Spinlock Deckvest 150N Manuel utilisateur
WARNING:
WHEN NOT CORRECTLY FITTED, THIS PRODUCT
MAY NOT PERFORM AS A LIFEJACKET OR HARNESS
RISKING SERIOUS DANGER TO THE USER.
For users aged above 16 years and weighing
not less than 50 kg.
Do not use for white water paddling or with
personal watercraft.
Do not use as a cushion.
Gas cylinders are dangerous goods. They
should be kept out of reach of children and
not be misused.
ESSENTIAL INFORMATION: DO NOT REMOVE
UNTIL SOLD.
It is essential you read these instructions before
using your Deckvest.
DECKVEST AUTOMATIC GAS INFLATION
This device is designed to inflate automatically upon immersion. Pulling the manual inflation handle will
also activate the inflation mechanism or it can be inflated by blowing into the oral inflation tube. It can
be converted to non-automatic operation using a Spinlock Deckware Series Manual Conversion Kit.
ISO 12402-3 - 150N Lifejacket
ISO 12402-2 - 275N Lifejacket
ISO 12401 - Deck Harness 50kg+
www.spinlock.co.uk
150N & 275N Automatic Lifejacket with
integral Deck Harness
with Hammar hydrostatic inflation system
approved to CE European & ISO International Standards
Unrestricted working at speed
Soft contoured to fit the body, the clean,
cutaway shape is strikingly comfortable to
wear in all weathers.
Automatic inflation
Hammar® pressure activated firing head is designed
to inflate when submerged. Visual indicator shows the
‘armed’ status of the cylinder and the firing head.
Instantly fitted
The high tensile 2T front fastener provides instant
access.Twin adjuster buckles ensure a snug and
secure fit when tightened.
Includes essential Sprayhood, Thigh
straps, Emergency line cutter, and Water-
activated high intensity flashing Light
1
Product features
Inflated
Ultra-compact personal deck safety wear.
1
3
6
5
2
4
8
7
2
Automatic Lifejacket (150N / 250N) with integral
Deck harness.
Automatic inflation - Latest Hammar® automatic
firing head designed to activate when submerged.
Spray hood, to prevent inhalation of sea water. Easily
accessible and structured to stand free of the face.
Visual indicator shows the ‘armed’ status of the
cylinder and the firing head.
High intensity flashing light - activates upon contact
with water.
Contoured thigh straps - shaped for maximum comfort
to hold the jacket in position.
Safety line attachment loop. High tensile fibre -
lighter, quieter and stronger than steel.
QBZ split zip. Instant access to oral inflator tube.
Ensures rapid inflation and easy repacking.
Emergency safety line cutter. Stowed in snag-free
pouch for instant access.
‘Through Life Support Program’ for registered owners
including extended 5 year guarantee.
Please register within 30 days of purchase at
www.spinlock.co.uk
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
features
3
Fitting and adjusting your Deckvest
AB C D E
A BC D E
A B CD
A B C DE
4
Tightening / loosening belt
Threading adjuster buckles
2x
!
Back of harness
Fitting thigh straps
ABCDE
5
Lifejacket inflation: Hammar®
Oral inflation tube
Firing head
Auto
AB A B
Green Red
Manual
6
Lifejacket repacking See video at www.spinlock.co.uk
1. AB C D
Remove all air.
A BC D
Open zips.
A B C D
Run right hand slider
round to wearer’s
left side.
A B C D
RE-attach zips on right
(firing head) side.
7
2. Concertina bladder onto itself ensuring a smooth flow for the manual lanyard.
3. Concertina bladder top into cover.
Sprayhood
4. Run zip round to close and fasten flap across
breakout point, ensuring firing head is
aligned in the window.
8
Contents
Page no:
Introduction 8
Approval conditions 8
Inflating and deflating your lifejacket 9
Maintaining your Deckvest 10
Instructions for use 11-13
Inspection record sheet 14
Spinlock Deckvest
This Deckvest is an integrated lifejacket and harness approved to ISO 12402-3
(150N) and ISO 142402-2 (275N)
It is important to get into the habit of wearing Deckvest. It is comfortable, safe and
a pleasure to wear.
A lifejacket or harness only works if it is fitted and secured correctly.
Inflatable lifejackets only become buoyant when inflated: they contain no inherently
buoyant materials.
As user, it is your personal responsibility to understand the operation and
maintenance requirements of your inflatable lifejacket and be familiar with its
limitations.
Approval conditions:
This Deckvest is an integrated CE approved lifejacket according to ISO 12402-3
(150N) / ISO 12402-2 (275N) and a CE approved Deck harness according to ISO
12401.
Re-arming a Deckvest
Only approved Spinlock Deckware Hammar re-arming kits should be used. Follow
attached Hammar detailed instructions for re-arming.
9
Inflating your lifejacket
It is recommended that the following inflation procedures are followed:
1. MANUAL INFLATION
To manually inflate the lifejacket, sharply pull the rubber handle downwards.
The CO2 gas cylinder should inflate the bladder within seconds.
2. ORAL INFLATION
To inflate the lifejacket by mouth, locate the oral inflation tube by opening the
zip from the yellow breakout point on the front panel of the lifejacket. Then after
removing the end cap, blow into the tube until the lifejacket is fully inflated.
3. AUTOMATIC INFLATION
Inflation should occur automatically within seconds of the inflator being
submerged 10 cm under water. The automatic capsule is designed to activate the
sprung pin to puncture the CO2 cylinder and inflate the bladder.
CO2 Cylinder size
Model 150N: use 33g
Model 275N: use 60g
INFORMATION: PRESSURE VARIANCE
With variations in air or water temperatures, topping up by oral inflation
may be required to maintain full buoyancy-especially after prolonged
immersion.
Deflating the lifejacket
To deflate the lifejacket, invert the oral-inflation tube end cap and insert it into the
valve. Holding the cap firmly in this position, gently squeeze the lifejacket until all
air or gas has been expelled. Return the cap to its normal position.
Usage below freezing
When the temperature is below freezing, even a fully charged cylinder may not
adequately inflate your lifejacket. Do not use your lifejacket under these conditions
unless it has been partially inflated by mouth.
WARNING: Using the CO2 inflation when your jacket is already fully
inflated can over-pressurise and damage your lifejacket.
