StarTech.com ET91000LC Manuel du système

Gigabit RJ45 to Multi-Mode LC Fiber Media Converter

StarTech ID: ET91000LC

StarTech.com’s high-speed ET91000LC gigabit media converters are engineered to make fiber connections

simple and reliable for even the most demanding network specialists. StarTech.com’s ET91000LC is

the perfect solution for connecting buildings to main networks.<br />

<br />

Easy to set up and install in a matter of seconds. This reliable and compact fiber optic media converter

features a heavy-duty power supply to withstand the most challenging environments. It has 6

LED indicators to ensure its continuous operation.<br />

<br />

While supporting a maximum multimode fiber optic cable distance of 550 meters, it allows full

wire speed of 148,800 packets per second throughput that prevents bottlenecks and keeps your

data flowing quickly and smoothly.<br />

<br />

Guaranteed compatibility with 3COM, Cisco, Lucent and Nortel networks and fully complies with

the IEEE 802.3 and 802.3u standard.

Applications and Solutions

> Connect remote areas of large buildings to the main network

> LAN-to-LAN connectivity between remote offices

> Connecting network servers and power users to Gigabit backbone

> Connects distant network or devices up to 550m in an existing multimode network

Features

> Compliant with IEEE 802.3u standard and guaranteed compatibility with 3Com, Cisco, Lucent,

and Nortel networks

> Easy installation and setup in seconds

> It’s compact design and weight makes it portable and unobtrusive to carry

> LED indicators continuously shows operating status of the converter

> Plug and Play installation allows the converters to be connected to a PC, hub or a switch using an

auto-sensing MDI/MDIX port

> Standard RJ-45 connectors for connecting to UTP media, and SC connector for connecting to

fiber media

> Supports a maximum multimode fiber optic cable distance of 550 meters

> Supports Half-Duplex and Full-Duplex operating modes up to 2 Gigabits/sec

> Supports IEEE 802.3ab 1000BaseT and IEEE 802.3z 1000BaseSX industry standards

Specifications

> Color Beige

> Connector Types 2 - Fiber Optic LC Female

> Connector Types 1 - RJ45 Female

> Product Height 0.79 in [20 mm]

> LED Indicators 1 - Power

> LED Indicators 1 - Fiber

> LED Indicators 1 - UTP

> Product Length 4.84 in [123 mm]

> Power Adapter - DC Voltage DC 12

> Carton Quantity 12

> Shipping (Package) Weight 1.59 lb [0.72 kg]

> Product Weight 24.36 oz [690 g]

> Product Width 3.39 in [86 mm]

> Networks Standards

> IEEE 802.3ab 1000BaseT

> IEEE 802.3z 1000BaseSX

> Fiber Duplex Mode Full-Duplex or Half-Duplex

> Distance

> Multi-mode: 550 meters (1805 feet)

> Wave Length 850nm

> Certifications FCC Class A & CE Mark C-Tick

> Weight 0.59 lbs

> Operating Temperature 0<sup>0</sup>C ~ 55<sup>0</sup>C

> Power Adapter 12V/0.5A
