Pyxis

User Guide

Version 0.3.3

FCC ID:2AA7KPYXIS-HRD23000

Pyxis User Guide - Version 0.3.3 1

Contents

User Guide .................................................................................................................................2

1. Introduction........................................................................................................................4

1.1 Intro........................................................................................................................................................... 4

1.2 CAUTION READ THIS BEFORE USING BATTERY ........................................................................................... 5

1.3 Charger ...................................................................................................................................................... 5

1.4 Notes ......................................................................................................................................................... 6

2. Components and Features...................................................................................................7

2.1 Components and Buttons .......................................................................................................................... 7

2.2 Device Specifications ................................................................................................................................. 8

2.3 Micro SD, SIM card....................................................................................................................................10

2.4 Battery Charging .......................................................................................................................................10

3. UHF RFID........................................................................................................................... 11

4. Other Features.................................................................................................................. 12

4.1 PING tool ..................................................................................................................................................12

4.2 Bluetooth..................................................................................................................................................13

4.3 GPS ...........................................................................................................................................................14

4.4 Volume setup............................................................................................................................................15

4.5 Sensor.......................................................................................................................................................16

4.6 Keyboard ..................................................................................................................................................17

4.7 Network....................................................................................................................................................18

4.8 Keyboard emulator (optional)...................................................................................................................19

4.9 Call function..............................................................................................................................................20

Calling numbers ....................................................................................................................................................... 20

Contacts ................................................................................................................................................................... 20

SMS and MMS.......................................................................................................................................................... 20

5. Optional Features ............................................................................................................. 21

5.1 Barcode Scanner (Optional) ......................................................................................................................21

Restrictions:............................................................................................................................. 23

SAR Information....................................................................................................................... 24

Simplified EU declaration of conformity ................................................................................... 24

Warranty ................................................................................................................................. 25

WARRANTY ..........................................................................................................................................................25

EXCLUSIONS .........................................................................................................................................................25

RMA PROCEDURE.................................................................................................................................................25

DISCLAIMER OF WARRANTIES ..............................................................................................................................25

LIMITATION OF LIABILITY .....................................................................................................................................25

Pyxis User Guide - Version 0.3.3 2

User Guide

Version 0.3.3

07th August 2019

Star Systems International and the Star Systems International logo are trademarks of Star Systems

International Ltd. in Hong Kong and other countries.

Specifications are subjected to changes without prior notice.

Disclaimer and limitation of liability

Star Systems International Ltd. shall not be liable for technical or editorial errors or omissions contained

herein or for incidental or consequential damages about the furnishing, performance, or use of this

material. The information in this document is provided “as is” without warranty of any kind - including but

not limited to, the implied warranties of merchantability and fitness for a purpose and is subjected to

change without notice. The warranties for Star Systems International products are set forth in the express

limited warranty statements accompanying such products. Nothing herein should be construed as

constituting an additional warranty.

This document contains proprietary information that is protected by copyright. No part of this document

may be photocopied, reproduced, or translated to another language without the prior written consent of

Star Systems International Ltd.

This product is not designed, intended, authorized or warranted to be suitable for life support applications

or any other life critical applications which could involve potential risk of death, personal injury, property

damage, or environmental damage.

Your safety is extremely important. Read and follow all warnings and cautions in this document before

handling and operating RFID equipment. You can be seriously injured, and equipment and data can be

damaged if you do not follow the safety warnings and cautions.

A caution alerts you to an operating procedure, practice, condition, or statement that must be strictly

observed to prevent equipment damage or destruction, or corruption or loss of data.

Note: Notes either provide extra information about a topic or contain special instructions for handling a

condition or set of circumstances.

Pyxis User Guide - Version 0.3.3 3

FCC Compliance

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications

or changes to this equipment. Such modifications or changes could void the user’s authority to operate the

equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

. Reorient or relocate the receiving antenna.

. Increase the separation between the equipment and receiver.

.Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

.Consult the dealer or an experienced radio/TV technician for help. During SAR testing, this device is set to transmit

at its highest certified power level in all tested frequency bands, and placed in positions that simulate RF exposure

in usage near the body with the separation of 10 mm. Although the SAR is determined at the highest certified power

level, the actual SAR level of the while operating can be well below the maximum value. This is because the device

is designed to operate at multiple power levels so as to use only the power required to reach the network.

