Speco VGA19LCD Manuel utilisateur

VGA17LCD

VGA19LCD

17 AND19 TFTLCD VGAMONITORS

USERMANUAL

SpecoTechnologies

200NewHighway

Amityville,NY11701

800-645-5516

www.specotech.com

WARNING:

TOREDUCETHERISK OF FIREORELECTRICSHOCK, DONOTEXPOSETHIS

PRODUCTTORAINORMOISTURE.

DONOT INSERTANYMETALLICOBJECTTHROUGHVENTILATIONGRILLS.

CAUTION:

CAUTION

Explanation ofGraphical Symbols

Thelightningflashwitharrowheadsymbol,withinan equilateral

triangle,isintended toalerttheusertothepresenceofuninsulated

"dangerousvoltage"withintheproduct'senclosurethatmaybeof

sufficientmagnitudetoconstituteariskof electricshocktopersons.

Theexclamation pointwithinan equilateral triangleisintended toalert

theusertothepresenceofimportantoperatingandmaintenance

(servicing)instructionsintheliteratureaccompanyingtheproduct.

Riskof electricshock Donot open

Toreducetheriskof electricshock, donotremovethebackcover.Thereareno

user-serviceablepartsinside.

Removing theback covervoidsthewarranty.

HaveyourLCD repaired byqualified servicepersonnel only.

Warningsandprecautions

lDonotplaceyourhands, face,orobjectsclosetotheventilationopeningsof youLCD.

The top of yourLCD getsveryhot fromexhaustairthat isreleased throughthe

ventilation openings. Burnsorpersonal injuriesmayoccurif you aretoo closetheLCD.

Damagemayoccurif you placeanyobjectnearthetop of yourLCD.

lDisconnectallcablesbeforemovingyouLCD.MovingyouLCDwithitscablesattached

maydamagethecablesandcausefireorelectricshockdanger.

lDonotexposeyouLCD torainormoisture.

lKeep yourLCD awayfromexcessivedust, high temperatures,moisture,ordirect

sunlight.

lUseyourLCDinawell-ventilated area anddonotcovertheventilationopenings.

lDonot modifyyourLCDoruseanunshieldedpowercordorvideo inputsourcecable,or

youmayexperienceexcessiveinterference.

lDisconnectyourLCD andunplug thepowercordwhen theLCDisnot used foralong

period oftime.

lIfthepicturedisplayedisinanywayabnormal,turnoffyourLCD,then disconnectitfrom

theelectrical outlet. Makesurethatyourvideo input sourcecableisconnected correctly,

then reconnect yourLCDtotheelectrical outlet.

lDisconnectyourLCD fromtheelectricaloutletbeforecleaning orperforming

maintenance. Donot useliquidoraerosol cleaners. Useonlyaslightlydampclothfor

cleaning.

lDonotplaceyourLCD onan unstablecart, stand, ortable.YourLCDmayfall,causing

seriousdamage.

Importantsafeguards

Chapter6Safety, Regulatoryand Legal Information

USRegulatorycompliancestatements

YourLCD VGAhasbeentested and found tocomplywiththelimitsforaClass Bdigitaldevices,

pursuant toPart15oftheFCC Rules.Theselimitsaredesignedtoprovidereasonable

protectionagainstharmfulinterferenceinaresidential installation.YourLCDgenerates,uses,

andcan radiateradiofrequencyenergy,andifnotinstalled andused in accordancewiththe

instruction,maycauseharmful interferencetoradiocommunication. However, thereisno

guarantee thatinterferencewithnot occurinaparticularinstallation.If yourLCDdoescause

harmful interferencetoradioortelevision reception,whichcan bedeterminedbyturningyour

LCD off andon, theuserisencouraged totrytocorrect theinterferencebyoneormorethe

followingmeasures:

lReorientorrelocatethereceivingantenna.

lIncreasetheseparation between theequipmentandthereceiver

lConnect theequipment intoan outletonacircuit different fromthat towhichthereceiver

isconnected.

lConsultthedealeroran experienced radio/LCD technician forhelp.

