Speco D4VS Manuel d'instructions
OSD Main Menu
Option Description
• To enter the main menu, right click on the mouse and select setup from the submenu or press
the setup button on the remote control/
• Enter username and password.
The default username is admin
and password is 1111. SEARCH Select this option to enter the Search menu
SETUP Select this option enter the Setup menu
DISPLAY Select between dierent multi-view display formats.
Click this option to create a snapshot of selected channel image.
(BMP STILL IMAGE)
SNAPSHOT
SUPER EZ COPY
AUDIO Select this option to set an audio channel to output;
(Channel 1 through 4, Audio Mute).
CAMERA PTZ Select this option to access the PTZ interface
ENABLE MAIN
MONITOR SEQUENCE
Select this option to enable/disable video sequence function.
DISABLE ALARM OUT Select this option to enable/disable Alarm outputs.
MANUAL
DIGITAL DETERRENT
Displays a window where the user can manually
trigger the Digital Deterrent audio message.
SITE INFORMATION Press the button to view the record setting of a selected channel.
SYSTEM INFORMATION Displays a window with the system information.
EXPORT HELP Displays quick instructions for exporting video.
SYSTEM LOCK Locks the DVR from unauthorized user access..
SYSTEM SHUTDOWN Click this button to shutdown system.
Select this option to enable/disable manual recording. Also known
as Panic Record. Default is set to continuous recording.
ENABLE MANUAL
RECORD
ADVANCED MENU
Select this option to start EZ Setup WizardEZ SETUP
Archive the video clip without getting into the menu.
Playback
EZSearch
• Select EZSEARCH and click NEXT.
and click NEXT.
click NEXT. Thumbnail view of each
hour will be shown.
• Double click on the hour of interest.
Thumbnail view of each 2.5 minutes
within the hour will be shown.
• Double click on the thumbnail to
begin playback.
• Select SEARCH from the sub-menu
Each thumbnail represents an hour of
video. Select a thumbnail to narrow event.
Each thumbnail now represents
2.5 minutes of video.
Time Line
• Select TIME LINE and click NEXT.
Event
• Select EVENT and click NEXT.
• Click on PLAY to begin playback.
• Go into playback mode as described in the previous section.
Export
• Click on BACKUP near the bottom of the playback screen.
Export(BACKUP)
EZCopy
• Click on EZCOPY START near the bottom of the playback screen. This will begin the start
time of the recorded data to be exported.
•The DVR will continue to play the recorded video.
• Move time cursor to go to the time to end backup.
• Click on EZCOPY STOP and this will end the data export.
• Select the FILE FORMAT and click NEXT.
• Select the specific CHANNEL and click start to begin export.
• Select the ARCHIVE MEDIA TYPE and click NEXT.
◦ STILL IMAGE : Snapshots
◦ NSF : Proprietary *.nsf video format
◦ AVI : *.avi video format, Separated Subtitle, MAC compatible
• Select the MEDIA TYPE (USB DRIVE) and click NEXT.
• Select the specific CHANNEL and DURATION and click START to begin export.
Event Export
•To export an event, go into Live mode and go to SEARCH from the sub-menu.
• Select EVENT and click NEXT.
• Select the MEDIA TYPE (USB DRIVE) and click BACKUP to begin export of event.
• Start Internet Explorer and enter the IP address and port of the DVR.
◦ For example http://[ip address] : [port] → http://192.168.80.6:80
•The ActiveX controls and plug-ins dialog will be prompted for installation.
• Install the plug-ins.
• Click on CONNECT and enter the IP, port number, username and password of the DVR.
◦The default usernames and passwords are admin / 1111 and user1 / 1111.
• Click on SEARCH to go into PLAYBACK.
Export via Web-Browser Viewer
iPhone®
• Click on EZCOPY START near the bottom of the playback screen. This will indicate the
start time of the recorded data to be exported.
•The DVR will continue to play the recorded video.
• Move time bar cursor to go to the time to end backup.
• Click on EZCOPY END and this will indicate the end time of the data export.
• Select AVI BACKUP button.
• Select the CHANNEL and FILE PATH and click OK to begin export.
Viewing DVR via Mobile Devices
The DxVS provides mobile surveillance software for both the iPhone® and the Android™
• Search for ‘Speco Player’ in the Apple App Store and install the app.
• Select the ADD menu and enter site information. Click ADD to save the site information.
• Select the saved site from “Devices”
• Select Playback/Live then click Connect
Android™
SpecoTech Multi-Client Viewer
The SpecoTech Multi-Client Viewer Software and manual are included on the CD.
• Select the ADD menu and enter site information. Click ADD to save the site information
• Select the saved site from “Devices” and select LIVE VIEW or PLAYBACK
• Select 4 channels to view and click “Start” button
SpecoTech Multi-Client Viewer Software is a multiple site
monitoring client software that allows streaming of video and
audio, and transmission of alarm signals from the DVRs over the
network.
The SpecoTech Multi-Client can display up to 16 DVRs and
supports dual monitors. PTZ Camera control is also supported
by this software By attaching a microphone and speaker system
to devices on site, the user may make bi-directional audio
communication over the network
Refer to the complete manual for more information
• Search for ‘Speco Player’ in the Android Play Store and install the App.