In general, the closer you are to a wireless base station antenna, the lower the power output.

FCC Radiation Exposure Statement .

This device was tested for typical body.worn operations with the back of the handset kept 10mm from the body.

To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 10 mm separation

distance between the user's body and the back of the handset. The use of belt clips, holsters and similar accessories

should not contain metallic components in its assembly. The use of accessories that do not satisfy these

requirements may not comply with FCC RF exposure requirements, and should be avoided.

RF Exposure Information(SAR)

The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue.

Device Types HRD23001F (FCC ID: 2AA7KPYXIS-HRD23000) has also been tested against this SAR limit.

The highest SAR value reported under this standard during product certification for use when properly worn on

the body is1.168 W/kg and for head is 0.24 W/kg

Pyxis User Guide - Version 0.3.3 4

1. Introduction

1.1 Intro

PYXIS device is a smart mobile PDA that integrated with various features such as wireless communication,

data acquisition, wireless transmission, data processing and UHF scanning etc. It is configured with Android

OS and it possesses high reliability and expansibility. With a set of advanced data acquisition options, PYXIS

can be operated in various industries to acquire precise and abundant datum automatically. Meanwhile,

the device can match the options with staffs accordingly. The corporation which deployed PYXIS will realize

the deployment work is simple and maintenance work will be remarkably decreased.

PYXIS is highly rugged, compact and durable. With IP65 water and dustproof capability, the device has met

IEC sealing standard. Therefore, it can be operated by staff such as Vehicle Administration, Inventory

Management, Asset Management, Fleet Management etc. Wherever your staff locations are, PYXIS can

remain its connectivity with the system to make sure business in high-effective operating.

PYXIS mobile data terminal adopted 4G LTE technology to realize multipath communication and calling

function for fieldwork, data exchange efficiency has been enhanced simultaneously (Optional). Therefore,

PYXIS will bring the largest investment return for enterprises.

Pyxis User Guide - Version 0.3.3 5

1.2 CAUTION READ THIS BEFORE USING BATTERY

•Do not leave the battery unused for an extended period of time, whether it is in the device or not.

If the battery has been used for over 6 months, it should be checked to assure the charging

function is working properly or it should be disposed of correctly.

•The lifespan of a Li-ion battery is around 2 to 3 years, it can be recharged for approximately 300 to

500 times. (One full battery charge period means completely charged and completely discharged.)

•Even when a Li-ion battery is not in use, it will continue to discharge slowly. Therefore, the battery

charging status should be checked frequently per recommended practices.

•Observe and record the information of any new unused and non-fully charged battery. Based on

operating time of new battery and compare with a battery that has been used for long time.

According to product configuration and application program, the operating time of battery would

be different.

•Check battery charging status at regular intervals.

•When the battery capacity drops below about 80%, charging time may be increased.

•If a battery is stored or otherwise unused for an extended period, be sure to follow the storage

instructions in this document. If you do not follow the instructions, and the battery has no charge

remaining, consider it to be damaged. Do not attempt to recharge it or to use it. Replace it with a

new battery.

•Store the battery at temperatures between 5 °C and 20 °C (41 °F and 68 °F).

1.3 Charger

The charger model is GME10D-050200FGu, output voltage/current is 5V DC/2A.

Pyxis User Guide - Version 0.3.3 6

1.4 Notes

1. Using the incorrect type battery is dangerous and may cause fire or an explosion.

Please dispose the used battery according to instructions.

2. The Reader Device and its battery should only be connected to a USB Interface, version 2.0 or higher.

Using other types of USB power is not recommended and will void your warranty.

3. The suitable temperature range for this product and accessories is 0-10°C to 50°C.

4. Caution risk of explosion if battery is replaced by an incorrect type. Dispose of any used batteries

according to the instructions.

Pyxis User Guide - Version 0.3.3 7

2. Components and Features

2.1 Components and Buttons

Pyxis has 4 side buttons, 4 main buttons and a trigger on handle, UHF scanning area,

2D scanning module (OPTIONAL), HD camera and flashlight locate on the top.