Warning: Useonlyshieldedsignal cablestoconnectI/OdevicestoyourLCD.Youare

cautionedthatchangesormodificationsnotexpresslyapproved bytheparty

responsibleforcompliancecouldvoidyourauthoritytooperatetheLCD.

FCC STATEMENT

ThisLCD complieswithpart15FCCRules. Operation issubjecttothefollowingtwo

conditions(1)Thisdevicemaynot causeharmfulinterference.(2)ThisLCD must

acceptandinterferencereceived, includinginterferencethatmaycauseundesired

operation.

CanadaRegulatorycompliancestatements

ThisLCD doesnotexceed theClass Blimitsforradionoiseemissionsfromdigital apparatusas

set outintheradiointerferenceregulationsofIndustryCanada.

SafetyPrecautions

Warning…………………………………………………………………………………………… 2

ImportantSafeguards…………………………………………………………………………… 3

SafetyPrecautions………………………………………………………………………………..4

TableofContents………………………………………………………………………………… 5

Components………………………………………………….. ………………………………….5

Feature…………………………………………………………………………………………….6

Exploring YourNewMonitor……………………………………………………………………..7

Function KeysInstruction forLCD………………………………………………………….….8

I/OConnection……………………….…………………………………………………………… 9

OSD(OnScreen Display)……………………………………………………………………… 10

ApplicableTiming……………………………………………………………………………….13

Wall mountable…………………………………………………………………..……………... 14

Dimension………………………………………………………………………..……………... 15

Specification……………………………………………………………………..……………...16

Components

(1)LCD ColorMonitor 1

(2)Accessories

(a)Powercord1

(b)UserManual 1

(c)AudioPCline 1

(d)VGACable 1

(e)PowerAdapter 1

Tabl

eofContents

Zoomandshrinkscaling

Integrated 8-bittriple-channel ADC/PLL

Built-ininternal amplifierandspeakers

1280*1024SVGAsupportforcomputerinput(17”/19”)

Supportmultiplelanguageselections

2Dcombfilterand2Dde-interlace

Feature

Youcanoperateyourmonitorbyusingthebuttonson thefront panel.

FrontPanel

BackSide

ExploringYourNewMonitor

15”17”19”

Up: Scrollupthemenubar,hotkeytoadjust channel up

Down:Scroll downthemenu bar,hotkeytoadjust channel down

MENU Menu:ActivateOSDmenu

Right :Increasesettingthemenubar,hot keytoadjustvolumeup

Left : Decreasesettingthemenu bar,hotkeytoadjustvolumedown

SOU/AOU Source: Changeinputsource/Autoadjust

Power:Turnon oroffthemainboard

FunctionKeys InstructionforLCD

1. VGAinput

2. PCAudioinput

3. DC /12Vinput

I/OConnection:

OSD(On Screen Display) menuenablesusertomanipulatetheimageandsettingsOSD

main menuconsistsofsource:

OSDMenuContrast,Brightness,GammaCorrect,ColorAdjust, , ExitofColor,H.Position,V.

Position, Sharpness, Phase, Clock, Exit ofPicture, Language,OSDH. Position,OSDV.

Position, OSDTime,ExitofOSD, Reset,Volume, Exitof Miscellaneous, Exit.

LCD OSDSetting

Color

AutoColor：AutoColoradjustment (OnlyforRD engineermode)

Contrast：Adjustlight and darklevel of theTFT display. Settingvalue from0~100.

Defaultvalueis50.

Brightness：Adjustshadeandbrightness level ofTFT display.Settingvaluefrom0~100.

Defaultvalueis50.

ColorTemp：Thisfunction willadjust colortemperature;moredetailspleaserefertobelow

menu.

Exit：Backtomainmenu.

Colortemperature

OSD(OnScreen Display)
