Page 1 of 11B-SRM12-013-0.FM Broadcast Products Technical Bulletin 20-2012-070

Portable Memory Recorder

DATE: July 16, 2012

DESCRIPTION

Software version 1.50 is available.

NOTE: Software cannot be downgraded.

ORDERING INFORMATION

To order upgrades, contact:

Sony SoftwarePLUS®

(800) 538-7550

www.sony.com/softwareplus

NOTE: The software is available by download only from the

SoftwarePLUS website above.

NEW FUNCTIONS

NOTE: For more detailed descriptions of the new functions, refer

to the SR-R1 Operation Manual, 1st Edition (Revised 3).

FPS Formats Supported

When connected to PMW-F3, the following FPS formats are

supported:

422 SQ/Lite S29PsF(23/29PsF)

422 SQ/Lite S59P(23/29PsF)

444 SQ S29PsF(23/29PsF)

422 SQ/Lite S25PsF(25PsF)

422 SQ/Lite S50P(25PsF)

444 SQ S25PsF(25PsF)

NOTE: PMW-F3 does not support 24PsF.

NOTE: Refer to the SR-R1 Operation Manual, 1st Edition

(Revised 3), Appendix > Connection to the PMW-F3 > Select

FPS Recording (as reproduced on pages 2 and 3 of this bulletin).

PARTS REQUIRED

Part No. Description Qty.

FSRR1V150 SR-R1 Software V1.50 1

Broadcast Products

Technical Bulletin 20-2012-070

SUBJECT: SOFTWARE UPGRADE—VERSION 1.50

SRM12-013

MODEL: SR-R1

SERIAL NO:

SR-R1 10,001–10,145

Page 2 of 11B-SRM12-013-0.FM Broadcast Products Technical Bulletin 20-2012-070

Page 3 of 11B-SRM12-013-0.FM Broadcast Products Technical Bulletin 20-2012-070

Page 4 of 11B-SRM12-013-0.FM Broadcast Products Technical Bulletin 20-2012-070

Monitor LUT Conversion Function

The monitor LUT conversion function (supports S-Log) is added.

VIDEO menu > LUT

This function converts color reproduction of signals set with

gamma (such as S-Log) from cameras (such as PMW-F3) to

optimize color reproduction on the monitor. The LUT file must be

obtained separately for each camera.

NOTE: When LUT is set, color reproduction is applied to both HD

SDI OUT (MON) 1 and 2 outputs.

SRExpress Mode

SRExpress mode is added.

SYSTEM menu > INGEST > SRExpress

High-speed file transferring is enabled by connecting with IoXT

or KONA 3G from AJA Video Systems.

SDI INGEST Mode

SDI INGEST mode is added.

SYSTEM menu > INGEST > SDI INGEST

This function is provided to connect NLE equipment to REMOTE

terminal (RS-422) and to transfer files in normal playback speed.

NOTE: Only files that are in the same format as the system

format setting are applicable for playback. In addition, SELECT

becomes enabled in the menu and applicable files can be

flagged for refining.

RS-422 Control

RS-422 control is supported.

SYSTEM menu > REMOTE/LOCAL > REMOTE

Remote mode of RM-280 is supported. When the unit is set to

REMOTE, the key setting on the control panel follows the KEY

MAP setting.

NOTE: Even if the menu setting is LOCAL, the REMOTE

connector is active. If RM-280 is not used for controlling SR-R1,

disconnect RM-280 or turn RM-280 power OFF.

Control Against File Name Duplication

When File Name is set to Camera, two randomly-generated

characters are added to the suffix of the file name. For example:

A001C001_120404XY (where XY are the added characters).

This function reduces duplication of file names on the PC after

files are ingested.

Page 5 of 11B-SRM12-013-0.FM Broadcast Products Technical Bulletin 20-2012-070

3G-SDI Input/Output

3G-SDI input/output is supported.

SYSTEM menu > SYSTEM FORMAT > SDI IN/SDI OUT

Continuous Playback

Continuous playback is supported.

SYSTEM menu > PB FUNCTION > PB CONTINUE > LIST

Continuous playback can be performed in order of the FILE LIST

definition.

REC PAUSE Function

The REC PAUSE function is supported.

REC PAUSE and REC RESTART can be operated by pressing only

the pause key. The file is closed at REC PAUSE, and a new file is

created and opened at REC START.

Mark Function

The Mark function is supported. Button operations are as follows:

Press Operation

FUNC+REC Sets mark point. Up to three mark points

can be set in one file. The mark points are

deleted with EJECT or power OFF

functions. (The mark points are not

recorded on the card.)

FUNC+PAUSE Mark point last entered is opened.

FF (Next) Start TC of next file or next mark point is

opened.

REW (Prev) Start TC of previous file or previous mark

point is opened.

FUNC+Enter (Enter dial on File List screen) The list of

mark points appears on the right of the

screen.

Cue Up with Timecode Input

Cue up is supported with timecode input.

While the file is opened, input numeric data of the timecode in

SYSTEM menu > PB FUNCTION > IN POINT, and press

FUNC+PAUSE to cue up to the IN POINT.

NOTE: Because searching depends on comparison with the

current timecode value and target value, cue up may not be

executed correctly in some cases.

