StarTech.com PEXM2SAT32N1 Manuel utilisateur

Manual Revision: 05/25/2016

For the latest information, technical specications, and support for

this product, please visit www.startech.com/PEXM2SAT32N1.

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

PEXM2SAT32N1

3-Port M.2 NGFF SSD Adapter Card - 1 x PCIe

M.2, 2 x SATA III M.2 - PCIe 3.0

*actual product may vary from photos

Instruction manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction manual

Table of Contents

Introduction............................................................................................1

Packaging contents.................................................................................................................................. 1

System requirements............................................................................................................................... 1

Product diagram ....................................................................................2

Top view ....................................................................................................................................................... 2

Bottom view................................................................................................................................................ 2

Mounting hardware ................................................................................................................................. 2

LED indicators.........................................................................................3

LED diagram................................................................................................................................................ 3

Hardware installation............................................................................4

Install a drive on the PCIe card............................................................................................................. 4

SATA M.2 drive-installation diagram (top side).............................................................................. 4

PCIe M.2 drive-installation diagram (bottom side)....................................................................... 5

Install the low-prole bracket............................................................................................................... 5

Install the PCIe card.................................................................................................................................. 5

Initialize a drive ......................................................................................6

Prepare a drive for use on a computer running Windows.......................................................... 6

Prepare a drive for use on a computer running Mac OS............................................................. 7

Technical support...................................................................................8

Warranty information............................................................................8

Instruction manual

Introduction

This M.2 adapter card lets you mount both PCIe and SATA-based M.2 (NVMe) SSDs

inside your computer, through a PCI Express slot. It’s a versatile solution for upgrading

the performance and storage capacity of your desktop computer or server. The M.2

adapter card supports a single PCIe M.2 SSD, plus two SATA-based M.2 SSDs.

The adapter card oers wide installation compatibility, with support for virtually all M.2

drives (2230, 2242, 2260, 2280).

Packaging contents

• 1x 3-port M.2 NGFF SSD adapter card

• 1x low-prole bracket

• 3x M.2 mounting screws

• 3x M.2 mounting standos

• 3x M.2 mounting nuts

• 1x screwdriver

• 1x quick-start guide

System requirements

• A computer enabled with PCI Express (PCIe), and an available PCI Express x4, x8, or

x16 slot

• One or two SATA host ports on the host computer (for example, the SATA controller

card, or the motherboard SATA ports inside of your computer)

• An operating system that natively supports PCIe SSDs (NVMe), such as:

o Windows® 7 and later

o Mac OS 10.10.3 and later

Note: When installed in a compatible operating system, the card is natively supported

and doesn’t require any additional drivers or software. However, your operating system

must natively support PCIe SSDs (NVMe – Non-Volatile Memory Express).

System requirements are subject to change. For the latest requirements, please visit

www.startech.com/PEXM2SAT32N1.

Instruction manual

m.2 PCIe

SSD slot

Drive-installation holes

Product diagram

Top view

Bottom view

Mounting hardware

Screw Nut Stando

Bracket (full-prole pictured)

2x SATA data ports

Bracket screws

Drive-installation holes

PCI Express x4 connector

2x m.2 SATA SSD slots

*connects to your host SATA ports

Instruction manual

LED indicators

The PEXM2SAT32N1 features four LEDs, which indicate the status and activity of the

card and its connected drives:

LED diagram

SATA m.2

SSD1 LED

SATA m.2

SSD2 LED

Power LED

PCIe m.2

SSD LED

LED Behavior Status

SATA M.2 SSD 1 LED

Solid green A drive is installed into the SATA 1 M.2 slot —

drive is idle

Solid red There is activity on the installed drive (read

and write)

SATA M.2 SSD 2 LED

Solid green A drive is installed into the SATA 2 M.2 slot —

drive is idle

Solid red There is activity on the installed drive (read

and write)

PCIe M.2 SSD LED

Solid green A drive is installed into the PCIe M.2 slot —

drive is idle

Blinking red There is activity on the installed drive (read

and write)

Power LED Solid blue The card is powered and operational

Instruction Manual

Hardware installation

Install a drive on the PCIe card

Warning! Drives and PCIe cards should be handled carefully, especially when they’re

transported. If you’re not careful with your drives, you may lose data as a result. Make

sure that you’re properly grounded by wearing an anti-static strap when you install

any computer component. If an anti-static strap isn’t available, touch a large, grounded

metal surface for several seconds to discharge any built-up static electricity.

1. The card features drive-installation mounting holes at dierent intervals (30 mm,

42 mm, 60 mm, and 80 mm) to support all M.2 drive sizes. To determine which

mounting hole to use, place your M.2 drive next to the card and note the drive-

installation holes that match the height of your drive.

2. Fasten a stando and a nut to the adapter card at the mounting-hole location(s)

that match(es) the length of your drive.

3. Gently slide the M.2 connector on your drive into the corresponding connector on

the adapter card.

Note: The connector on your drive is keyed so that it only ts one way.

4. Repeat steps 2 and 3 for each of your M.2 drives.

Note: Two SATA drives can be installed to the top side of the adapter card, while one

PCIe drive can be installed on the bottom side of the adapter card.

5. Place one of the included M.2 mounting screws in the drive-mount stando and use

a screwdriver to tighten the screw and hold your M.2 drive in place.

6. If necessary, repeat step 5 for a second and third drive.

7. To remove a drive, use a screwdriver to remove the M.2 mounting screw that is

holding the drive in place and gently pull the drive out of the adapter card.

SATA M.2 drive-installation diagram (top side)

Instruction Manual

PCIe M.2 drive-installation diagram (bottom side)

Install the low-prole bracket

The adapter card can be installed in a low-prole or a full-prole computer. The full-

prole bracket comes preinstalled on the card, but if you have a small form-factor

computer, you can install the low-prole bracket instead.

