Contents

1. GENERAL DESCRIPTION 1-1

2. COMMAND FUNCTION LIST 2-1

3. COMMAND DETAILS 3-1

3-1 Explanation of Terms 3-1

3-2 Exception processing 3-2

3-3 Standard Command Details 3-3

3-3-1 Font style and character set 3-3

ESC GS t n 3-3

ESC R n 3-4

ESC / N 3-4

ESC 6 3-5

ESC 7 3-5

ESC M 3-6

ESC P 3-6

ESC : 3-7

ESC SP n 3-7

3-3-2 Character Expansion Settings 3-8

SO 3-8

DC4 3-8

ESC W n 3-9

ESC h n 3-9

3-3-3 Print mode 3-10

ESC E 3-10

ESC F 3-10

ESC – n 3-11

ESC n 3-11

ESC 4 3-12

ESC 5 3-12

ESC GS 4 m n 3-13

SI 3-15

DC2 3-15

ESC RS i n 3-16

3-3-4 Line Spacing 3-17

LF 3-17

CR 3-17

ESC a n 3-18

ESC 0 3-18

ESC 1 3-18

ESC z 0 3-19

ESC z 1 3-19

ESC A n 3-20

ESC 2 3-20

ESC 3 n 3-21

ESC y n 3-21

ESC J n 3-22

ESC I n 3-22

3-3-5 Page Control Commands 3-23

FF 3-23

ESC C n 3-24

ESC C NUL n 3-24

VT 3-25

ESC B n1 n2 … nk NUL 3-25

ESC N n 3-26

ESC O 3-26

3-3-6 Horizontal Direction Printing Position 3-27

ESC RS A n 3-27

ESC l n 3-28

ESC Q n 3-29

HT 3-30

ESC D n1 n2 … nk NUL 3-30

ESC GS a n 3-31

ESC GS A n1 n2 3-32

ESC GS R n1 n2 3-32

3-3-7 Download 3-33

ESC & NUL n1 n2 [m d1 d2 d3 d4 d5 (d6 d7)] n2 - n1 + 1 3-33

ESC & m n1 n2 [d1 d2 d3 d4 d5 d6 d7 d8 d9 d10 .... ak dk] n2 - n1 + 1 3-36

ESC % N 3-39

3-3-8 Bit Image Graphics 3-40

ESC K n NUL d1 d2 … dn 3-40

ESC L n1 n2 d1 d2 … dk 3-41

ESC ^ m n1 n2 d1 d2 … dk 3-42

3-3-9 Logo 3-45

ESC FS q n [x11 x12 y11 y12 d1…dk]1…[xn1 xn2 yn1 yn2 d1…dk] n 3-45

ESC FS p n m 3-47

3-3-11 Cutter Control 3-48

ESC d n 3-48

3-3-12 External Device Drive 3-49

ESC BEL n1 n2 3-49

BEL 3-50

FS 3-50

SUB 3-51

EM 3-51

ESC GS EM DC1 m n1 n2 3-52

ESC GS EM DC2 m n1 n2 3-53

3-3-13 Status 3-54

ENQ 3-54

EOT 3-54

ESC ACK SOH 3-55

ESC RS a n 3-55

ETB 3-56

ESC RS E n 3-57

3-3-14 Kanji Characters (only on models that carry Kanji characters) 3-58

ESC p 3-58

ESC q 3-58

ESC $ n 3-59

ESC s n1 n2 3-60

ESC t n1 n2 3-60

ESC r c1 c2 d1...dk 3-61

ESC u 1 3-63

ESC u 0 3-63

ESC x 1 3-64

ESC x 0 3-64

ESC w 1 3-65

ESC w 0 3-65

3-3-15 Others 3-67

RS 3-67

CAN 3-67

DC3 3-68

DC1 3-68

ESC @ 3-69

ESC U n 3-69

ESC GS # m N n1 n2 n3 n4 LF NUL 3-70

ESC # N m n1 n2 n3 n4 LF NUL 3-71

ESC ? LF NUL 3-72

3-4 Black Mark Related Commands 3-73

ESC d n 3-74

FF 3-75

ESC FF n1 n2 3-76

ESC GS ( F p1 p2 a m n1 n2 3-77

ESC RS m n 3-78

3-5 USB Related Commands 3-79

3-6 2-Color Printing Command Details 3-80

ESC RS C n 3-80

ESC 4 3-81

ESC 5 3-81

