StarTech.com PEX8M2E2 Manuel utilisateur

Manual Revision: 11/05/2019

User Manual

For the latest information and specications visit

www.startech.com/PEX8M2E2

x8 PCI Express to Dual M.2 PCIe SSD Adapter

Actual product may vary from photos

SKU#: PEX8M2E2

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du

Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

Safety Measures

• Wiring terminations should not be made with the product and/or electric

lines under power.

• Cables (including power and charging cables) should be placed and routed

to avoid creating electric, tripping or safety hazards.

Mesures de sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit

et/ou les câbles électriques sont sous tension.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent

être placés et acheminés de façon à éviter tout risque électrique, de chute ou

de sécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでくださ

い。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し

を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

にしてください。

Misure di sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le

linee elettriche sotto tensione.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati

e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o

pericoli per la sicurezza.

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller

elledningarna är strömförda.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så

sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................1

Safety Statements..................................................................................2

Product Diagram ....................................................................................4

Product Information ..............................................................................5

Package Contents ..................................................................................................................................... 5

Requirements ............................................................................................................................................. 6

Installing a Drive into the Adapter......................................................6

Installing the Low-Prole Bracket .......................................................7

Installing the Adapter in a Computer .................................................8

Preparing a Drive ...................................................................................9

Windows® OS.............................................................................................................................................. 9

Mac OS .......................................................................................................................................................... 10

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram

Component Function

1Mounting Bracket (full

Prole)

• Used to secure the Adapter

to the Computer.

2Bracket Screws (x 2) • Used to secure the

Mounting Bracket to the

Adapter.

3PCIe Connector • Used to connect the Adapter

to the Computer’s PCIe

Connector.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

4Drive Installation Holes

(x 6)

• Used to secure the Drives to

the Adapter.

5Standos (x 2),

Stando Installation

Screws (x 2), and Drive

Mounting Screws (x 2)

• Used to secure the Drives to

the Adapter.

6M.2 Connectors (x 2) • Used to connect the Drives

to the Adapter.

Product Information

Package Contents

• x8 PCI Express to Dual M.2 PCIe SSD Adapter x 1

• Low-Prole Bracket x 1

• Full- Prole Bracket (installed) x 1

• Installation Hardware Sets x 2

• Standos x 2

• Stando Installation Screws x 2

• Drive Mounting Screws x 2

• User Manual x 1

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Requirements

For the latest requirements, please visit www.startech.com/

PEX8M2E2.

• PCI Express M.2 SSD x 2

• Computer System with x8 or Larger PCI Slot x 1

• Phillips Head Screwdriver x 1

• Pliers x 1

Installing a Drive into the Adapter

Warning! Drives and Adapters should be handled carefully,

especially when they are transported. If you are not careful

with your drives, you may lose data as a result. Make sure

that you’re properly grounded when handling a Drive or

Adapter.

1. Place the Drive next to the Adapter and note the Drive

Installation Holes that match the height of the Drive. If the

Standos and Installation Screws are already installed in

the correct position, proceed to step 6.

2. On the front of the Adapter use Pliers to hold the Stando

in place while using a Phillips Head Screwdriver to remove

the Screw on the back of the Adapter. Then use the Phillips

Head Screwdriver to remove the Screw on the front of the

Adapter.

3. Remove the Stando.

4. Repeat steps 2 - 3 to remove the second Stando and

Stando Installation Screw.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

5. Gently slide the M.2 Connector on the Drive into the

corresponding M.2 Connector on the Adapter and press

the Drive down toward the adapter until the Drive is in

place.

Note: The M.2 Connector on the Drive is keyed so that it

only ts in the Adapter one way.

6. Place the Stando in the Drive Installation Hole that

matches the length of your drive.

7. Replace the Stando Installation Screw that you removed

in step 2 and tighten it in place.

8. Insert the Drive Mount Screw through the Drive Slot and

into the Stando. Use the Phillips Head Screwdriver to

tighten the Drive Mount Screw, securing the Drive in place.

9. Repeat Steps 5 - 7 to install the second Drive into the

Adapter.

Installing the Low-Prole Bracket

The Adapter can be mounted in both low-prole and full-

prole computer systems. By default, the full-prole bracket

comes pre-installed in the Adapter.

1. Use a Phillips Head Screwdriver to remove the two Bracket

Screws from the Adapter.

2. Remove the Full-Prole Bracket from the Adapter.

3. Align the Screw Holes on the Low-Prole Bracket with the

Bracket Holes on the back of the Adapter.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

4. Insert the two Bracket Screws through the Adapter and

into the Low-Prole Bracket.

5. Using a Phillips Head Screwdriver tighten the Bracket

Screws in place being careful not to over-tighten.

Installing the Adapter in a Computer

1. Turn o the Computer.

2. Remove the case from the Computer. For more information

about how to properly do this, consult the documentation

that came with your computer system.

