StarTech.com DKT30CSDHPD3 Manuel utilisateur

Manual Revision: 05/31/2018

User Manual

For the latest information and specications visit

www.startech.com/DKT30CSDHPD3

USB-C™ Multiport Adapter with SD Card Reader

PD 3.0 | 4K HDMI® | GbE | 2 x USB 3.0 & 1 x USB-C

SKU#: DKT30CSDHPD3

Actual product may vary from photos

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Use of Trademarks, Registered Trademarks, and other Protected Names

and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

Safety Measures

• Wiring terminations should not be made with the product and/or electric

lines under power.

• Product installation and/or mounting should be completed by a certied

professional as per the local safety and building code guidelines.

• Cables (including power and charging cables) should be placed and routed

to avoid creating electric, tripping or safety hazards.

Mesures de sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit

et/ou les câbles électriques sont sous tension.

• L’installation et/ou le montage du produit doit être réalisé par un

professionnel certié et dans le respect des normes locales et du code de

construction local.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent

être placés et acheminés de façon à éviter tout risque électrique, de chute ou

de sécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでください。

• 製品の設置やマウントは、使用地域の安全ガイドラインおよび建築基準に従い、有資格の専門業者が行うようにしてください。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回しを行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

にしてください。

Misure di sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le

linee elettriche sotto tensione.

• L’installazione e/o il montaggio dei prodotti devono essere eseguiti da un

tecnico professionale certicato che conosca le linee guida locali sulle norme

edilizie e sulla sicurezza.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati

e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o

pericoli per la sicurezza.

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller

elledningarna är strömförda.

• Installation och/eller montering får endast göras av behöriga yrkespersoner

och enligt gällande lokala förordningar för säkerhet och byggnormer.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så

sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Warning Statements

Make sure to assemble this product according to the instructions. Failure to do

so might result in personal injury or property damage.

Never use this product if parts are missing or damaged.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................1

Safety Statements..................................................................................2

Warning Statements..............................................................................3

Product Diagram....................................................................................4

Top View ....................................................................................................................................................... 4

Side View...................................................................................................................................................... 4

Product Information..............................................................................5

Package Contents ..................................................................................................................................... 5

Requirements ............................................................................................................................................. 5

Powering the Multiport Adapter .........................................................6

USB Power Delivery 3.0 ........................................................................................................................... 6

USB Power Delivery 2.0 ........................................................................................................................... 6

Connecting the USB-C Power Adapter.............................................................................................. 6

Disconnecting the USB-C Power Adapter........................................................................................ 7

Connecting the Multiport Adapter .....................................................7

USB-A Ports ................................................................................................................................................. 7

HDMI Port................................................................................................8

RJ45 Port....................................................................................................................................................... 8

USB-A Port ................................................................................................................................................... 8

Inserting an SD Card ................................................................................................................................ 8

Removing an SD Card.............................................................................................................................. 9

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

LED Indicators.........................................................................................10

RJ45 Port....................................................................................................................................................... 10

Additional Information .........................................................................10

Installing the Driver.................................................................................................................................. 10

Conguring a Display.............................................................................................................................. 11

Display Preference .................................................................................................................................... 11

Troubleshooting.....................................................................................12

Reactivating an SD Card Autoplay/Autorun Function................................................................. 12

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram

Actual product may vary from photos

Top View

Side View

USB-C Port

(Power/Data) SD Card

Slot USB-A

Ports HDMI

Port

RJ45 Port

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Information

Package Contents

• Multiport Adapter x 1

• User Manual x 1

Requirements

For the latest requirements, please visit www.startech.com/DKT30CSDHPD3.

Host Computer:

• An available USB-C port (to ensure full adapter functionality, the Host

Computer USB-C port must support USB Power Delivery 3.0 and DP Alt

Mode). USB Power Delivery 2.0 is also supported on this adapter, see

limitations in Powering the Multiport Adapter section.

• (Optional) Video Card with DisplayPort 1.2 (required when using a 4K display)

Display:

Display requirements are optional and will depend on the port conguration of

the connected Host Computer.

• 4K capable display

• HDMI capable display

Cables:

Cable requirements are optional and will depend on the port conguration of

the connected Host Computer.

• USB-A Cable

• USB-C Cable

• HDMI Cable

• CAT5e/CAT6 Cable

Operating Systems:

• Windows 10 ®, 8, and 7

• macOS 10.13, 10.12, and 10.11

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Powering the Multiport Adapter

USB Power Delivery 3.0

Fast Role Swap:

A Fast Role Swap function is available when using Power Delivery 3.0. This

function prevents USB data disruption when switching power sources (bus

power to USB-C power adapter or USB-C power adapter to bus power). For this

function to work, the Host Computer must also support Power Delivery 3.0.

