Sony MSW-2000P SERIES Guide d'installation

this is not a rehearsal.

www.pro.sony-europe.com

Enabling

the present,

protecting the past.

The ew MSW-2000P Series Studio Recorders.

MSW-2000P Series

Studio Editing Recorders

In the digitally based broadcast industry of today and tomorrow,

only the fittest enterprises will grow and prosper. In short, those that

deliver the quality, flexibility, choice and value - that an ever more

demanding audience requires.

Whatever your medium, from satellite or terrestrial to cable; and

whether you operate locally, nationally or internationally, networked

systems based upon open MPEG-2 compression, can deliver what’s

required at every step of the programme production chain.

Hence the rapid increase in the popularity of MPEG-2 based

systems. The advantages of this technology are felt at every stage

of the process. Not only is MPEG-2 the worldwide standard for

digital programme delivery via DTV, DVB and DVD, it is also widely

used for the contribution and distribution of material between studio

centres.

In addition, MPEG-2 4:2:2P@ML is also a firm favourite for

programme production. Thus the number of linear and non-linear

options based upon this system continues to increase dramatically.

MPEG-2 brings a number of pivotal benefits to your organisation.

These range from its versatility - optimising quality and cost for each

programme application; interoperability - bringing you an extensive

choice of equipment from multiple suppliers and the reassurance of

a future-proof investment.

Today as broadcasters begin to reap the full advantages of

MPEG-2 technology, they are demanding the resources to produce

programmes of the very highest quality using recording systems that

are also based upon open compression and interfacing standards.

In anticipation of this requirement, Sony has introduced a new

family of MPEG IMX™ Studio Editing Recorders based upon

MPEG-2 4:2:2P@ML data compression at 50Mb/s intra-frame -

the MSW-2000P Series.

Developed from Sony’s unique experience of, and world

renowned reputation for, 1/2“ recorders : Betacam, Betacam SP,

Digital Betacam and Betacam SX, the MSW-2000P Series ensures

compatibility with all Betacam-based tape libraries and facilities.

So not only is this exciting new range the ideal tool for migrating to

an open MPEG-2 environment - quickly, simply and cost effectively;

it is perfect for protecting your investment in current 1/2” resources.

Exploit the full business

MPEG env

MSW-2000P Series

benefits of an end-to-end

vironment with

MPEG IMXTM

Studio Editing Recorders.

DNW-7P/9WSP/90P/90WSP

Betacam SX Camcorders

DNW-A225P/A220P/A25P

Betacam SX Digital Portable Editors

DNW-A28P

Betacam SX Digital Portable Recorder

DVW-250P

Digital Betacam Portable VTR

DVW-707P/709WSP/790WSP

Digital Betacam Camcorders

BVW-D600P/400AP/300AP

Betacam SP Camcorders

DVCAM Camcorders

Enter the Open World of MPEG-2 with MPEG IMX™ Recorders

MSW-2000P Series MPEG IMX™Studio Recorders are more than just ideal tools on wh

to base your open MPEG-2 infrastructure. They also play a vital role in migrating your

existing operations to MPEG-2.

DSR-2000P + Op

MPEG 50Mb/s o

•DVCAM Playback

•DV Playback

•DV LP Playback

•DVCPRO Playback

DNW-A75P/75P/

MPEG 50Mb/s o

•Betacam SX Playba

•Betacam SP Playba

•Betacam Playback

hich

MSW-2000P

MPEG 50 Mb/s over SDTI-CP I/O

•MPEG IMX Recording and Playback

•Betacam SX Playback

MSW-M2000P

MPEG 50 Mb/s over SDTI-CP I/O

•MPEG IMX Recording and Playback

•Digital Betacam Playback

•Betacam SX Playback

•Betacam SP Playback

•Betacam Playback

MSW-A2000P

MPEG 50 Mb/s over SDTI-CP I/O

•MPEG IMX Recording and Playback

•Betacam SX Playback

•Betacam SP Playback

•Betacam Playback

tional DSBK-210 SDTI-CP Output Board

ver SDTI-CP output for following:

A65P/65P Series + BKNW-124 SDTI-CP Output Board

ver SDTI-CP output for following:

ack

ack (A75P/A65P)

(A75P/A65P)

MAV-2000

Multi Access Video and Audio

Other manufacturers se

with SDTI-CP I/O

MAV-555

Multi Access Video Disk R

o Server

ervers

ecorder

MAV-70XGI

Transmission Server

BDX-N1000

Network Interface Unit

BDX-2300

BDX Interface Unit

Other manufacturers NLE or

servers with SDTI-CP I/O

MSW-2000P Series

MPEG IMX Studio Editing Recorders

DNE-2000

Nonlinear Editor

MPEG Transcoder

The MSW-2000P Series employs 8-bit 4:2:2 component

video sampling and MPEG-2 4:2:2P@ML data compression

at 50Mb/s, I-frame. This provides very high picture quality

and excellent multi-generation performance.

