. Select Search for a suitable driver for my device (recommended), and click Next.

4. Select CD-ROM drives, but uncheck the other boxes, then click Next.

5. Click Next.

6. Click Finish to complete the driver installation.

For Windows® XP/Server 2003/XP-x64/Server 2003-x64

1. Insert the Driver CD into the CD-ROM drive.

2. At the Found New Hardware Wizard, select Install the software automatically (Recommended),

then click Next.

3. If a Hardware Installation warning pops up indicating that the driver software has not been

digitally signed, click Continue Anyway, then click Finish to complete the driver installation.

Instruction Manual 3

For Windows® Vista/Vista-x64

1. Insert the Driver CD into the CD-ROM drive.

2. At the Found New Hardware Wizard, select Locate and install driver software (recommended).

3. Click Next to continue to setup.

4. The Add New Hardware Wizard will now ask you Would you like to install this device software?.

Click Install to continue.

5. Click Close once driver installation is complete.

To Verify Windows® Driver Installation

To verify that the necessary software has been installed, Click on the Device Manager tab in

System Properties, which you can be accessed through the Control Panel or by following these

steps:

1. Right-click on My Computer and select Manage.

2. In the left pane of the Computer Management window, click on Device Manager.

You should see one PCI Express ECP Parallel Port … installed under Ports (COM & LPT) item.

Instruction Manual 4

Specications

Product Dimensions 21 mm (0.83 in ) x 110 mm (4.33 in )

x 120 mm (4.72 in )

Bus Type PCI-Express one lane

Chipset OXPCIe952

Maximum Data Transfer Rate Up to 1.5 Mbps

OS Support

Windows 95/ 98SE/ ME/ 2000/ XP(32/64bit)/

Vistal(32/64bit)/ 7(32/64bit)/ Server 2008

R2, and Linux

Instruction Manual 5

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit www.startech.com/

support and access our comprehensive selection of online tools, documentation, and downloads.

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for

the periods noted, following the initial date of purchase. During this period, the products may

be returned for repair, or replacement with equivalent products at our discretion. The warranty

covers parts and labor costs only. StarTech.com does not warrant its products from defects or

damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers,

directors, employees or agents) for any damages (whether direct or indirect, special, punitive,

incidental, consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss,

arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If

such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
