Spar F300i Manuel utilisateur
GB
ECE R44/04
GROUP 0+
ISOFIX for Group 0+ Sparco F300i
INSTRUCTION MANUAL
0-13
kgs
Know Your Child Seat
6
1
2
34
5
6
7
8
9
10 11
13
12
1. Headrest
2. Shoulder pad
3. Shoulder strap
4. Harness buckle
5. Harness release button
6. Harness strap
7. Handle
8. Lap belt guide
9. Seat shell
10. Handle adjustor
11. Harness yoke
12. Headrest adjuster
13. Diagonal belt guide
*ECE = European Standard for Safety Equipment
The child safety seat has been designed, tested and
certified according to the requirements of the
European Standard for Child Safety Equipment (ECE
R44/04).
The seal of approval E (in a circle) and the approval
number are located on the approval label (sticker on
the child safety seat).
This approval will be invalidated if you make any
modifications to the child safety seat. Only the
manufacturer is permitted to make modifications to
the child safety seat.
Suitability GB
7
...as a child safety seat installed in a vehicle.
EU Standard ECE R44 04
Group Weight Age Orientation Fixing of child
Group
0+
Backward
facing
Child seat belt
(5 points)
0-18
months
0-13kg
Use in The Vehicle
8
DO NOT use on a
passenger seat with a
front airbag!
DO NOT use with
2-point belt. With the
vehicle's 3-point
seatbelt.
Danger! An airbag hitting the infant carrier can cause
serious injuries to your child, possibly resulting in death.
Please observe the instructions in your vehicle manual for
the use of child seats.
Please observe the regulations applicable to your
particular country.
Do not use with 2-point belt.
The safety belt must be approved to ECE R 16 or a
comparable standard.
Do not use on passenger seats with a front airbag!
Can be used if the vehicle seat is equipped with a 3-point
belt.
With the vehicle's 3-point seatbelt
You can use your child car seat as follows:
GB
9
In the direction of travel NO
Against the direction of travel YES
With 2-point belt NO 1
With 3-point belt YES 2
On front passenger seat YES 3
On outer rear seat YES
On centre rear seat NO 4
(Please observe the regulations applicable to your
particular country).
1. The use of a 2-point belt substantially increases the
risk of injury to your child in the event of an accident.
2. The safety belt must be approved to ECE R 16 or a
comparable standard (see test label on belt with an "E"
or "e" in a circle).
3. Do not use on passenger seats with a front airbag!
4. Can be used if the vehicle seat is equipped with a
3-point belt.
1. Securing your baby using the baby insert
Securing Your Baby
For the protection of your baby.
The baby insert gives your baby the
necessary support while he or she
is still small.
The baby insert is used to provide
extra comfort for very small babies.
Caution! Please use the baby insert
attached to this infant carrier when
your baby's weight is less than 9kg.
Always secure your baby in the infant carrier using
the harness.
Never leave your baby unattended in the infant
carrier when placing it on elevated surfaces {e.g. a
table, nappy changing unit, etc.).
Never allow the strap end to become caught in
moving parts (e.g. automatic doors, escalators, etc.).
Caution! The plastic parts of the infant carrier heat up
in the sun, so that your baby may get burnt. Protect
your baby and the infant carrier against intensive
solar radiation (e.g. by putting a light cloth over the
seat).
The infant carrier requires only one seating position
in the car. This advantage means, however, that your
baby must be in a semi-reclined position.
Take your baby out of the infant carrier as often as
possible to relieve its spine. We recommend frequent
breaks during long journeys. Even outside of the car,
please avoid leaving your baby in the infant carrier
for too long.
10
2. Adjusting The Handle
You can engage the adjustor in three positions:
Simultaneously press both buttons on the handle.
Then whilst holding the adjustor pressed turn the
handle backwards until it engages in the desired
position.
A: For carrying and for transport in the car.
Caution! Ensure that the handle is securely engaged
before you pick up the infant carrier.
B: For placing your baby into the infant carrier.
Tip! You can swivel the handle from position to position
without pressing the buttons.
C: For setting the infant carrier down safety outside the
car.
GB
11
A correctly adjusted headrest ensures your baby’s
optimal posture in the infant carrier.
The headrest must be adjusted so that the shoulder
straps are at the same level as your baby's shoulders
or slightly above.
To adjust the height of the headrest to fit your baby:
Tilt the headrest adjuster until it disengages.
Slide the headrest adjuster until the shoulder straps
are at the correct height and re-engage.
Press the harness release
button and at the same time
pull both shoulder straps
forward.
3. Adjusting the headrest
4. Loosening the shoulder straps
12
5. Securing your baby using the harness
Loosening the shoulder straps.
Open the harness buckle (press the red release
button).
Place your baby into the infant carrier.
Put the shoulder straps over the shoulders of your
baby, then put the buckle tongues together and
engage in the harness buckle with an audible "click".
Caution! Do not twist or interchange the shoulder
straps.
GB
13
For the safety of your baby, please check that...
6. Tightening the harness
7. Checklist to ensure that your baby is buckle up correctly.
Pull the strap end
Caution! Pull the strap end
straight towards you, not
upwards or downwards.
Please pay attention to the
strap end.
Whilst traveling (especially
outside the car) it should
always be attached to the
cover.
The shoulder straps of the
infant carrier are comfort-
able but FIRM fit around
your child.
The shoulder straps are
adjusted correctly.
The shoulder straps are not
twisted.
The buckle tongues are
engaged in the harness
buckle.
14