MSW-2000P Series recorders can input and output an

MPEG-2 Elementary Stream via SDTI-CP (SMPTE 326M),

enabling the transfer of data to other MPEG devices, such

as non-linear editors and servers.

The Series features a compact 4U-size design -

174 x 427 x 550 (H x W x D) - and weighs only 22kg.

MSW-2000P Series recorders offer two major innovations in

front-panel design, while retaining the familiar operational

controls of recorders such as Betacam SP, Betacam SX and

Digital Betacam. A clear multi-function display provides

comprehensive information, allowing quick access and easy

control of a variety of functions. Additionally, dedicated

controls are included for each of the eight, independently

editable audio channels.

MSW-2000P Series recorders provide eight, independently

editable, 16-bit 48kHz channels as standard. They can also

be switched to provide four channels of 24-bit 48kHz

digital audio.

MSW-2000P Series recorders provide long recording and

playback times.

•220 (625)/184 (525) minutes - L cassette

•71 (625)/60 (525) minutes - S cassette

MSW-2000P Series recorders offer 625/525 switchable

operation for all playback-compatible 1/2-inch formats.

*For playback of 525 line Betacam SP tape in 625 machines and vice

versa, the analogue composite outputs are for monitoring purposes only.

•Analogue composite I/O

MPEG-2 50Mb/s, I-frame compression

Long recording and playback times

525/60, 625/50 switchable operation

MPEG-2 bit stream over SDTI-CP

Compact design

Elegant front panel design

High-quality digital audio

Main features of the MSW-2000P Series

MPEG IMXTM Recorders

MPEG IMX™ Format

General

Tape width

Tape material

Recording/Playback time

Tape speed

Track pitch

Tracks per frame

Longitudinal tracks

Playback compatibility

MSW-M2000P

MSW-A2000P

MSW-2000P

Video

Compression

Video bit rate

Active lines per frame

Sampling frequency

Quantization

Error correction

Audio

Compression

Sampling frequency

Quantization

Channels

Data recording capability

Error correction

Versatile interfaces

•Analogue component I/O

•SDI I/O

•SDTI-CP I/O

•Analogue audio (4 ch)

•AES/EBU audio (16 bit - 8 ch/24 bit - 4 ch)

•Audio monitor (2 ch)

All equipped as standard.

Most of the electronic circuitry of the MSW-2000P

Series is arranged on plug-in boards for quick and

easy maintenance. The drum assembly and tape

transport have been designed to provide low-cost

maintenance and ensure rugged and reliable

operation. An upper drum mechanism has been

used to significantly reduce the time required for

periodic scanner replacement.

12.65 mm (1/2-inch)

Metal Particle tape

Max. 184 (525)/220 (625) with L cassette

64.467 (525)/53.776 (625) mm/s

21.7 µm

8 tracks/frame

Time code/Control

Betacam, Betacam SP, Betacam SX, Digital BETACAM

Betacam, Betacam SP, Betacam SX

Betacam SX

MPEG-2 4:2:2P@ML, Intra frame coding

(ISO/IEC 13818-2000)

50 Mb/s

512 (525)/608 (625)

Y: 13.5 MHz, R-Y/B-Y: 6.75 MHz

8 bits/sample

Reed-Solomon

None

48 kHz

16 or 24 bits/sample (selectable)

8 or 4

Yes

Reed-Solomon

Easy maintenance

Operational features of

MSW-2000P Series

MPEG IMXTM

Shot marks

Frame-accurate

insert/assemble editing

Multi-segment record capability for

use in Flexicart and LMS systems

Wide variable speed range

High speed picture search

Pre-read editing

Dynamic motion control

Optional accessories

For programmable slow-motion playback from the

recorder control panel, or from external edit controllers.