1. Use a Phillips head screwdriver to remove the two bracket screws from the card.

2. Remove the full-prole bracket from the adapter.

3. Line up the low-prole bracket with the bracket holes on the back of the card.

4. Insert the two bracket screws you removed in step 1 and tighten them in place.

Install the PCIe card

Warning! PCIe cards can be severely damaged by static electricity. If an anti-static strap

isn’t available, discharge any built-up static electricity by touching a large grounded

metal surface for several seconds.

The card is natively supported when installed in a compatible operating system (see

Requirements). Once the card is installed in your host computer the required drivers

will automatically install.

1. Turn o your computer and any devices or peripherals that are connected to it (for

example, printers, external storage, and so on).

2. Unplug the power cable from the back of your computer.

3. Disconnect any peripheral devices that are connected to your computer.

4. Remove the cover from your computer case. Consult the documentation that came

with your computer for details about how to do this safely.

Instruction Manual

5. Locate an open PCIe slot and remove the corresponding metal cover plate from

the back of your computer case. Consult the documentation that came with your

computer for details about how to do this safely. This card works in PCIe slots of 4, 8,

or 16 lanes (x4, x8, or x16 slot).

Note: If you install the card into a low-prole (small form-factor) desktop system, it

may be necessary to replace the preinstalled full-prole bracket with the included

low-prole (half-height) installation bracket. See Install the low-prole bracket for

instructions on how to do this.

6. Gently insert the card into the open PCIe slot and fasten the bracket to the back of

the case.

7. As necessary, connect SATA cables from the SATA ports on the card, to the SATA

ports inside your computer (for example, connect the card’s SATA ports to your

computer’s SATA controller or to the SATA ports on your computer’s motherboard.)

8. Place the cover back onto your computer case.

9. Reconnect the power cable to the back of your computer.

10. Reconnect all of the peripheral devices that you disconnected in step 3.

11. Turn on your computer.

Initialize a drive

Prepare a drive for use on a computer running Windows

If you install a drive that already has data on it, the drive appears under My Computer

or Computer with a drive letter assigned to it. If you install a brand-new drive that

doesn’t contain any data, you must prepare the drive for use.

Warning! When you complete the following steps, all of the data on your drive will be

deleted. If your drive has data on it that you require, you should create a backup le or

use a dierent drive.

1. Navigate to Disk Management.

2. A dialog window appears and asks you to initialize the drive. Depending on the

version of Windows that you’re running, you have the option to create either an

MBR or a GPT disk.

Note: GPT (GUID partition) is required for drives larger than 2 TB, but GPT isn’t

compatible with some earlier versions of operating systems. MBR is supported by both

earlier and later versions of operating systems.

3. Locate the disk that is labeled Unallocated. To conrm that the drive is the correct

one, check the drive capacity.

4. Right-click the section of the window that says Unallocated and click New

Partition or New Simple Volume.

5. To initialize the drive in the format of your choice, complete the on-screen

Instruction Manual

instructions.

When the drive is successfully installed, it appears under My Computer or Computer

with a drive letter assigned to it.

Prepare a drive for use on a computer running Mac OS

Warning! When you complete the following steps, all of the data on your drive will be

deleted. If your drive has data on it that you require, you should create a backup le or

use a dierent drive.

1. Do one of the following:

• In Spotlight, enter Disk Utility.

• Open Finder. Navigate to Applications and click Utilities. Open Disk Utility.

2. Select the new drive and click the Partition tab.

3. Enter a name for the partition.

4. Click Apply.

The drive should now appear on your desktop and be accessible in Finder.

Table des matières

Autres manuels StarTech.com Adaptateur

StarTech.com

StarTech.com US1GA30SXSC Manuel utilisateur

StarTech.com

StarTech.com CBESATA2 Manuel utilisateur

StarTech.com

StarTech.com PEX867WAC22 Manuel utilisateur

StarTech.com

StarTech.com DVI2DPA Manuel utilisateur

StarTech.com

StarTech.com V933536 Manuel utilisateur

StarTech.com

StarTech.com S322SAT3R Manuel utilisateur

StarTech.com

StarTech.com USB32HD2 Manuel utilisateur

StarTech.com

StarTech.com PEX433WAC11 Manuel utilisateur

StarTech.com

StarTech.com CDP2HD4K60SA Manuel utilisateur

StarTech.com

StarTech.com USBA-BLUETOOTH-V5-C2 Manuel utilisateur

StarTech.com

StarTech.com MPEX2S952 Manuel utilisateur

StarTech.com

StarTech.com 8ST102BUSBCMULTIP Manuel utilisateur

StarTech.com

StarTech.com 8STDKT30CHPD Manuel utilisateur

StarTech.com

StarTech.com USB32HDDVII Manuel utilisateur

StarTech.com

StarTech.com DKT30CHVSDPD Manuel utilisateur

StarTech.com

StarTech.com ICUSB2321FIS Manuel utilisateur

StarTech.com

StarTech.com USB21000S Manuel utilisateur

StarTech.com

StarTech.com ICUSB2321284 Manuel utilisateur

StarTech.com

StarTech.com USB2DVIMM6 Manuel utilisateur

StarTech.com

StarTech.com USB31GEHD Manuel utilisateur

StarTech.com

StarTech.com USB433ACD1X1 Manuel utilisateur

StarTech.com

StarTech.com ICUBS232SM3 Manuel utilisateur

StarTech.com

StarTech.com IDE35252X Manuel utilisateur

StarTech.com

StarTech.com USB2VGAMM6 Manuel utilisateur

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
