Sony SRF-DR2000 Manuel utilisateur

FM Data Receiver

1998 by Sony Corporation

SRF-DR2000

Operating instructions see 2-GB

Mode d’emploi voir 2-FR

Bedienungsanleitung seite 2-DE

Gebruiksaanwijzing zie 2-NL

Istruzioni per l’uso vedere 2-IT

3-864-117-31 (1)

2-GB

General Information

FOR YOUR RECORDS

For your assistance in reporting this unit in case of loss or

theft, please record below the model number and serial

number which are located on the back of the unit.

Please retain this information.

Model number

Serial number

Your ID number

Date of purchase

Place of purchase

Digital DJ System E2 is a registered

trademark of Digital DJ Inc.

3-GB

Table of Contents

Before You Begin ............................................................................ 4

Features ............................................................................................ 4

Getting Started

Installing the Batteries ................................................................... 5

Selecting a Language...................................................................... 7

Operating the Radio

Manual Tuning ............................................................................... 9

Presetting Stations ........................................................................ 10

Receiving Visual FM Data

Receiving Information Visually on Your Receiver .................. 12

Saving Information That You Can Recall ................................. 17

Deleting Information That Has Been Saved ............................. 19

Monitoring Stock Prices, Sports News, etc. .............................. 20

Setting the Functions.................................................................... 28

Additional Information

ID Numbers ................................................................................... 32

Using the Stand ............................................................................. 36

Specifications................................................................................. 36

Precautions .................................................................................... 37

Troubleshooting............................................................................ 39

Index to Parts and Controls ........................................................ 40

Index ............................................................................................... 42

4-GB

Before You Begin

Thank you for choosing the Sony FM data receiver!

The FM data receiver will give you many hours of listening

pleasure and will display up-to-date information.

Before operating the FM data receiver, please read these

instructions thoroughly and retain them for future reference.

Features

•FM stereo radio

•High-speed data receiver which can receive text and

graphics.

•Five Function buttons for user-friendly operations and

intuitive information-receiving operations.

•Automatic display of urgent messages from FM multiplex

broadcasts.

•Function to automatically turn off the power approximately

after 120 minutes (Auto Power OFF).

•Seven languages (English, French, German, Italian, Spanish,

Dutch, and Swedish) for the display indications to choose

from.

About FM multiplex broadcast

FM multiplex broadcast provides text and graphic data

through the open signal space in the frequencies of

normal radio broadcasts. It is transmitted by specific FM

broadcasting stations and the information cannot be

received using an ordinary radio. Some FM multiplex

broadcasts can be received free-of-charge, while others

may incur a subscription fee.

5-GB

”Getting Started

Installing the Batteries

Open the battery compartment lid and insert two R6 (size AA)

batteries (not supplied) with correct polarity.

Battery Life (Approx. hours)

Sony Alkaline LR6(SG) Sony R6(SR)

Audio only 35 14

FM multiplex reception 23 9

* For maximum performance we recommend that you use alkaline

batteries.

When to replace the batteries

Replace the batteries when “LOW BATTERY” is displayed.

Notes

• Insert the batteries with correct polarity.

• The dry batteries cannot be charged.

• Turn off the radio, and then replace the batteries within 20

seconds after the batteries are removed from the battery

compartment. Otherwise, the saved FM data and the preset

stations will be erased. In this case, preset the stations again. Be

sure to take note of important data saved in the memory.

• When you are not going to use your unit for an extended period

of time, remove the batteries to prevent possible damage from

battery leakage and corrosion.

Getting Started

DC IN 3V

R6 (size AA) ×2

6-GB

Using external power sources

You can connect the following external power sources through

the DC IN 3 V jack located on the left side of the unit. (When

you plug a cord into the DC IN 3 V jack, the internal batteries

are automatically bypassed.)

•House current using a Sony AC-E30HG (not supplied) AC

power adaptor

•12/24 V car battery using a Sony DCC-E230 (not supplied)

car battery cord

Notes

• When operating the unit with an external power source, do not

remove the batteries in the battery compartment as they serve as

backup power for the memory.

• Use only the recommended AC power adaptor or car battery cord

manufactured by Sony. The polarity of the plugs of other

manufacturers may be different.

Polarity of the plug

When the radio turns off unexpectedly

When you set the Auto Power OFF function to ON, the radio

turns off automatically approximately after 120 minutes to

prevent unnecessary drain on the batteries. To listen to the

radio continuously, press POWER.

If the radio does not turn on after pressing POWER, or if the

radio turns off unrelated to the Auto Power OFF feature, the

batteries are exhausted.

Replace both batteries with new ones.

To set this function see “To set the Auto Power OFF” (page 29)

under “Setting the Functions” (page 28, 29).

7-GB

Getting Started

Selecting a Language

You can select from seven languages (English, French,

German, Italian, Spanish, Dutch, and Swedish) for the

indications in the display. The explanation in the following is

when English is selected. Consequently, the indications in the

display are in English.

1While holding down ENTER, press POWER to turn on

the unit. The LANGUAGE SELECT MENU appears.

2Press the Function button corresponding to ↑UP or

↓DWN to move the cursor to the language you want.

Then, press the Function button corresponding to ENT.

The indications in the display will switch over to the

selected language.

POWER

ENTER

Function buttons

5:Spanish

ENT

vDWN

4:Italian

3:German

2:French

1:English

LANGUAGE SELECT MENU

8-GB

To change the selected language

Press POWER to turn off the unit and follow steps 1 and 2

on the previous page.

Notes

• The receiver does not translate the FM data it receives. Only the

indications in the display will switch over to the selected

language. The FM data will be displayed in the language

originally broadcast.

• The three display windows shown below will be in English, even

when you select a different language.

(see page 7)

(see page 13)

5:Spanish

ENT

vDWN

4:Italian

3:German

2:French

1:English

LANGUAGE SELECT MENU

PAGE:Last Page

H-PAGE

MSG

PAGE

MSG:Last Message

H-PAGE:Station Menu

Stored Data.

Retrieving

Choices for

M2:Free Programs

M1:Subscription

Downloads.

Data While Receiver

To Retrieve Stored

9-GB

1Connect the stereo headphones to the 2jack.

2Press POWER to turn on the unit.

If the frequency indication does not appear in the display, press

FM DATA.

3Press TUNE +/– to manually tune in to the desired

station.

If you press and hold TUNE +/–, the frequency is scanned

rapidly. Release the button to stop scanning.

4Adjust the volume with VOLUME.

To turn off the unit

Press POWER.

Operating the Radio

Manual Tuning

”Operating the Radio

POWER

VOLUME

NEWS•MUSIC

FM DATA

ENTER

Function

buttons

TUNE +/–

10-GB

Presetting Stations

The unit is initially preset with five FM radio stations. You can

replace each of the five stations with a station of your choice.

1Press POWER to turn on the unit.

2Press TUNE +/– to manually tune in to the desired

station.

If the frequency indication does not appear in the display, press

FM DATA.

3Press ENTER.

Press one of the Function buttons to preset the station,

“PRESET” flashes in the display.

4Press and hold down the desired Function button until

you hear two beeps.

To change an existing preset station

Follow step 1 to 4 above. For step 4, press the Function button

of the station you wish to change.

The existing preset station of the selected Function button will

be erased and replaced with your new favorite station.

97.5

87.5

MHz

92.0 98.0

108.0104.3

PRESET

97.5

MHz

92.0 98.0

108.0104.3

PRESET
