Starblitz ASPIC Manuel utilisateur

ASPIC

User guide /

Mode d’emploi /

Manual de usuario

www.starblitz.fr

Wireless ash

STARBLITZ® ASPIC

User guide

Thank you very much for selecting Starblitz® ASPIC wireless TTL ash light. Please

read these instruction carefully and keep them handy for your reference.

Starblitz® ASPIC TTL studio ash for location shoot, 400Ws (GN 70), 1/8000s high sync

speed, with build- in T TL receiver. Locking SST-818 TX transmitter on camera, you

can total control with remote Starblitz® ASPIC studio ashes, such as TTL/ M/ Multi,

without leaving shooting place. Whether shoot in bright sunshine with wide open

aperture, shoot during fast moving events, or shoot in scene where ambient light

varies, the reliable TTL wireless trigger and 1/8000s high sync speed, makes photo-

graphy with more exibility, freedom and eciency. Starblitz® ASPIC is perfect tool

for shooting portraits, weddings and sports, allowing you to get perfect shot anytime

and anyplace

Sommaire

Safety Note............................................................................................................... 3

Warning Sign............................................................................................................ 3

Content of Carton .................................................................................................... 4

Name of Parts........................................................................................................... 4

Operation Panel....................................................................................................... 6

LCD Screen ............................................................................................................... 4

Prepare ash for use................................................................................................ 8

Switch on Flash Light .............................................................................................. 9

Power Level .............................................................................................................. 9

Charging Battery ................................................................................................... 10

Battery Protective Maintenance .......................................................................... 10

Operating Audible Beep ....................................................................................... 11

Operating Modeling Lamp ................................................................................... 11

Select Triggering Ways .......................................................................................... 11

Wireless Mode........................................................................................................ 12

Setting Channel and Group .................................................................................. 12

Flash Mode-TTL Auto Flash................................................................................... 13

Flash Mode-Multi Stroboscopic Flash.................................................................. 15

Flash Mode-M Manual Flash................................................................................. 16

Constant Color Mode ON/OFF .............................................................................. 17

Use Starblitz® ASPIC with other ashes............................................................... 18

Error codes ............................................................................................................. 18

Auto-dump............................................................................................................. 19

Installing Umbrella................................................................................................ 19

Changing Flash Tube ............................................................................................. 20

Flash Capacitor Preventative Maintenance......................................................... 22

USB Firmware Update ........................................................................................... 22

Main features ......................................................................................................... 22

Features.................................................................................................................. 23

Safety Note

Do not use the unit in an environment where moisture or ammable vapor is likely

to come in contact with the unit.

Do not explore any components in direct sun for a long time. Do not restrict air

vents while in use.

Do not use a unit with damaged covers, ash tubes, modeling lamps. If the unit is

dropped or damaged in any way, always have it checked out before using it. Do not

place ammable materials close to either the ash tube or the modeling lamp when

the unit is in use.

Do not attempt to disassemble or service the unit on your own to avoid shock

hazard. Only ash tubes and batteries may be replaced on your own.

Do not drop foreign objectives inside the housing. There is a risk of electrical

shock. Always use a blower brush or clean facial tissue to remove dust and moisture

from the modeling lamp and the ash tube.

Always turn o the unit whenever mounting or dismounting accessories. Always

turn o the unit and remove battery before maintenance.

Always keep out of reach of children.

Warning Sign

The manual is based on the assumption that both camera and ash light are

powered on.

The following alert symbol is used in this manual:

This Caution symbol indicates a warning to avoid shooting problem.

Content of Carton

Your Starblitz® ASPIC ash light should include the following items, please check

carefully:

1x Starblitz® ASPIC studio ash

1x Lithium battery (included in Starblitz® ASPIC studio ash)

1x LED modeling lamp (included in Starblitz® ASPIC studio ash)

1x 100-240V charger for lithium battery

1x Car charger adapter

1x Standard reector

1x Protective cover

1x Tripod head adapter

1x 4m Sync Cord

Name of Parts

1Standard Reector

2Operation Buttons

3LCD Screen

4Power Switch

5USB Upgrade Terminal

63.5MM Sync Cord Input

7Handle

8Adjusting screw

9Reector Releasing Knob

10 Battery Locking Knob

11 Replaceable Battery

Operation Panel

1«MODEL»

1. Shortly press: Control modeling lamp turn o/ 1/ 2 / 3 / 4 / 5/ 6 in sequence

2. Long press: 1. set channel 2. set group

2«AUDIO»

1. Shortly press: Turn ON / OFF

2. Long press: In Multi mode, set ﬂash times and ﬂash frequency

3«TEST»

Flash test

4«+»

Shortly press: Increase setting value

5«MODE»

1. Shortly press: switch ash mode ETTL auto ash/M manual ash/ Multi strobos-

copic ash

2. Long press: Set color temperature mode

6«–»

Shortly press: Reduce setting value

LCD Screen

12 13 14 15

2 3 4

1Supported TTL mode

2M manual mode/ Multi stroboscopic mode

3Channel 1,2,3,4

4Group A, B, C

5Battery level indicator

6Stroboscopic ash times

7Error indicator

8Modeling lamp ON

9Manual ash output/ Flash exposure compensation (FEC)

10 Stroboscopic ash frequency / Manual ash output

11 Flash recycling ready

12 Modeling lamp output

13 2.4G wireless radio signal

14 Audio beep

15 Flash recycling indicator

Prepare ash for use

1. Fix Flash on Light Stand

Select a light stand or support system of suitable weight and dimensions to ensure

stable operation of the unit. Rotate knob clockwise to lock ash unit rmly on sup-

port system.

The ash unit includes a 1/4”Tripod head adapter. It applies to x on camera tripods

or other support system with 1/4” screw.

2. Release Protective Cap

To remove protective cap, push reector release knob back towards the rear of the

unit and rotate protective cap anti clockwise (Fig 1). Put the protective cap aside.

To avoid deformation of plastic protective cap, always cool down ash unit before

tting protective cap.

3. Install Standard Reector

Install standard reector where the protective cap was before. Align the three pegs

on the reector with the three slots, press the reector in and rotate clockwise until

it locks in place(Fig 2 & 3 ).

Always switch o the unit before tting and changing reectors.

4. Adjust Flash Light Angel

Rotate regulating screw anticlockwise, adjust the unit to appropriate angle. Rotate

regulating knob clockwise to tight ash head.

5. Install Battery

Push battery forward until hear a clicking sound (Fig. 4).

Switch o power before remove battery. Press down lock button and move it

backward (Fig. 5).
