StarTech.com ST4000PEXPSE Manuel utilisateur

Manual Revision: 11/03/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

ST4000PEXPSE

4 Port PCI Express Gigabit Ethernet PoE PSE

Network Card

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Product Diagram ....................................................................................2

Front View .................................................................................................................................................... 2

LED Indicators............................................................................................................................................. 2

Installation ..............................................................................................3

Hardware Installation .............................................................................................................................. 3

Software Installation................................................................................................................................ 3

Verifying Installation................................................................................................................................ 4

Specications..........................................................................................5

Technical Support ..................................................................................6

Warranty Information............................................................................6

Instruction Manual

Introduction

Packaging Contents

• 1x PCI Express Network Card

• 1x Driver CD

• 1x Instruction Manual

System Requirements

• PCI Express enabled computer system with available PCI Express slot

• Available SATA power or LP4 Molex connector from the computer power supply

• Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64), Windows Server®

2012, 2008 R2, 2003(32/64), Linux 2.4.x and later

Instruction Manual

Product Diagram

Front View

LED Indicators

LED Color Status

Link/Activity Green Solid On: Link detected Flashing: Data

transmission O: No link detected

PoE Enabled Yellow

Solid On: PoE enabled (Powered Device

detected) O: PoE disabled (Powered

Device not detected)

Instruction Manual

Installation

Hardware Installation

WARNING! PCI Express cards, like all computer equipment, can be severely damaged

by static electricity. Be sure that you are properly grounded before opening your

computer case or touching your PCI Express card. StarTech.com recommends that you

wear an anti-static strap when installing any computer component. If an anti-static

strap is unavailable, discharge yourself of any static electricity build-up by touching a

large grounded metal surface (such as the computer case) for several seconds. Also be

careful to handle the PCI Express card by its edges and not the gold connectors.

Hardware Installation

1. Turn your computer o and any peripherals connected to the computer (i.e. Printers,

external hard drives, etc.). Unplug the power cable from the rear of the power

supply on the back of the computer and disconnect all peripheral devices.

2. Remove the cover from the computer case. See documentation for your computer

system for details.

3. Locate an open PCI Express slot and remove the metal cover plate on the rear of the

computer case (Refer to documentation for your computer system for details.). Note

that this card will work in PCI Express slots of additional lanes (i.e. x4, x8 or x16 slots).

4. Connect either an LP4 Molex or SATA Power connector from the computer power

supply to the appropriate connector on the card.

5. Gently insert the card into the open PCI Express slot and fasten the bracket to the

rear of the case.

6. Place the cover back onto the computer case.

7. Insert the power cable into the socket on the power supply and reconnect all other

connectors removed in Step 1.

Software Installation

Windows 8 / Server 2012

Upon starting Windows with the card installed, Windows should auto-install using

native drivers.

Windows 7 / Server 2008 R2 and earlier

1. Upon starting Windows, if the “Found New Hardware” wizard appears on the screen,

cancel/close the window and insert the included Driver CD into the computer’s CD/

DVD drive.

2. Select the Open folder to view les option from the Autoplay menu. If Autoplay is

disabled on your system, browse to your CD/DVD drive to view the CD contents.

Instruction Manual

3. Navigate to the LAN/Realtek/RTL8111B_8111C_8111E folder and then select the

appropriate folder for your operating system version.

4. Double-click the le Setup.exe application to start the driver installation program.

5. Follow the on-screen instructions to complete the installation.

NOTE: You may be prompted to restart once the install completes.

Verifying Installation

Windows

1. Open the Device Manager by right-clicking on Computer, and then select Manage.

In the new Computer Management window, select Device Manager from the left

window panel (For Windows 8, open the Control Panel and select Device Manager).

2. Expand the “Network adapters” section. On a successful install, you should see the

following devices in the list with no exclamation points or question marks.

