Sper scientific 850097 Manuel utilisateur

Manometer

SD Card Loggers

850097, 850098, 850099

Instruction Manual

Environmental Measurement Instruments

Manometer SD Card Loggers 850097, 850098, 850099

Printed in the USA

The contents of this manual may not be reproduced or

transmitted in any form or by any means electronic,

mechanical, or other means that do not yet exist or may

be developed, including photocopying, recording, or any

information storage and retrieval system without the

expressed permission from Sper Scientic.

TABLE OF CONTENTS

Introduction............................................................................5

Features.................................................................................6

Materials Supplied.................................................................7

Keypad...................................................................................8

Meter Components.................................................................9

Setup Mode..........................................................................10

Measurement Procedures....................................................15

Datalogger............................................................................19

Battery Replacement............................................................22

Troubleshooting....................................................................22

Specications.......................................................................23

Warranty...............................................................................26

INTRODUCTION

Sper Scientic Manometer SD Card Loggers read differential

pressure in air and in non-corrosive and non-ionized gas but

they are not to be used with liquids. They record data with

date and time onto standard SD memory cards (like a digital

camera). When full, simply exchange SD cards for unlimited

data storage. The removable SD card is easy to transport and

insert into your computer’s memory card slot or SD card read-

er. Uploads pre-formatted data to Excel, without the need for

additional software and cables. Additional SD cards are read-

ily available in a variety of memory sizes. The meter comes

fully calibrated from the factory. N.I.S.T. traceable recalibration

is available from Sper Scientic.

FEATURES

• 10 units of measure

• Maximum and Minimum

• Auto power off

• Low battery indicator

• Hold function

• Zero Adjustment

• Backlight

• Touch-tone

• Direct upload of data to Excel

• SD memory card datalogger

• Manual datalogger option

• Internal clock and calendar

• Tripod mounting screw

• Built-in tabletop stand

• Audible overload alarm

MATERIALS SUPPLIED

• Meter

• Tubing and pipe connection lugs

• SD Card

• 6 AA Batteries

• Instruction Manual

• Soft Carrying Case

OPTIONAL ACCESSORIES

840058 USB Power Cable

840097 AC Adapter

840059 Additional SD Card

840093 Field Tripod

840090 Water Resistant Instrument Pouch

METER COMPONENTS

Keypad

1. LCD Display

2. POWER

3. HOLD/ ESC

4. SET/ (TIME

CHECK)

5. LOG/ENTER

6. /UNIT

Side of Meter

8. RESET

9. DC9V Power

Adapter Input Socket

Back of Meter

10. Battery Cover

Screws

11. Tripod Mounting

Screw

12. Tripod Stand

Top of Meter

13. Tubing Inputs

Bottom of Meter

14. SD Card Socket

15. Tubing Couplers

15.

Please Note: Tubing Not Included

10.

11.

12.

13.

14.

SETUP MODE

The advanced Setup Mode allows you to customize the

following meter preferences and defaults:

dATE - Set time & date

SP-T - Sampling time interval

PoFF - Auto Power Off

bEEP - Touch-Tone On/Off

dec - Set SD card decimal type

Sdf - Format SD memory

Note…

The setup functions can be performed under any

parameter, but not while utilizing the datalogger function.

Once selections are saved, the meter will default to the

selected preferences.
