Stab ROTOR SAT HH100i Manuel utilisateur

CONTENTS

- INTRODUCTION ......................................................................................................... page 1

- ROTOR TECHNICAL DATA ..................................................................................... page 2

- INTERFACE TECHNICAL DATA ............................................................................ page 3

- MOUNTING INSTRUCTIONS .................................................................................. page 4

1. Where to install the sat dish .................................................................................... page 4

2. Rotor’s installation.................................................................................................... page 4

3. Connections ................................................................................................................ page 5

3.1 Specifications of the recommended coaxial cable........................................... page 5

3.2 Map to determine the installation parameters - EUROPE MAP ................ page 6

NORTH AFRICA MAP ..................................................................................... page 6a

MIDDLE EAST MAP......................................................................................... page 6b

SOUTH EAST ASIA MAP ................................................................................ page 6c

4. How to find out the elevation angle of the Rotor ................................................. page 7

5. How to find out the elevation value of the dish .................................................... page 7

6. Dish pointing .............................................................................................................. page 7

- USE OF THE REMOTE CONTROL......................................................................... page 10

7. Description of the normal buttons use ................................................................... page 10

8. Description of the special buttons use .................................................................... page 10

9. Storing a satellite position ........................................................................................ page 10

10. Setting and storing the EAST - WEST limits ..................................................... page 11

11. Recalculation function ............................................................................................ page 11

12. Return to the 0° position of the rotor................................................................... page 12

13. Restoring the satellites tables ................................................................................ page 12

- PROBLEMS SOLVING GUIDE ................................................................................. page 13

- WARRANTY CONDITIONS ...................................................................................... page 14

- HOW TO CONTACT US ............................................................................................. page 15

Via Seminiato, 79

44031 AMBROGIO (FE) ITALY

http:// www.stab-italia.com

e-mail: [email protected]

ROTOR SAT HH100i- HH120i

with interface

Rotor Sat HH100i-HH120i instructions manual – page 1

Attention:

•Please read carefully this instructions manual before installing and using it.

•If your receiver includes DiSEqCTM 1.2 protocol, you will not need to connect the interface.

•When you will decide to replace your old receiver with a new one, kindly check if the new receiver

includes DiSEqCTM 1.2 protocol before buying it.

DEAR CUSTOMER,

Congratulations! You are now the owner of STAB ROTOR SAT.

This is the first sat motor developed by STAB in cooperation with EUTELSAT in order to define the

DiSEqCTM 1.2 standard.

The DiSEqCTM 1.2 system is a trademark of EUTELSAT.

All drawings and technical data are STABTM property and can be changed without prior notice.

Rotor Sat HH100i-HH120i instructions manual – page 2

ROTOR TECHNICAL DATA

SPECIFICATIONS

- Operating protocol DiSEqCTM 1.2 Level

- Maximum antenna diameter 100 cm

- Maximum antenna weight 12 Kg

- Antenna support length 125mm

- Rotation angle ±62°

- Rotation speed 1,8°/s(18V) 1,2/s(13V)

- Operating power supply 13 / 18 Vdc

- Consumption in stand-by mode 30mA

- Consumption in operating mode 190mA

- Starting consumption max 350mA

- Operating temperature -40°C +80°C

- Maximum relative humidity 100%

-Programmablepositions 49 satellites

- Preset positions 26 satellites

- Connectors F type

- Connections Sat coaxial cable

- Mechanical limits ±70°

- Software programmable limits from 5° to 62°

- Fine tuning impulse0,1°

- Inclination max 70°

- Weight 3 Kg

OPTION

- Extension for antenna support

SPECIFICATIONS

- Operating protocol DiSEqCTM 1.2 Level

- Maximum antenna diameter 120 cm

- Maximum antenna weight 17 Kg

- Antenna support length 180mm

- Rotation angle ±62°

- Rotation speed 1,1°/s(18V) 0,8/s(13V)

- Operating power supply 13 / 18 Vdc

- Consumption in stand-by mode 30mA

- Consumption in operating mode 190mA

- Starting consumption max 350mA

- Operating temperature -40°C +80°C

- Maximum relative humidity 100%

-Programmablepositions 49 satellites

- Preset positions 26 satellites

- Connectors F type

- Connections Sat coaxial cable

- Mechanical limits ±70°

- Software programmable limits from 5° to 62°

- Fine tuning impulse0,1°

- Inclination max 70°

- Weight 3,2 Kg

ROTOR SAT HH100 ROTOR SAT HH120

OPTIONAL

Rotor Sat HH100i-HH120i instructions manual – page 3

INTERFACE TECHNICAL DATA

Voltage to LNB........................................... 13 / 18 Vcc

Power supply ...................... 230 Vac (110 on request)