Instruction Manual

Specications

Number of Ports 4

Host Interface PCI Express x4

Chipset c

External Connector(s) 4 x RJ-45 Female

Internal Connector(s)

1 x LP4 (4 pin; Molex Large Drive Power)

Male

1 x SATA Power (15 pin) Plug

Maximum Data Transfer Rate 2000 Mbps (Full-duplex)

Supported Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

IEEE 802.1Q VLAN tagging

IEEE 802.3az Draft 2.2 (EEE)

IEEE 802.1P Layer 2 Priority Encoding

IEEE 802.3at Type 1 and 2

Compatible Networks 10/100/1000 Mbps

Ethernet Full Duplex Support Yes

Auto MDIX Yes

Operating Temperature 0°C to 55°C (32°F to 131°F)

Storage Temperature -40°C to 75°C (-40°F to 158°F)

Humidity 10% ~ 90% RH

Dimensions 240 x 18 x 120 mm

Compatible Operating Systems Windows® 8 / 8.1 (32/64bit), 7 (32/64),

Vista(32/64), XP(32/64)

Windows Server® 2012, 2008 R2,

2003(32/64)

Linux 2.4.x and later

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.

Table des matières

Autres manuels StarTech.com Carte réseau

StarTech.com

StarTech.com USB150WN1X1W Manuel utilisateur

StarTech.com

StarTech.com ST1000SPEX43 Manuel utilisateur

StarTech.com

StarTech.com ST100S Manuel utilisateur

StarTech.com

StarTech.com ST10000SPEX Mode d’emploi

StarTech.com

StarTech.com ST4000SPEXI Manuel utilisateur

StarTech.com

StarTech.com 2 Port IEEE-1394 CardBus Card with Digital Video Editing... Manuel utilisateur

StarTech.com

StarTech.com EC1000S Manuel utilisateur

StarTech.com

StarTech.com 8STST4000PEXPSE Manuel utilisateur

StarTech.com

StarTech.com PEX1000MMSC2 Manuel utilisateur

StarTech.com

StarTech.com CB1000BT Manuel utilisateur

StarTech.com

StarTech.com ST5GPEXNB Manuel utilisateur

StarTech.com

StarTech.com PEX10000SRI Manuel utilisateur

StarTech.com

StarTech.com ST1000SPEXD4 Manuel utilisateur

StarTech.com

StarTech.com ST1000PEXPSE Manuel utilisateur

StarTech.com

StarTech.com USB150WN1X1 Manuel utilisateur

StarTech.com

StarTech.com ST20000SPEXI Manuel utilisateur

StarTech.com

StarTech.com UE1200CB Manuel utilisateur

StarTech.com

StarTech.com PEX1000MMSC2 Manuel utilisateur

StarTech.com

StarTech.com EC2000S Manuel utilisateur

StarTech.com

StarTech.com NETRS2321E Manuel utilisateur

StarTech.com

StarTech.com ST1000SMPEX Manuel utilisateur

StarTech.com

StarTech.com PR12GIP-NETWORK-CARD Manuel utilisateur

StarTech.com

StarTech.com PEX10000SRI Manuel utilisateur

StarTech.com

StarTech.com ST20000SPEXI Manuel utilisateur

Manuels Carte réseau populaires d'autres marques

FirstComm

FirstComm OBiWiFi5G Manuel utilisateur

Sun Microsystems

Sun Microsystems Interface Adapter Manuel utilisateur

TRENDnet

TRENDnet TU2-ETG Manuel utilisateur

YASKAWA

YASKAWA SI-EN3 Manuel utilisateur

Paradyne

Paradyne BitStorm 2600 IP DSLAM Manuel utilisateur

Belkin

Belkin F5D7050 Manuel utilisateur

3Com

3Com EtherLink 3C509B Manuel utilisateur

TRENDnet

TRENDnet TEG-PCITX Manuel utilisateur

Cisco

Cisco MC16E Manuel utilisateur

Delta Electronics

Delta Electronics Braking Modules VFDB Series Manuel utilisateur

TwinMOS

TwinMOS Booming Manuel utilisateur

Dialogic

Dialogic Media Board DM/V1200BTEPEQ Manuel utilisateur

Buffalo

Buffalo AirStation WLI-PCM-L11GP Manuel utilisateur

National Instruments

National Instruments NI 9234 Manuel utilisateur

Hama

Hama 49276 Manuel utilisateur

Linksys

Linksys WCF54G - Wireless-G Compact Flash Card Manuel d'utilisation

Compaq

Compaq Wireless LAN 100 Manuel utilisateur

Bose

Bose PowerMatch Dante Manuel utilisateur