For easy and low cost integration into existing “on-air”facilities

Tapes containing Shot Marks can be scanned by the

MSW-2000P Series. The position of each Shot Mark

can be automatically detected and - after scanning -

can be displayed on a monitor. This allows fast and

easy cueing to any mark.

With all the interfaces provided as standard, the

number of accessories to the MSW-2000P Series has

been kept to a minimum. Options are shown below:

•Remote control panel

•RCC-5G Remote cable

•RMM-130 Rack mount kit

•Maintenance manual

•MPEG IMXTM Video cassettes*

BCT-6MX (7) / 12MX (14) / 22MX (26) / 32MX (38) / 60MX (71) (small)

BCT-64MXL (76) / 94MXL (112) / 124MXL (148) / 184MXL (220) (large)

* 625 record duration shown in brackets

•MPEG IMX™cassette: -1 to +3 times

•Digital Betacam cassette: -1 to +3 times

•Betacam SX cassette: -1 to +2 times

•Betacam, Betacam SP cassette: -1 to +3 times

With noiseless image and Digital Jog Sound.

Shuttle search speed

•MPEG IMX™cassette:

+/-78 times normal play speed

•Digital Betacam cassette:

+/-50 times normal play speed

•Betacam SX cassette:

+/-78 times normal play speed

•Betacam, Betacam SP cassette:

+/-42 times normal play speed

Video and any of the 8 channels of digital audio can be

edited independently. Editing is to +/-0 frame accuracy.

Pre-read editing is a standard feature of all MSW-2000P

Series recorders. This significantly speeds up the

editing process and simplifies operations such as titling,

video layering and audio sweetening.

Autres manuels Sony Équipement d'enregistrement

Sony

Sony XDSPD1000 Manuel utilisateur

Sony

Sony XDS1000 Manuel utilisateur

Sony

Sony DMX-R100 Manuel utilisateur

Sony

Sony PCM-R300 Manuel utilisateur

Sony

Sony Video Walkman GV-S50 Manuel utilisateur

Sony

Sony IFU-HS1 Manuel utilisateur

Sony

Sony PCM-D100 Manuel utilisateur

Sony

Sony CI-100 Manuel utilisateur

Sony

Sony SRW-1 Manuel utilisateur

Sony

Sony Memory Stick PRO Duo MS-MT Series Manuel utilisateur

Sony

Sony CCD-FX73OV Manuel utilisateur

Sony

Sony XE-8 - Graphic Equalizer Manuel utilisateur

Sony

Sony DMX-R100 Manuel utilisateur

Sony

Sony XDCAM PDW-U1 Manuel utilisateur

Sony

Sony RCD-W1 Operating Instructions (primary... Manuel utilisateur

Sony

Sony DPS-V55 Manuel utilisateur

Sony

Sony TC-177SD Guide de configuration

Sony

Sony HXR-IFR5 Manuel utilisateur

Sony

Sony PCM-MI Manuel utilisateur

Sony

Sony PFV-D300 Manuel utilisateur

Sony

Sony HXCU-FB70 Manuel utilisateur

Sony

Sony MU-R201 Manuel utilisateur

Sony

Sony DMX-R100 Manuel utilisateur

Sony

Sony MSW-A2000 Manuel utilisateur

Manuels Équipement d'enregistrement populaires d'autres marques

KV2 Audio

KV2 Audio 500 Series Manuel utilisateur

Robotics Technologies

Robotics Technologies microBus-Cam II Manuel utilisateur

Seca

Seca 460 Manuel utilisateur

Cognex

Cognex MVS-8000 Series Manuel utilisateur

Mect

Mect MPNC006 Series Manuel utilisateur

Bad Caf

Bad Caf THE LEASH Manuel utilisateur

Strymon

Strymon NIGHTSKY Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manuel utilisateur

Tews Technologies

Tews Technologies TPMC465 Manuel utilisateur

Honeywell

Honeywell Excel 50 Manuel utilisateur

SeaLevel

SeaLevel COMM+8.LPCI Manuel utilisateur

Arturia

Arturia AUDIOFUSE STUDIO Manuel utilisateur

Rukra

Rukra RK-1240 Manuel utilisateur

Samson

Samson SCOM Manuel utilisateur

Dynacord

Dynacord DPS260 Manuel utilisateur

Nice

Nice Core Manuel utilisateur

Pyle Pro

Pyle Pro PSS8 Manuel utilisateur

RF-System

RF-System TinyGate Manuel d'utilisation et d'entretien
