StarTech.com USB3S2ESATA Manuel utilisateur

SATA Hard Drive Adapter

USB 3.0 to eSATA Adapter

USB3S2ESATA

Instruction Manual

Manual Revision:01/10/2011

For the most up-to-date information, please visit www.startech.com

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes

only and do not represent an endorsement of a product or service by StarTech.

com, or an endorsement of the product(s) to which this manual applies by the

third-party company in question. Regardless of any direct acknowledgement

elsewhere in the body of this document, StarTech.com hereby acknowledges that

all trademarks, registered trademarks, service marks, and other protected names

and/or symbols contained in this manual and related documents are the property

of their respective holders.

Table of Contents

Introduction.............................................................. 1

Packaging Contents............................................................. 1

System Requirements ......................................................... 1

Installation................................................................ 2

Hardware Installation........................................................... 2

Hardware Removal.............................................................. 2

Speciﬁcations........................................................... 3

Technical Support.................................................... 4

Warranty Information............................................... 4

Introduction

The USB3S2ESATA USB 3.0 to eSATA Adapter Cable allows for

connecting an external SATA (eSATA) device or enclosure to a host

computer through USB 3.0 in a single convenient package. Integrated USB

3.0 and eSATA cables and no external power source or driver installation

required, means a simple and hassle-free installation. No assembly

required or having to search for the right cable.

With support for SuperSpeed USB 3.0 connectivity at transfer rates up to 5

Gbps (10 times faster than USB 2.0) and backwards compatible with USB

2.0, this adapter provides a fast and easy-to-use Plug-and-Play experience

for home, ofﬁce or laptop users alike. Compatible with any type of single

drive/volume eSATA device, this versatile adapter is backed by a StarTech.

com 2-year warranty and free lifetime technical support.

Packaging Contents

• 1 x USB 3.0 to eSATA adapter

• 1 x Instruction Manual

System Requirements

• USB enabled computer system with available USB type A port

• Microsoft®Windows®2000/XP/Server 2003/Vista/Server 2008 R2/7

(32/64-bit), or Apple®Mac OS®10.2 ~ 10.6, or Linux®

*actual product may vary from photos

Installation

WARNING! Hard drives and storage enclosures require careful handling,

especially when being transported. If you are not careful with your hard

disk, lost data may result. Always handle your hard drive and storage

device with caution. Be sure that you are properly grounded by wearing an

anti-static strap when handling computer components or discharge yourself

of any static electricity build-up by touching a large grounded metal surface

(such as the computer case) for several seconds.

Hardware Installation

1. Connect the eSATA end of the adapter cable into an eSATA port on the

external storage device, while it is powered off.

NOTE: Port Multiplier support is not available, so only a single disk/volume

from the eSATA device will be detected.

2. Turn on the external storage device.

3. Connect the USB end to an available USB port on the host computer.

The adapter will operate at the native speed of the USB port (i.e. USB

2.0 port: 480 Mbps, USB 3.0 port: 5 Gbps).

NOTE: If the eSATA port on the host computer supports Hot-Plugging /

Plug-and-Play operation, the computer can be running when the cable is

plugged in. Otherwise connect the cable before turning the computer on.

4. The computer system will automatically detect the storage device and

install it. No additional driver installation is required for the adapter

cable.

5. Once successfully installed, the Link LED on the adapter will light up.

The external storage device is now ready for use.

Hardware Removal

Stop the external storage device through the operating system by either

unmounting the storage volume (Mac OS) or stopping the USB device

(Windows).

Once the storage device has been stopped, it can be safely turned off or

the adapter cable disconnected.

Specications

Host Interface USB 3.0 revision 1.0

Chipset ID LucidPort USB300

Connectors 1 x USB 3.0 type A male

1 x 7-pin eSATA female

LEDs 1 x Link/Activity

Compliant Standards SATA revision 2.0

Maximum Data Transfer Rate USB 3.0: 5 Gbps

eSATA: 3 Gbps

Port Multiplier Support No

Operating Temperature 0°C ~ 50°C (32°F ~ 122°F)

Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)

Humidity 5% ~ 85% RH

Cable Length USB: 1m / 3.3ft

eSATA: 30cm / 1ft

Weight 77g

Compatible Operating

Systems

Windows 2000/XP/Server

2003/Vista/Server 2008 R2/7

(32/64-bit),

Mac OS 10.2 ~ 10.6, Linux

NOTE: If used with the Apple Mac OS operating system, this device

will function in USB 2.0 mode only

Technical Support

StarTech.com’s lifetime technical support is an integral part of our

commitment to provide industry-leading solutions. If you ever need

help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial

date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion.

The warranty covers parts and labor costs only. StarTech.com does

not warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.

com USA LLP (or their ofﬁcers, directors, employees or agents) for

any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of proﬁts, loss of business, or any

pecuniary loss, arising out of or related to the use of the product exceed

the actual price paid for the product. Some states do not allow the

exclusion or limitation of incidental or consequential damages. If such

laws apply, the limitations or exclusions contained in this statement

may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy” since 1985,

providing high quality solutions to a diverse IT and A/V customer

base that spans many channels, including government,

education and industrial facilities to name just a few. We offer

an unmatched selection of computer parts, cables, A/V products,

KVM and Server Management solutions, serving a worldwide

market through our locations in the United States, Canada, the

United Kingdom and Taiwan.

Visit www.startech.com today for complete information about

all our products and to access exclusive interactive tools such as

the Cable Finder, Parts Finder and the KVM Reference Guide.