4. CHARACTER CODE TABLE 4-1

5. APPENDIX 5-1

5-1 StatusSpecications 5-1

5-1-1 ENQ Command Status 5-1

5-1-2 EOT Command Status 5-1

5-1-3 Automatic Status 5-2

5-1-4 PrinterStatusTransmissionSpecicationwhenusingEthernetandWirelessLANInterfaces 5-7

5-2 Expansion Position 5-9

5-2-1 7 x 9 Fonts 5-9

5-2-2 5 x 9 (2P-1) Fonts 5-9

5-2-2 Japanese Character Fonts 5-10

6. SPECIAL APPENDIX COMMAND LIST BY MODEL 6-1

1-1STARCommandSpecications

Rev. 0.70

1. GENERAL DESCRIPTION

ThisspecicationsdocumentdescribesthecommandspecicationsfortheSTARMODEondotimpactprinters.

Information contained herein applies to models with the following conditions.

• Dot impact printers

• Printer head: 72 DPI (vertical direction)

• Interfaces: Parallel/RS-232C/USB/Ethernet/Wireless LAN

• Paper width: 3 inch/2.25 inch/1.75 inch

• Paper feed minimum pitch: 1/144 inch (0.176 mm)

<ApplicableModels:>

•Individualboards: BD100,BD500

• Complete printer product: SP2000, SP500, SP700

2-1STARCommandSpecications

Rev. 0.70

2. COMMAND FUNCTION LIST

• Standard Commands

Class Commands Name

Font Style and

Character Set

ESC GS t Specify code page

ESC R Specify international character set

ESC / Specify/cancel slash zero

ESC 6 SwitchtoIBMcharacterset#2(onlywithstandardspecications)

ESC 7 SwitchtoIBMcharacterset#1(onlywithstandardspecications)

ESC M Specify 7 x 9 font (half dots)

ESC P Specify 5 x 9 font (2P-1)

ESC : Specify 5 x 9 font (3P-1)

ESC SP Set character space

Character

Expansion

Settings

SO Specifydouble-wideexpandedcharacters

DC4 Canceldoublewideprinting

ESC W Specify/canceldouble-wideprinting

ESC h Specify/canceldouble-tallprinting

Print Modes ESC E Select emphasized printing

ESC F Cancel emphasized printing

ESC - Select/cancel underline mode

ESC _ Select/cancel upperline mode

ESC 4 Specifywhite/blackinversionandredcolorprinting

ESC 5 Cancelwhite/blackinversion/specifyblackcolorprinting

ESC GS 4 Selectred/blacksubstitutefunction[ESC4/5setting]

SI Select upside-down printing

DC2 Cancel upside-down printing

ESC RS i Specify/cancel rotating print mode

Line Spacing LF Line feed

CR Line feed (according to memory switch settings)

ESC a Feed paper n lines

ESC 0 Set line feed to 1/8 inch

ESC 1 Set line feed to 7/72 inch

ESC z 0 Set line feed to 1/12 inch

ESC z 1 Set line feed to 1/6 inch

ESC A Denen/72inchpitchlinefeed

ESC 2 Set ESC A line feed pitch

ESC 3 Set line feed to n/216 inch line feed pitch (approximate value)