Bus Power:

The Multiport Adapter is powered by the Host Computer’s USB-C port and does

not require a separate power adapter.

1. Connect the USB-C Host Connector on the Multiport Adapter to a USB-C

port on the Host Computer.

2. Depending on the Host Computer’s operating system, the Multiport

Adapter will automatically detect and install the required driver.

USB Power Delivery 2.0

If the Host Computer’s USB-C Port only supports USB Power Delivery 2.0, it will

still support Power Delivery pass-through, but it will not support Fast Role Swap.

If your Host Computer’s USB-C port does not support Power Delivery, then it will

not support Power Delivery pass-through.

Connecting the USB-C Power Adapter

The Multiport Adapter is powered using the Host Computer’s USB-C power

adapter.

The Multiport Adapter requires 12 W of Power Delivery to power the adapter

and its connected devices.

1. Connect the Multiport Adapter’s USB-C Connector to a USB-C port on the

Host Computer.

2. Connect the USB-C connector on the Host Computer’s power adapter to the

USB-C port on the Multiport Adapter.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

3. The power adapter will power the Multiport Adapter and pass power

through to the Host Computer.

4. Depending on the Host Computer’s operating system, the Multiport

Adapter will automatically detect and install the required driver.

Disconnecting the USB-C Power Adapter

Warning (if the Host only supports Power Delivery 2.0): Before disconnect-

ing a USB-C power adapter from the Multiport Adapter, ensure all data

transfers are complete. If you disconnect the power adapter while transfer-

ring les to or from an attached storage device, the transfer will stop. This

may corrupt any les that you were attempting to transfer.

1. Complete all data transfers.

2. Disconnect the Multiport Adapter’s USB-C Connector from the Host

Computer.

3. Disconnect the USB-C Power Adapter from the Multiport Adapter.

4. Disconnect the HDMI device from the HDMI Port.

5. Eject the SD or Micro SD card(s).

6. Disconnect any USB peripherals.

Connecting the Multiport Adapter

USB-A Ports

The USB-A Ports can be used as charging ports (e.g. cell phone, laptop,

tablet, etc.), or to connect a USB storage device (e.g. Flash Drive) or other USB

peripheral device (e.g. Keyboard, Mouse, etc.).

1. Connect a USB-A Cable to a USB-A Port on the Multiport Adapter.

2. Connect the other end of the USB-A cable to a USB-A Port on your USB

device.

Note: The USB-A Port on the Multiport Adapter can fast-charge devices that

comply with USB Battery Charging Specication Revision 1.2.

Table des matières

Autres manuels StarTech.com Adaptateur

StarTech.com

StarTech.com 167B-USBC-MULTIPORT Manuel utilisateur

StarTech.com

StarTech.com USB External Sound Card Adapter Manuel utilisateur

StarTech.com

StarTech.com MHD2VGA Manuel utilisateur

StarTech.com

StarTech.com USB32DP4K Manuel utilisateur

StarTech.com

StarTech.com PEX1PCI1 Manuel utilisateur

StarTech.com

StarTech.com SAT2M2NGFF25 Manuel utilisateur

StarTech.com

StarTech.com CF2USAT18E Manuel utilisateur

StarTech.com

StarTech.com USB31000SPTB Manuel utilisateur

StarTech.com

StarTech.com MDVIDVIMF Manuel utilisateur

StarTech.com

StarTech.com ST3300GU3B Manuel utilisateur

StarTech.com

StarTech.com ICUSB232INT1 Manuel utilisateur

StarTech.com

StarTech.com DKT30CHPD Manuel utilisateur

StarTech.com

StarTech.com USB433ACD1X1 Manuel utilisateur

StarTech.com

StarTech.com USB21000S Manuel utilisateur

StarTech.com

StarTech.com MDVIHDMIMF Manuel utilisateur

StarTech.com

StarTech.com MSTCDP123HD Manuel utilisateur

StarTech.com

StarTech.com USB3S2ESATA Manuel utilisateur

StarTech.com

StarTech.com MSDREADU2OTG Manuel utilisateur

StarTech.com

StarTech.com USB32DPPRO Manuel du système

StarTech.com

StarTech.com USB2SATA25 Manuel utilisateur

StarTech.com

StarTech.com SFF-TA-1001 Manuel utilisateur

StarTech.com

StarTech.com DP2DVID2 Manuel utilisateur

StarTech.com

StarTech.com USB300WN2X2D Manuel du système

StarTech.com

StarTech.com MDP2DPDVHD Manuel utilisateur

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