Frequency ..............................................50 Hz (60 Hz)

Operating power consumption .......................... 12 W

Power supply in stand-by mode........................... 5 W

Display................................................................. 3 digit

Connectors.......................................................... F type

Connections ...................................... sat coaxial cable

Weight ................................................................... 750 g

Dimensions.......................................71 x 59 x 150 mm

Operating command.................manual or automatic

by remote control

Operating protocol ..............................DiSEqCTM 1.2

WARNING

•Avoid exposure of the interface to rain or humidity as it could cause sparks or electric shocks.

•Do not open the interface and do not touch any components with your hands, screwdrivers or any other

objects as it can cause damage and is extremely dangerous.

•Before operating the motor, make sure that the temperature of the interface is adjusted to that of the

surrounding environment (5°C ÷ 40°C).

•The interface is sensitive to magnetic fields. Therefore keep it away from motors, magnets, etc.

•Place the interface over a flat and stable surface and avoid heavy knocks.

•If the interface drops to the floor, disconnect it immediately from the mains. If after careful examination

there is no damage to the box, you can connect it again. Otherwise if there is evidence of damage, please

contact your local dealer.

MOUNTING INSTRUCTIONS

Rotor Sat HH100i-HH120i instructions manual – page 4

1. Where to install the sat dish

1.1 Choose a position from where the dish can see the SOUTH without any impediments or obstructions.

Buildings, trees, water-pipes etc. can block partially or completely the sat reception.

2. Rotor’s installation

2.1 Fix the supporting pole (ø 50 ÷ 83 mm diameter) in a perfectly

vertical position.

2.2 Use the provided support to fix the rotor to the pole (fig. 1).

It is strictly forbidden to install the motor upside-down.

2.3 Point the rotor position to the south using a compass (fig. 2).

2.4 Assemble the dish according to the manufacturer’s instructions.

2.5 Fixthedishtotherotor’s antenna supportwiththeprovidedbrackets

(fig. 1).

2.6 Align the dish to rotor’s pole indicator (fig. 2 - 3).

2.7 On a coax cable approximately 1,5 m long, set up two F-connectors

(fig. 4) and connect the LNB to the rotor’s LNB plug (fig. 5 - cable 1).

2.8 Fit an F-connector on each end of the cable going to the interface

(fig. 4) and connect the rotor’s REC plug to the MOTOR plug of

the interface (fig. 5 - cable2).

Warning: - See cable specifications on page 5.

2.9 With the provided shorter cable connect the REC plug of the

interface to the input plug of your receiver (fig. 5 - cable 3).

MINIMUM

HEIGHT

TO AVOID

VIBRATION

FIG. 1

F-CONNECTOR

3 mm

15 mm

8 mm

FIG. 2

FIG. 3

FIG. 4

SOUTH

3. Connections (fig. 5)

Rotor Sat HH100i-HH120i instructions manual – page 5

cable n. 2 cable n. 1

cable n. 3

(provided)TV

LNB

RECEIVER

ANT. 2

ANT. 1

REC LNB

3.1 Specifications of the recommended coaxial cable

CABLE

LENGTH TO 30 M

(to 98.4 feet) FROM 30 TO 60 M

(from 98.4 to 196.8 feet)

Cable type sat coaxial cable sat coaxial cable

Inner conductor CU ø=1,02 mm CU ø=1,13 mm

Inner conductor resistance 22 ohm/Km 18 ohm/Km

Outside conductor resistance 22 ohm/Km 10 ohm/Km

A bad quality cable can prejudice the motor correct working!

Please follow the next specifications:

cable n. 3

REC MOTOR

REMOTE CONTROL

INTERFACE

cable n. 1

(provided)

cable n. 2

FIG. 5 RECEIVER ROTOR LNBINTERFACE

Rotor Sat HH100i-HH120i instructions manual – page 6

LONGITUDE

3.2Map to determine the installation parameters - EUROPE MAP

3.2 Map to determine the installation parameters - NORTH AFRICA MAP

LONGITUDE

Rotor Sat HH100i-HH120i instructions manual – page 6a

3.2 Map to determine the installation parameters - MIDDLE EAST MAP

LONGITUDE

Rotor Sat HH100i-HH120i instructions manual – page 6b
