Spektrum Ix20 Manuel utilisateur

Instruction Manual

NOTICE

All instructions, warranties and other collateral documents are subject to change at the sole

discretion of Horizon Hobby,LLC. For up-to-date product literature, visit www.horizonhobby.com

or www.towerhobbies.com and click on the support or resources tab for this product.

MEANING OF SPECIAL LANGUAGE

The following terms are used throughout the product literature to indicate various levels of

potential harm when operating this product:

WARNING: Procedures, which if not properly followed, create the probability of property

damage, collateral damage, and serious injury OR create a high probability of supercial injury.

CAUTION: Procedures, which if not properly followed, create the probability of physical

property damage AND a possibility of serious injury.

NOTICE: Procedures, which if not properly followed, create a possibility of physical property

damage AND a little or no possibility of injury.

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the

product before operating. Failure to operate the product correctly can result in damage to

the product, personal property and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and common sense and

requires some basic mechanical ability. Failure to operate this Product in a safe and responsible

manner could result in injury or damage to the product or other property. This product is not

intended for use by children without direct adult supervision. Do not attempt disassembly, use

with incompatible components or augment product in any way without the approval of Horizon

Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is

essential to read and follow all the instructions and warnings in the manual, prior to assembly,

setup or use, in order to operate correctly and avoid damage or serious injury.

Age Recommendation: Not for children under 14. This is not a toy.

SAFETY PRECAUTIONS

• Always ensure all batteries have been properly

charged prior to using the model.

• Always check all servos and their connections

prior to each run.

• Never operate your model near spectators,

parking areas or any other area that could result

in injury to people or damage of property.

• Never operate your model during adverse

weather conditions. Poor visibility can cause

disorientation and loss of control of your model.

•Never point the transmitter antenna directly

toward the model. The radiation pattern from

the tip of the antenna is inherently low.

•If, at any time during the operation of your

model, you observe any erratic or abnormal

operation, immediately stop operation of your

model until the cause of the problem has

been identied and corrected.

CHARGING WARNINGS

CAUTION: All instructions and warnings must be followed exactly. Mishandling of Li-Po

batteries can result in a re, personal injury and/or property damage.

•NEVER LEAVE CHARGING BATTERIES

UNATTENDED.

•NEVER CHARGE BATTERIES OVERNIGHT.

•By handling, charging or using the included

Li-Po battery, you assume all risks associated

with lithium batteries.

• If at any time the battery begins to balloon or

swell, discontinue use immediately. If charging

or discharging, discontinue and disconnect.

Continuing to use, charge or discharge a battery

that is ballooning or swelling can result in re.

•Always store the battery at room temperature

in a dry area for best results.

• Always transport or temporarily store the

battery in a temperature range of 40–120º F

(5–49° C). Do not store the battery or model

in a car or direct sunlight. If stored in a hot car,

the battery can be damaged or even catch re.

•Always charge batteries away from

ammable materials.

•Always inspect the battery before charging.

• Always disconnect the battery after charging and let

the charger cool between charges.

• Always constantly monitor the temperature of

the battery pack while charging.

• ONLY USE A CHARGER SPECIFICALLY

DESIGNED TO CHARGE LI-PO BATTERIES.

Failure to charge the battery with a compatible

charger may cause a re resulting in personal

injury and/or property damage.

•Never discharge Li-Po cells to below 3V

under load.

•Never cover warning labels with hook and

loop strips.

•Never charge batteries outside recommended

levels.

•Never charge damaged batteries.

• Never attempt to dismantle or alter the charger.

•Never allow minors to charge battery packs.

•Never charge batteries in extremely hot or

cold places (recommended between 40–

120° F [5–49° C]) or place in direct sunlight.

WARNING AGAINST COUNTERFEIT PRODUCTS: If you ever need to replace your

Spektrum receiver found in a Horizon Hobby product, always purchase from Horizon Hobby,

LLC or a Horizon Hobby authorized dealer to ensure authentic high-quality Spektrum product.

Horizon Hobby, LLC disclaims all support and warranty with regards, but not limited to,

compatibility and performance of counterfeit products or products claiming compatibility with

DSM or Spektrum technology.

NOTICE: This product is only intended for use with unmanned, hobby-grade, remote-controlled

vehicles and aircraft. Horizon Hobby disclaims all liability outside of the intended purpose and

will not provide warranty service related thereto.

TABLE OF CONTENTS

How To Use the Manual

Navigating the Pages

Return To Spektrum AirWare App

Using the Table of Contents

Box Contents

Basic Operation

Setting Up A New Model

Transmitter Functions

Spektrum LED

Charging

Physical Transmitter Adjustments

Transmitter Mode Change

Stick Tension

Throttle Strap Adjustment

Control Sticks

Control Stick Length Adjustment

Android Operating System

Android Navigation Icons

Android Home Screen Elements

Notication Screen

Spektrum AirWare Navigation

Volume Control

Telemetry Reset

Model Type Defaults

Acro Defaults

Heli Defaults

Sail Defaults

Multi Defaults

Model Utilities

Select A Different Model

Add A New Model

Sort Model List

Import Models

Export Models

Model Details

Model Name

Model Image

Using the Built In Camera

Monitor Channel Count

Model Category

Expanded Model Details

Reset Model Timer

Duplicate Model

Reset Model

Delete Model

Export Model

Save As Template

Model Note

Binding

Spektrum Failsafe Types

Binding And Programming Failsafe

Testing Failsafe

Auto Switch Select

Active Boxes

Active Box Custom Setup

My List

MODEL ADJUST

Servo Setup

Reverse

Travel

Sub Trim

Speed

Absolute Travel

Balance

On The Fly (OTF) Trim Functions

Dual Rates and Expo

Throttle Cut

Throttle Curve

Adding and Deleting Curve Points

Heli, Sail and Multirotor Throttle Curve

Throttle Hold

Practical Throttle Curve Example

Video Tx

Mixing

Offset

Trim

Combo Mixing

Understanding Mixing

0.5 Mixing Values

Back Mixing

Sailplane Pre-Conﬁgured Mixes

Forward Programming

Sequencer

AS3X®

Differential

V-Tail Differential

Flap System

Pitch Curve

Acro Pitch Curve

Swashplate

Electronic E-Ring

Elevator Compensation

Gyro

Heli Gyro
