Space Scooter X580 Manuel utilisateur
Owner’s Manual
Model: X580
EN14619 Class A / ASTM F2264
Space Scooter Step by Step Manual
If you need additional assistance, please contact us by e-mail
WARNING: Adult assembling required.
Page 2
Index
Safety warnings....................................................................................... 3
Space Scooter 101®................................................................................. 6
Setup and unfolding................................................................................ 7
How to Unfold..................................................................................... 7
How to Fold®..................................................................................... 10
Folding for storage............................................................................ 10
How to ride ........................................................................................... 12
Ride as a traditional kick scooter ...................................................... 12
Ride as a Space Scooter®................................................................... 12
Check and adjust................................................................................... 14
Check collar clamp ............................................................................ 14
Check wheels and bearings............................................................... 14
Check quick release........................................................................... 14
Maintenance ......................................................................................... 16
Check flywheel and add ballbearingoil ............................................. 16
Space Scooter®F.A.Q. (frequently asked questions) ............................ 17
Issues with folding or unfolding........................................................ 17
The grip of the tray plank diminishes. .............................................. 17
The chain skips or runs next to the gears(flywheel)......................... 17
Noises, Sounds, etc.. ......................................................................... 17
Warranty ............................................................................................... 19
Copyright............................................................................................... 21
Produced by: ......................................................................................... 21
Page 3
Safety warnings
AN IMPORTANT MESSAGE TO PARENTS:
This manual contains important information. For your child’s safety,
it is your responsibility to review this information with your child
and make sure that your child understands all warnings, cautions,
instructions and safety topics. We recommend that you
periodically review and reinforce the information in this manual
with your child and properly maintain your child’s scooter to insure
their safety.
GENERAL WARNING:
LIKE ANY OTHER MOVING PRODUCT, USING A SCOOTER CAN BE A
DANGEROUS ACTIVITY AND MAY RESULT IN INJURY EVEN WHEN
USED WITH PROPER SAFETY PRECAUTIONS. USE AT YOUR OWN
RISK AND USE COMMON SENSE.
WARNING: DO NOT USE PARTS MANUFACTURED BY ANOTHER
COMPANY WITH YOUR SPACE SCOOTER®. Do not modify the
structure or parts of the scooter, which may cause risk of failure.
WARNING:
The air spring of the shock absorber is filled with high-pressure air.
Do not disassemble or destroy it, and never throw it into a fire as
that may cause the air spring to explode.
Page 4
Always wear a helmet when riding your scooter and keep
the chain strap securely buckled.
Always wear shoes.
Ride on smooth, paved surfaces away from motor vehicles.
Avoid sharp bumps, drainage grates, and sudden surface
changes.
Avoid streets and surfaces with water, sand, gravel, dirt,
leaves, and other debris. Wet weather impairs traction,
braking, and visibility.
Do not ride at night.
Brake may get hot from continuous use.
Be cautious of traveling downhill, as this may cause the
Space Scooter to go very fast.
Adults must assist children in the initial adjustment
procedures, which include unfolding the scooter, adjusting
the handlebars, steering to height, and folding the scooter
for storage.
Obey all local traffic, bike and scooter laws and regulations.
Watch out for pedestrians.
Do not exceed the 200Lbs (90Kg)weight limit on the scooter.
Do not allow children under age of eight (8) to use the
scooter. Children under age fourteen (14) should ride with
adult supervision at all times.
Although the child may meet the weight requirment to ride
the Space Scooter, a parent’s decision to allow his or her
child to ride this product should be based on the child’s
maturity, skill level and ability.
Always pay attention to surroundings to avoid sudden
braking and sudden turning which may cause the user fall
down, this may hurt the user or other people.
Always ensure that your child is wearing proper protective
equipment such as an approved safety helmet.
Page 5
A helmet may be legally required by local law or regulation in
your area. Your child should always wear shoes, never ride with
bare foot or in sandals, and keep shoelaces tied and out of the
way of the wheels.
ALWAYS USE COMMON SENSE, READ THE WARNING
INSTRUCTIONS TO DECREASE RISKS AND SERIOUS INJURY. USE
AT YOUR OWN RISK AND WITH APPROPRIATE AND SERIOUS
ATTENTION TO SAFE OPERATION. USE CAUTION.
