Camera Installation
Before you install the camera, carefully plan where and how it will be positioned, and where you
will route the cable that connects the camera to the power adaptor.
Before starting permanent installation, verify its performance by observing the image on the
receiver when the camera is positioned in the same location/position where it will be permanently
installed and the receiver is placed in the location where it will be used most of the time.
Installation Warnings
Aim the camera(s) to best optimize the viewing area: Select a location for the camera that provides
a clear view of the area you want to monitor, which is free from dust, and is not in line-of-sight to a
strong light source or direct sunlight.
Avoid installing the cameras where there are thick walls or obstructions between the cameras and
the receiver.
Night Vision
This camera has built-in IR Cut Filter, which provides the camera with the ability to view images in
no/low light conditions.
Installing the Camera
1. Carefully unpack the camera
NOTE: If you are installing cameras that did not come with the system, please see the pairing
camera section of this manual for details on installation.
2. Mount the camera to the wall
Mark the position of the screw holes on the wall, and drill holes and insert 3 screws, then firmly
attach the camera to the wall. Make sure to strongly secure the screw the mounting bracket into
the wall
NOTE: The camera can also be placed on a flat surface, such as a
Table or Shelf, and no mounting hardware is required.
3. Adjust the viewing angle of the camera
You can adjust camera angle to desired viewing area.
NOTE: You can install additional cameras (maximum of 4 cameras).
When adding cameras that were not included in the original box, you
will need to pair up the cameras with the receiver. Refer to the camera
pairing section of this manual.
