A. Running belt tightening adjustment If the running belt is too loose, please insert the supplied hex
wrench into the adjusting hole of the left footstep of the treadmill, turn it 1/4 turn clockwise, and then
adjust the right foot to rotate clockwise. 1/4 laps, note that the left and right must be adjusted
synchronously, so that the running belt can be tightened and the running belt will not deviate from the
center point. If the running belt is too tight, the left and right synchronization will be adjusted
counterclockwise.
Note: The running belt cannot be adjusted too tightly. This will break the running belt, increase the
pressure of the front/rear drum, cause damage to the roller bearing, etc., produce abnormal noise or
other problems, and only need to adjust to the running belt without slipping.
B. Running belt alignment adjustment
When you use the treadmill, the pressure on the two belts is not the same when running, and the
pressure on the running belt is unbalanced, causing the running belt to deviate from the center. This
deviation is normal and it automatically returns to the center when no one is running on the running belt.
If you don't get back to the center, you need to run back to the center.
Run the treadmill at no load, adjust the speed to the sixth gear, and observe the distance from the
running belt to the left and right side bars:
●If it is to the left, use a hex wrench to turn the left screw 1/4 turn clockwise;
●If it is biased to the right, use a hex wrench to turn the right screw 1/4 turn clockwise;
●If the running belt is still not in the middle, repeat the above action until it is adjusted to the middle.
After adjusting the running belt to the middle, adjust the speed to the sixth gear, and observe the
deviation of the running belt and the smooth running condition. If there is any deviation, repeat the
adjustment step.
Caveat! Do not overtighten the rollers! This will result in permanent damage to the bearing!
8. lubricating oil
The treadmill is lubricated at the factory, but the treadmill's lubricity is often checked to help keep the
treadmill in optimal use. The treadmill must be lubricated after one year of use or 100 hours of operation.
After 30 hours or 30 days of use, when the treadmill is at rest, pull up the running belt from the side
and reach the surface of the running platform as far as possible. If you feel the lubricant, you do not need
to add lubricating oil; if you touch the surface There is a strong feeling of dryness, please follow the
instructions below to refuel. (Please use non-oil-based lubricants)
How to add lubricant?
please operate as shown below, open the sidebar left.For the fueling decorative cover on the front
side, use a pair of scissors or a utility knife to cut the oil bottle according to the size of the figure, and then
add the oil according to the bottom icon. When filling, please pay attention to insert the thin rod at the
front end of the oil bottle into the fuel filler pipe on the platform. Go in.