Function Description

1. RGB LED Monitor Display Device

2. Light Sensor, Distance Sensor Light and distance detection

3. Front Camera Photos and Videos record

4. UHF Scanning Module Scanning RFID Tags

5. Menu Display main menu

6. Home Back to main screen

7. Back Return to last step

8. Trigger Start scanning or take photos

9. Scan button

Two Scanning buttons located on each

side of the Pyxis

10. SIM/SD Card Slot Install SIM card or SD card

11. Barcode Scanner Scan 1D/2D barcode (OPTIONAL)

12. Top Camera, Flashlight Photos and Videos record

13. Power button Press to turn on/off device

14. Setup button

Custom function which can be defined

by software

910

Pyxis User Guide - Version 0.3.3 8

2.2 Device Specifications

Physical characteristics

Size

164.2mm*78.8mm*17mm

Weight

<654g (battery included)

Display

5.2 inch, IPS FHD 1920*1080P

Touch panel

4 main keyboards, 1 power button, 2 scan

buttons, 1 multi-function button

Battery

Li-ion, rechargeable, 8000mAh

Expansion

Micro SD card, up to 32 GB

Expansion Slot

1 SIM, 1 SIM/Micro SD

Audio

speaker, 2 microphones, voice call

Camera

13MP autofocus camera with flashlight

Performance

CPU

Cortex-A53 1.45GHz Quadcore

Android

RAM

2GB RAM

Communication

Interface

USB2.0, Type-C, OTG

ROM

16GB

Max. expansion

Supports up to 32 GB Micro SD card

User environment

Operating temp.

-10℃to 50℃

Storage Temp.

-40℃to 70℃

Humidity

5%RH – 95%RH non-condensing

Sealing

IP65, IEC sealing standard

Drop

specification

Multiple 1.8m/4.0ft drops to the concrete

Pyxis User Guide - Version 0.3.3 9

Communication

WAN

EU（Option）:

2G: 850/900/1800/1900MHz

3G: 850/900/1900/2100MHz

4G: B1, B3, B5, B7, B8, B20, B40

（

Option

）

2G: 850/900/1800/1900MHz

3G: 850/900/1700/1900MHz

4G: B2, B4, B7, B12, B17

（

Option

）

2G: 900/1800MHz

3G: 900/1900/2000/2100MHz

4G: B1, B3, B5, B38, B39, B40, B41

WLAN

IEEE802.11a/b/g/n, embedded antenna,

5 Gigabit WiFi (5G wifi isn’t support hotspot)

WiFi 2.4G; max. power 14.69 dBm

WiFi 5G - Band1: max. power 14.69 dBm

WiFi 5G - Band2: max. power 12.82 dBm

WiFi 5G - Band3: max. power 13.08 dBm

SRD5.8G; max. power 12.29 dBm

WPAN

Bluetooth 4.0; max. power 6.16 dBm

Data collection

Barcode

scanning

(Optional)

2D CMOS scanning engine

(Honeywell N6603/Zebra SE4710)

RFID

NFC 13.56Mhz

62.57 dBμV/m (3m) -14.23dBμA/m (10m)

Developing Environment

SDK

STAR Systems software develop kit

Language

Java

Develop

Eclipse/Android Studio

Autres manuels pour Pyxis

Table des matières

Autres manuels Star systems Scanner

Star systems

Star systems Pyxis Manuel utilisateur

Manuels Scanner populaires d'autres marques

Plustek

Plustek Scanner Manuel utilisateur

Z/I Imaging

Z/I Imaging PhotoScan 2001 Manuel utilisateur

Renkforce

Renkforce DS100-5M Manuel utilisateur

Image Access

Image Access WideTEK A2 Manuel utilisateur

Canon

Canon imageFORMULA CR-120N Manuel utilisateur

Fujitsu

Fujitsu FI-4860C2 Manuel utilisateur

GeoSlam

GeoSlam ZEB Horizon Instructions d'installation

Kodak

Kodak i5800 Scanner Manuel utilisateur

Kodak

Kodak i7300 Manuel utilisateur

Revopoint

Revopoint POP Manuel utilisateur

Fujitsu

Fujitsu fi-4860C Manuel utilisateur

Eddyfi Technologies

Eddyfi Technologies Floormap X Manuel utilisateur

Faselase

Faselase F6 Manuel utilisateur

Fujitsu

Fujitsu CardMinder Manuel utilisateur

Uniden

Uniden BC340CRS Manuel utilisateur

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Manuel utilisateur

Mustek

Mustek PageExpress 4800 Pro Manuel utilisateur

Optex

Optex 750830 Manuel utilisateur