Synchronized Recording with PMW-F3

Synchronized recording with PMW-F3 is supported.

SYSTEM menu > OTHERS > REC TRIGGER > SYNCHRO REC

Parallel or synchronized recording is supported with SRMemory

cards and SxS memory cards installed to PMW-F3 (DURATION,

TC, FILENAME, S&Q/SR Motion, and Metadata RDD-18).

Page 6 of 11B-SRM12-013-0.FM Broadcast Products Technical Bulletin 20-2012-070

Off-Speed Playback

Off-speed playback is supported.

Video can be replayed in a different system frequency from the

frame frequency originally recorded. The audio signal is replayed

with simplified interpolation. (Audio may be distorted.)

PROGRAM IMPROVEMENT

Image, audio, timecode, and other indications are improved at

start-up and during mode transitions.

UPGRADE PROCEDURE

System Requirements

•PC running Windows and with Memory Stick slot

•SRMemory card (for recording)

•Memory Stick PRO (confirmed for operation up to 8 GB)

•AC adapter (AC-DN2B/DN10 or equivalent with AC, DC

cable)

•Battery, charged (BP-GL95 or equivalent for power backup)

Prepare Software Files

1. Download the zip file from the SoftwarePLUS website:

SR-R1_V1_50_SRM12-013_120531.zip

2. Extract the zip file on the PC.

The following folder and files are created:

/MSSONY/PRO/SRMASTER/SR-R1/

CPSR.F1.50.0104.bin (Control panel)

DMSRSYS.F1.50.0162.lzh (DM SYS)

DMR1FPGA10.F1.50.A04F.lzh (DM FPGA1)

DMSRPROC.F1.30.0000.lzh (DM PROC)

3. Remove former version upgrade files from the memory stick.

NOTE: If former version files remain on the memory stick,

the recorder will be downgraded.

4. Copy the MSSONY folder to the root directory of the memory

stick.

NOTE: DO NOT extract the lzh files on the PC in advance

because the files are automatically extracted to the unit after

being transferred.

Page 7 of 11B-SRM12-013-0.FM Broadcast Products Technical Bulletin 20-2012-070

Update Software

NOTE:

•DO NOT turn OFF power during the upgrade.

•If using an AC adaptor on which a battery can be attached

(such as AC-DN2B or AC-DN10), attach a charged battery as

a power backup in case of an inadvertent power shutdown.

Confirm that the power supply will automatically switch to

the battery when the AC cable is disconnected prior to the

upgrade.

•Make sure no former version files or other unnecessary files

are on the memory stick.

•DO NOT replace any files obtained by extracting the zip file.

•Eject any SRMemory cards inserted in the recorder.

•A warning (such as “Unlock”) displayed during the upgrade is

not an error.

•Before upgrading SR-R1, upgrade any equipment that will be

connected to SR-R1.

1. Connect the AC adapter securely to the DC IN connector of

SR-R1, and mount a battery to the AC adapter if possible.

SYSTEM menu > BATTERY > BATT TYPE

NOTE: Confirm that the AC adapter is connected securely

because the installation takes approximately 30 minutes.

2. Confirm the current versions as follows:

a. Turn SR-R1 power ON.

b. On the control panel, press HOME + SYSTEM to open the

DIAGNOSIS menu.

c. Select SOFT VERSION, and press FUNC + ENTER.

(See Figure 1.)

Figure 1

Page 8 of 11B-SRM12-013-0.FM Broadcast Products Technical Bulletin 20-2012-070

NOTE: The latest versions are listed in Table 1. Versions new for

the V1.50 upgrade are in red.

3. Press HOME + SYSTEM to open the DIAGNOSIS menu, select

VERSION UP, and press ENTER. (See Figure 2.)

Figure 2

4. Select ALL, and press FUNC + ENTER. (See Figure 3.)

NOTE:

• When executing ALL, the file with the newer version is

selected automatically if there are different version files

for each ROM.

• When upgrading ROMs individually, select the ROM to

upgrade from the VERSION UP menu.

Table 1

ROM Latest Version

CP V1.00 (F1.50.0104)

DM(SY) V1.01 (F1.50.0162)

DM(FPGA1) V1.01 (F1.50.A04F)

DM(PLD) V1.00 (01.00.0000)

DM(PROC) V1.01 (F1.30.0000)

Page 9 of 11B-SRM12-013-0.FM Broadcast Products Technical Bulletin 20-2012-070

Figure 3

5. The All SOFT/FPGA screen appears. (See Figure 4.)

Confirm that the current versions and the versions on the

memory stick are correct.

Select OK, and press FUNC + ENTER to execute the upgrade.

Figure 4

Page 10 of 11B-SRM12-013-0.FM Broadcast Products Technical Bulletin 20-2012-070

6. When the upgrade is completed, confirm that “Completed”

appears in the lower left of the screen. (See Figure 5.)

Figure 5

7. Turn power OFF and ON to restart the unit.

Confirm Version

Confirm that software is upgraded correctly as follows.

1. Press HOME + SYSTEM to open the DIAGNOSIS menu.

2. Select SOFT VERSION, and press FUNC + ENTER.

(See Figure 6.)

Figure 6
