Option: If project requires Pedestal Base Pad, place Pad on the membrane
before moving to the next step. This pad will rest just underneath the pedestal.
If project requires Slope Corrector (refer to Step 1, see X),
attach Slope Corrector to the Pedestal before moving to
the next step. Use this process:
Rotate the Slope Corrector to the desired Slope % using
the triangle indicator, then firmly press Slope Corrector
onto Pedestal Top. At this time, make a note of the words
“UP SLOPE” and arrow on top of the slope corrector. When
correctly installed, this arrow will be pointed in the direction
that is up slope on this part of the roof.
Note: On some models, the triange indicator is yellow, while
on others it is red. These color differences have no impact
on function or proper use.
Provides mounting bracket for wooden joist system, upon which
deckboards can be installed
Provides mounting hardware for wooden deck tiles, upon which most
wooden deck tiles can be installed