3. Place the Adapter into an available PCIe Slot.

4. Insert a Computer Case Screw (not included) into the Case

Mounting Hole on the Bracket and tighten it into place.

5. Replace the cover on the Computer and turn on the

Computer.

6. When you install the Adapter into the Computer and the

OS automatically installs the necessary software, the Drive

is accessible as though it is installed internally in the system.

Before you use the Drive, you need to prepare it for use and

format it according to the requirements of your OS.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Preparing a Drive

Windows® OS

If the installed Drive has data on it, The Drive will appear under

My Computer or Computer with a drive letter assigned to it. If

you install a brand-new Drive that does not contain any data,

you must prepare the Drive for use.

Warning! When you complete the following steps, all of the

data on the Drive will be deleted.

1. Depending on the version of OS that you are running, do

one of the following:

• On your desktop, right-click My Computer and click

Manage.

• On your desktop, right-click Computer and click Manage.

• Click the Start button or Windows icon. Enter compmgmt.

msc and press Enter.

2. On the Computer Management screen, click Disk

Management.

3. A Dialog screen will appear that asks you to initialize the

Drive. Depending on the version of Windows that you’re

running, you have the option to create either an MBR or a

GPT disk.

Note: GPT (GUID partition) is required for drives that are

larger than 2 TB, but GPT isn’t compatible with some earlier

versions of operating systems. MBR is supported by both

earlier and later versions of operating systems.

4. Locate the disk that is labeled as Unallocated. To conrm

Table des matières

Autres manuels StarTech.com Carte PCI

StarTech.com

StarTech.com PEX2S1P552B Manuel utilisateur

StarTech.com

StarTech.com PEX3U3F800 Manuel utilisateur

StarTech.com

StarTech.com PEX2PECP2 Manuel utilisateur

StarTech.com

StarTech.com PCI4S9503V Manuel utilisateur

StarTech.com

StarTech.com PEXUSB3S2E2I Manuel utilisateur

StarTech.com

StarTech.com PEX4S232485 Manuel utilisateur

StarTech.com

StarTech.com PEXESAT322I Manuel utilisateur

StarTech.com

StarTech.com PEXHDCAP4K Manuel utilisateur

StarTech.com

StarTech.com PCISCSIUW Manuel utilisateur

StarTech.com

StarTech.com PCIUSB3S22 Manuel utilisateur

StarTech.com

StarTech.com PEXUSB311AC2 Manuel utilisateur

StarTech.com

StarTech.com PEXSATA24E Manuel utilisateur

StarTech.com

StarTech.com PEXSAT31E1 Manuel utilisateur

StarTech.com

StarTech.com PCISOUND5CH Manuel utilisateur

StarTech.com

StarTech.com PEX4S950 Manuel utilisateur

StarTech.com

StarTech.com PEX1000SFP2 Manuel utilisateur

StarTech.com

StarTech.com 2P6G-PCIE-SATA-CARD Manuel utilisateur

StarTech.com

StarTech.com PEX867WAC22 Manuel utilisateur

StarTech.com

StarTech.com PCISATA2 Manuel utilisateur

StarTech.com

StarTech.com PCI1P_LP Manuel utilisateur

StarTech.com

StarTech.com PCIBT Manuel utilisateur

StarTech.com

StarTech.com PEXUSB312C3 Manuel utilisateur

StarTech.com

StarTech.com PEX1P Manuel utilisateur

StarTech.com

StarTech.com PEXUSB312C2 Manuel utilisateur

Manuels Carte PCI populaires d'autres marques

ERMA

ERMA SSI 1417 Manuel utilisateur

SIIG

SIIG CyberSerial Dual PCI Instructions de montage

Moxa Technologies

Moxa Technologies CP-102E Manuel utilisateur

I-Bus

I-Bus IBC2602 Manuel utilisateur

Exsys

Exsys EX-60102 Manuel utilisateur

Chelsio Communications

Chelsio Communications T5 Series Manuel utilisateur

Conrad Electronic

Conrad Electronic 97 46 71 Manuel utilisateur

Micro Innovations

Micro Innovations USB650A Manuel utilisateur

KTI Networks

KTI Networks KF-310 Manuel utilisateur

Asus

Asus SpaceLink WL230 Manuel utilisateur

SIIG

SIIG SC2475 Manuel utilisateur

TRENDnet

TRENDnet TEW-703PI Manuel utilisateur

Belkin

Belkin F5D7000F Manuel utilisateur

Pericom

Pericom PI7C7100 Manuel utilisateur

ADLINK Technology

ADLINK Technology cPCI-3548 Manuel utilisateur

Digium

Digium TE200 Series Manuel utilisateur

Allo.com

Allo.com 2nd Gen E1/T1/J1 Manuel utilisateur

Western Digital

Western Digital FireWire PCI Adapter Manuel utilisateur
