StarTech.com EOC110K Manuel utilisateur

Ethernet over Coax

Ethernet over Coax Adapter Kit

EOC110K

EOC110R

Instruction Manual

Manual Revision:07/26/2010

For the most up-to-date information, please visit www.startech.com

Ethernet over Coax Receiver

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes

only and do not represent an endorsement of a product or service by StarTech.

com, or an endorsement of the product(s) to which this manual applies by the

third-party company in question. Regardless of any direct acknowledgement

elsewhere in the body of this document, StarTech.com hereby acknowledges that

all trademarks, registered trademarks, service marks, and other protected names

and/or symbols contained in this manual and related documents are the property

of their respective holders.

Table of Contents

Introduction............................................................... 1

Packaging Contents.............................................................. 1

System Requirements .......................................................... 1

Installation................................................................. 2

Hardware Installation............................................................ 2

Driver Installation.................................................................. 2

Cable Length ............................................................. 3

Speciﬁcations............................................................ 4

Technical Support..................................................... 5

Warranty Information................................................ 5

Introduction

The StarTech.com EOC110K Ethernet over Coax extender kit allows you

to span a 10/100 network over extremely long distances (up to 1.2km)

while still maintaining high speed network connectivity. Allowing Ethernet

connections over existing Coaxial cable with little to no modiﬁcation,

providing a perfect solution for a broad range of applications, including

connecting isolated user stations from the same or separate building,

or overcoming infrastructure obstacles and distances (e.g. older stone/

concrete architecture) where new wiring or wireless may be impossible.

Packaging Contents

• 2 x Ethernet over Coax converter box*

• 2 x Power Adapter*

• 1 x Instruction Manual

*EOC110R only contains one unit

System Requirements

• 10/100Mbps compatible Ethernet network/equipment

• Coaxial cabling (RG-59/6/7/11)

• Available AC power outlet at converter box locations

Rear View

Front View

Installation

Hardware Installation

NOTE: Both of the converter boxes in the EOC110K kit are identical, so

they can be installed at either end, in any order.

1. At one of the locations for the converter box, connect an RJ45 Ethernet

cable from the existing Ethernet network or computer network adapter to

the “LAN” port on the converter box.

2. Connect the coax cable to the “Link” F-Connector on the converter.

3. OPTIONAL: If also transmitting analog cable TV signals over the coax

line, connect the CATV F-Connector to a TV or TV receiver. Digital cable

TV signals are not supported.

4. Connect the included power adapter. The power LED should light up

solid. The LAN Link/Act LED should light up solid when successfully

connected to an Ethernet device on the “LAN” port.

5. Setup additional converter boxes by following the same Steps 1~4 for

each location.

6. Once all units are setup, they should be able to automatically locate one

another over the coax cabling. The Coax Link and Sync LEDs should

stay solid once communication is established. The Coax Link LED will

ﬂash during communication.

7. The devices plugged into the “LAN” ports should now be able to

communicate with one another freely.

Driver Installation

No driver or software installation is required for these converters on any

connected computer systems.

Cable Lengths

Maximum bandwidth (Mbps) based on coaxial cable type and length.

Distance RF

Bandwidth RG-59 RG-6 RG-7 RG-11

100m ~ 700m

< 30MHz

144 144 144 144

800m 128 144 144 144

900m 112 144 144 144

1000m 96 128 144 144

1100m 80 128 144 144

1200m 64 112 128 144

1300m 80 128 144

1400m 80 128 144

1500m 64 112 144

1600m 96 128

1700m 80 128

1800m 80 128

1900m 64 112

2000m 112

2100m 96

2200m 80

2300m 80

2400m 64

Specications

Transmission Standards ITU G.9954, IEEE802.3,

IEEE802.3u, IEEE802.3x

Connectors

(per unit)

2 x F-Connector female

1 x RJ45 female

1 x DC Power

LEDs

(per unit)

1 x Power

1 x LAN Link/Activity

1 x Coax Link/Activity

1 x Coax Sync

Compatible Cabling RG-59, 6, 7, 11

Maximum Distance 2400m (RG-11)

Power Adapter 5VDC, 2000mA, center positive,

type M plug

Operating Temperature 0°C ~ 55°C (32°F ~ 131°F)

Storage Temperature -10°C ~ 65°C (14°F ~ 149°F)

Humidity 10% ~ 90% RH

Dimensions (per unit) 280.0mm x 138.0mm x 76.8mm

Weight (per unit) 320g

Technical Support

StarTech.com’s lifetime technical support is an integral part of our

commitment to provide industry-leading solutions. If you ever need

help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a one year warranty.

In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial

date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion.

The warranty covers parts and labor costs only. StarTech.com does

not warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.

com USA LLP (or their ofﬁcers, directors, employees or agents) for

any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of proﬁts, loss of business, or any

pecuniary loss, arising out of or related to the use of the product exceed

the actual price paid for the product. Some states do not allow the

exclusion or limitation of incidental or consequential damages. If such

laws apply, the limitations or exclusions contained in this statement

may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy” since 1985,

providing high quality solutions to a diverse IT and A/V customer

base that spans many channels, including government,

education and industrial facilities to name just a few. We offer

an unmatched selection of computer parts, cables, A/V products,

KVM and Server Management solutions, serving a worldwide

market through our locations in the United States, Canada, the

United Kingdom and Taiwan.

Visit www.startech.com today for complete information about

all our products and to access exclusive interactive tools such as

the Cable Finder, Parts Finder and the KVM Reference Guide.
