Star Micronics SP500 Series Manuel utilisateur

The SP500 from Star Micronics combines renowned

reliability and a multitude of high end features into a

compact, value-driven solution. It is capable of fast

output, printing 40 columns at 4 lines per second. The

SP500 series have a bi-directional, logic seeking

mechanism resulting in an exceptional throughput,

outpacing its nearest competition.

Its compact footprint is further enhanced by its internal

power supply - no "brick on a rope" for this printer. An

example of which is shown in the highly effective cable

management system allowing the interface and internal

power supply cables to be neatly tucked away behind a

protective cover.

The hinged cover of the SP500, with its integrated rain

channel, protects the printer from liquid spills and other

debris. Protection from the elements and the single

color highlight feature of the SP500 series provides an

excellent solution for food service and kitchen

applications.

Visit www.starmicronics.com to learn more.

VVaauuee -- DDrriivveenn

IImmppaacctt PPrriinntteerr

SSPP550000

Retail Hospitality Ticketing Data Terminal

•Splash Resistant Design

•High Speed Logic Seeking Technology

•Prints Graphics

•Recessed Cable Connections

•Print on Receipt Paper or Ticket Stock

•Single Color Highlighting

Features

The Va ue Impact POS So ution!

Hardware

High Speed, Logic Seeking Print Head

Semi Automatic Paper Loading

Recessed Cable Connections

Splash Resistant Design

Small Footprint

Multiple Copy Support (Original + 2 copies)

Built-in Universal Power Supply

Horizontal & Vertical Use

Software

Logo Utility (Store Logos, Coupons, and Graphics)

Memory Switch Configuration / Setup Utility

Ethernet / WiFi Interface Setup Utility

StarIO SDK

Connectivity

Note: Connections in bboollddare supported;

grayed-out connection types may be

supported by special request.

9-Pin Serial

25-Pin Seria

Para e

USB

Powered USB

Ethernet

WiFi

Dual 9-Pin Serial/USB

Virtual Serial Port to USB

Virtual Serial Port to Ethernet

Virtual TCP/IP Port

Drivers

Windows®XP

Vista (32 bit / 64 bit)

Windows 7 (32 bit / 64 bit)

Server 2008 (32 bit / 64 bit)

XP Embedded

POS for .NET

OPOS™

JavaPOS™

USB Vendor C ass

What's Inc uded

Auto Cutter (SP542) or Tear Bar (SP512)

Ribbon Cartridge

User Manual

Paper Guide for 57.5mm Paper Width

Power Switch Cover

AC Power Cable

Ferrite Core (Ethernet Model)

Optiona Accessories

ournal / Rewinder Model

Putty or Gray Color Housing Model

Wall Mount Kit (WB-S500)

Vertical Stand Kit (VS-S500)

Ticket Alarm Buzzer (BU01-24-A)

Near End Paper Sensor

Technica Specifications

Print Method : 9-Pin Impact Dot Matrix

Print Speed : 4.2 LPS (40 columns)

Paper Width : 76mm, 57.5mm(w/ Paper Guide)

Paper Thickness : 0.07 - 0.10mm

Paper Diameter : Maximum 85mm

Emulation : Star Mode, ESC/POS™

Power: AC 90 to 264V 50/60 Hz

MCBF: 22 Million Lines

Cutter: 0.3 Million Cuts

Dimensions: W=140mm, H=163mm, D=225mm

Warranty For US and Canada: 3-Year Limited Warranty, Plus Optional Extended Services Agreement Policies (Extend-A-Star and Swap-A-Star)

For Further Information Sales: 1-800-782-7636 x107

Technical Support: 1-800-782-7636 x105

Web: http://www.starmicronics.com

SP500 Specifications

2/25/10