ESC y Set line feed to n/144 inch line feed pitch

ESC J Execute n/72 inch paper feed one time

ESC I Execute n/144 inch paper feed one time

FF Form feed

Page Control ESC C Set page length to n lines

ESC C 0 Set page length to n inches

VT Feedpapertoverticaltabposition

ESC B Setverticaltabposition

ESC N Setbottommargintonlines

ESC O Cancelbottommargin

2-2STARCommandSpecications

Rev. 0.70

Class Commands Name

Horizontal ESC RS A Set print region

Direction ESC I Set left margin

Position ESC Q Set right margin

HT Moveprintpositiontohorizontaltabposition

ESC D Set/cancelhorizontaltabposition

ESC GS a Specify position alignment

ESC GS A Specifyabsoluteposition

ESC GS R Specify relative position

Download ESC & Register download characters

ESC % Specify/cancel download characters

Bit Image ESC K Standarddensitybitimage

Graphics ESC L Doubledensitybitimage

ESC ^ 9Dotbitimage

Logos ESC FS q Register logo

ESC FS p Print logo

Cutter Control ESC d Paper cut instruction

External ESC BEL Set pulse width for external device drive

Device Drive BEL External device 1 drive instruction

FS External device 1 drive instruction (real time)

SUB External device 2 drive instruction (real time)

EM External device 2 drive instruction (real time)

ESC GS EM DC1 Setexternalbuzzerdrivepulsecondition

ESC GS EM DC2 Executeexternalbuzzerdrive

Status ENQ Inquire ENQ status

EOT Inquire EOT status

ESC ACK SOH Inquire automatic status

ESC RS a Set automatic status transmission conditions

ETB Update ETB status (check after printing)

ESC RS E Clear ETB counter, ETB status

Kanji characters

(Note 1) ESC p SettoJISChinesecharactermode(Japanesespecicationsonly)

ESC q CancelJISJapanesecharactermode(Japanesespecicationsonly)

ESC $ Set/cancelJISJapanesecharactermode(Japanesespecicationsonly)

ESC s SettwobyteKanjicharactersleft/rightspaces

ESC t Set1byteKanjicharactersleft/rightspaces(Japanesespecications

only)

ESC r Register Chinese download characters

ESC u 1 Specify 16 x 16 dot [single density] Kanji characters.

ESC u 0 Specify16x16dot[DoubleDensity]Kanjicharacters

ESC x 1 SpecifytwobyteKanjicharacters(cancelexpandedKanjicharacters)

ESC x 0 SpecifyexpandedKanjicharacters(Doubletall/Doublehigh/Doublehigh

& wide)

ESC w 1 Specify2-byte16x16dot[SingleDensity]Kanjicharacters (Default)

ESC w 0 Specifydoublehigh&wideKanjicharacters

2-3STARCommandSpecications

Rev. 0.70

Class Commands Name

Others RS Ringbuzzer

CAN Cancel print data and initialize commands

DC3 Printer deselect

DC1 Select printer

ESC @ Command initialization

ESC U Select printing direction

ESC GS # Set memory switch

ESC # Set memory switch

ESC ? LF NUL Reset printer and execute self print

Note 1 Kanji characters

• Japanese character control commands are ignored on models not installed with Japa-

nese character fonts.

• All Japanese character control commands are ignored if the specication for the location

of use is specied as SBCS (single byte countries) by the memory switch.

• Black Mark Related Commands

Class Commands Name

Black mark

commands

ESC d (Note 2) Paper cut instruction

FF (Note 2) Performs TOF operation

ESC FF Settopofformamountafterdetectingblackmark

ESC GS ( F Settopofformamountinblackmarkcontrol

ESC RS m Enable,disableblackmarkdetection

Note 2 These are commands whose operation specications vary when the black mark func-

tion is enabled by the memory switch.

• USB Related Commands

Class Commands Name

USB

Related com-

mands

• 2-Color Printing Related Commands

Class Commands Name

2-Color Printing ESC RS C Select/cancel 2-color printing mode

Related ESC 4 Specify red printing

Commands ESC 5 Specifyblackprinting

3-1STARCommandSpecications

Rev. 0.70

3. COMMAND DETAILS

3-1 Explanation of Terms

•Receptionbuffer

Thebufferforstoringdata(receptiondata)receivedfromthehost,asitiscalledthereceptionbuffer.

Receptiondataistemporarilystoredinthereceptionbuffer,thenprocessedsequentially.

•Linebuffer

Thebufferforstoringimagedataforprintingiscalledthelinebuffer.

•Linebufferfull

Thestateinwhichthebufferhasnomorespaceavailableiscalledlinebufferfull.Whenthebufferisfull,dataintheline

bufferisprintedandalinefeedisperformedwhennewprintdataisprocessed.ThisisthesameasaLineFeed.