WARNING: ALWAYS INSPECT SCOOTER PRIOR TO RIDING.
Properly inspecting and maintaining your Space Scooter® can
reduce the risk of injury. Always inspect your Space Scooter®
before riding and regularly maintain it.
WARNING: CHECK LOCAL LAWS REGARDING SCOOTER USE.
Check local laws and regulations regarding laws governing
helmet use and scooter operation in your area.
WARNING: THE SPACE SCOOTER® CANNOT DRIVE BACKWARDS
DUE TO ITS ANTI-ROLL BACK SYSTEM.
Page 6
Know your Space Scooter®
Remove your Space Scooter from the box and inspect it for any dents,
chips, etc. before use.
Kicking
Riding
Folding
WARNING: DO NOT USE PARTS MANUFACTURED BY ANOTHER COMPANY. Your Space
Scooter® has been built to certain design specifcations. The original equipment supplied
at the time of sale was selected on the basis of its compatibility with the frame, fork and
all other parts. Certain aftermarket products may or may not be compatible.
Folder
C:Kicking
A:Folding
B:Riding
handlebar grip
handlebar
upper steering tube
steering tube
quick-release
frames folding trigger
lower steering tube
handlebar quick
release
brake handle
deck
rear wheel
kickstand
folder
steering tube clamp
front wheel
head tube
Page 7
Setup and unfolding
Tightening the brake handle.
Note: The brake handle has not been tightened before the product
was packed in the factory; the user should tighten the brake handle
screw before using the scooter. Adjust brake handle to a suitable
position and tighten it with the allen wrench.
Unfolding
1. Release the folding mechanism by opening the quick release clamp
on the right side of folding mechanism.
2. Push "Folding" unlock button (A) on the folding mechanism to
unlock and pull the vertical pole upwards until you hear a click.
Turn the steering pole slightly to confirm spring-load lock pin is
locked into the correct position.
3. Tightening the quick-release clamp at the right side of the folder to
lock the mechanism.
Page 8
4. Open the quick-release clamp at top end of T-tube.
5. Insert and secure left and right handlebars by pressing the spring-
loaded buttons and inserting them into T-tube. Make certain BOTH
handlebars are properly locked into the T-bar by spring-loaded
buttons.
6. Close quick-release clamp to lock the handlebar. If needed, adjust
the nut at the lower end of the clamp to ensure a tighter fit.
7. To adjust the height of the handlebars: open the quick-release
clamp on the steering pole..
8. Press the spring-load button and raise or lower the T-bar to desired
position, and make sure that the spring-load button is locked into
the hole of the tube.
9. Re-secure the quick release clamp to lock it into place. If needed,
adjust the nut at the left end of the clamp to ensure a tighter fit.
WARNING: Failure to properly secure the quick-release lever may
cause the T-tube to telescope up or down while riding, which may
cause you to lose control and fall.
Page 9
10. To unfold the deck, stop the front wheel by placing a foot on it.
11. Hold the steering pole with one hand and pull the folding lever
with the other hand. At the same time, pull the steering pole
slightly forward untill the rear wheel is lifted from the ground. The
deck will unfold slowly. Let the deck raise completely and let go of
the folding lever. The deck will be locked at this position.
If the deck does not unfold normally, the user can pull the front end
of the deck to help unfold it.
Page 10
Convert your Space Scooter®into a traditional kick
scooter.
1. Fold the deck:
(Make sure the deck is either horizontal or tilted up at the front.)
Hold the steering pole with one hand and then pull the folding
lever up with the other hand. At the same time, push down on the
deck with a foot in order to lower the deck. This might need some
weight.
2. Adjust the steering pole position: To adjust the steering pole to
"kick-scooter" mode, push the "Riding" unlock button (B) on the
folding mechanism to unlock the head tube and raise the steering
tube up more until it securely locked into "kick scooter" position.
Folding for storage
3. Folding the deck:
(Make sure the deck is either horizontal or tilted up at the front.)
Hold the steering pole with one hand, then pull the folding lever up
with the other hand. At the same time, push down on the deck
with a foot in order to lower the deck. This might need some
weight.
1. Folding the steering pole: Open the quick-release clamp for the
steering pole, then push the spring-loaded button on the side of
the steering pole and push down on the upper part of the steering
pole. The spring-loaded button will lock into place at the hole at
Table des matières