• Top of line

Thetopoflineisastatethatsatisesthefollowingconditions.

A.Thereiscurrentlynoprintdatainthelinebuffer.

B.Thepositionisnotspeciedwiththehorizontaldirectionpositioncommand.

•Printableregion

Thisisthemaximumprintableareawiththeprinter’sspecications.

• Print region

Thisistheprintingareaspeciedbyacommand.(PrintRegion≤PrintableRegion)

• SBCS

ThisisanabbreviationofSingleByteCharacterSet.Thesearecharactersinlanguagesthataredisplayedusingthe

informationinonebyte.

Inthisspecicationsmanual,itreferstothestandardspecications(destination:singlebytecountries).

• DBCS

ThisisanabbreviationofDoubleByteCharacterSet.Thesearecharactersinlanguagesthataredisplayedusingthe

informationintwobytes.

Inthisspecicationsmanual,itreferstotheChinesecharacterspecicationssuchasJapan,ChinaandTaiwan(destina-

tion:doublebytecountries).

• Inch

This is a unit of length. 1 inch = 25.4 mm

• MSB

ThisisanabbreviationofMostSignicantBit.

• LSB

ThisisanabbreviationofLeastSignicantBit.

3-2STARCommandSpecications

Rev. 0.70

3-2 Exception processing

1)Undenedcodes

Codesfrom<00>Hto<1F>Haretargeted.Whencodesnotdenedascommandsinthisregionarereceived,theyare

discarded.

(Ex.)Ifprocessingthedatastringof<30>H<31>H<03>H<32>H<0A>H<33>H,theprinterwilldiscard<03>Hasan

undenedcode.

2)Undenedcommands

WhendatacontinuingthecodesofESCandFSarecodesnotdenedascommands,ESCandFSandsubsequent

codes are discarded.

(Ex.)Ifprocessingthedatastringof<30>H<1B>H<22>H<31>H<32>H,theprinterwillreadanddiscard<1B>H<22>H

asanundenedcommand.

3)Settingsoutsideofthedenedarea

Processingvaluesoutsideofthedenedareaincommandsaccompanyingarguments,thosecommandsareignored

and the preset values are unchanged.The processing of commands is terminated at the point values outside of the de-

nedregionareprocessedinargumentshavingapluralityofcommands.

(Ex.)Ifprocessingthedatastringof<1B>H<52>H<15>H,theprinterwilldiscardthedatastringof<1B>H<52>H<15>H

becausealthough<1B>H<52>Hisdenedasacommands(ESCR),theargument<15>Hisoutsideofthedenition.

Therefore, the international character set that is already set experiences no change.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Star Imprimante

Star

Star LC-4511 Manuel utilisateur

Star

Star TSP700II Manuel utilisateur

Star

Star SM-S220 Series Manuel utilisateur

Star

Star StarPRNT mC-Print3 Series Guide de démarrage rapide

Star

Star LC-1511 Manuel utilisateur

Star

Star SM-S201 Manuel utilisateur

Star

Star SM-S220I SERIES Manuel utilisateur

Star

Star SP747R Series Manuel utilisateur

Star

Star mC-Print3 MCP31LB Guide de sécurité

Star

Star TSP100IIIBI Guide de démarrage rapide

Star

Star SP712R series Manuel utilisateur

Star

Star TUP500 Guide de configuration rapide

Star

Star TSP654II Series Manuel utilisateur

Star

Star TSP143 Manuel utilisateur

Star

Star Line Thermal/Dot Printer Manuel utilisateur

Star

Star StarPRNT mC-Print3 Series Manuel utilisateur

Star

Star TSP400 SERIES Manuel utilisateur

Star

Star TSP800II SERIES Manuel utilisateur

Star

Star DP8340 SERIES Manuel utilisateur

Star

Star TSP650 SERIES Instructions de montage

Star

Star AR-1000 Manuel utilisateur

Star

Star TSP100III Series Manuel utilisateur

Star

Star Gemini-10X Manuel utilisateur

Star

Star SP298 SERIES Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
