SWITCHER PROCESSOR PACK
DVS-9000-C
DVS9000SF-C
INSTALLATION MANUAL
1st Edition
HK-PSU04
BKDS-9160
BKDS-9161
BKDS-9162
BKDS-9210
MKS-8110SD
MKS-8111SD
DVS-9000
DVS-9000SF
PRODUCTION SWITCHER PROCESSOR
DVS-9000/9000SF
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
DVS-9000 Serial No. 10001 and Higher
DVS-9000SF Serial No. 10001 and Higher
BKDS-9160 Serial No. 10001 and Higher
BKDS-9161 Serial No. 10001 and Higher
BKDS-9162 Serial No. 10001 and Higher
BKDS-9210 Serial No. 10001 and Higher
MKS-8110SD Serial No. 10001 and Higher
MKS-8111SD Serial No. 10001 and Higher
HK-PSU04 Serial No. 10001 and Higher
DVS-9000/9000SF
Attention-when the product is installed in Rack:
1. Prevention against overloading of branch circuit
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
make sure that the rack does not overload the supply
circuit.
2. Providing protective earth
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
confirm that the outlet is provided with a suitable
protective earth connection.
3. Internal air ambient temperature of the rack
When this product is installed in a rack, please make
sure that the internal air ambient temperature of the
rack is within the specified limit of this product.
4. Prevention against achieving hazardous
condition due to uneven mechanical loading
When this product is installed in a rack, please make
sure that the rack does not achieve hazardous
condition due to uneven mechanical loading.
5. Install the equipment while taking the operating
temperature of the equipment into consideration
For the operating temperature of the equipment, refer
to the specifications of the Operation Manual.
6. When performing the installation, keep the rear of
the unit 10 cm (4 inches) or more away from walls
in order to obtain proper exhaust and radiation of
heat.
When using a LAN cable:
For safety,do not connect to the connector for
peripheral device wiring that might have excessive
voltage.
1 (P)
1
DVS-9000/9000SF
Table of Contents
Manual Structure
Purpose of this manual .............................................................................................. 3
Related manuals ......................................................................................................... 3
Contents ..................................................................................................................... 3
1. Installation
1-1. Operating Environment ............................................................................... 1-1
1-2. Power Supply .............................................................................................. 1-1
1-2-1. Power Specifications .................................................................. 1-1
1-2-2. Recommended Power Cord ........................................................ 1-1
1-3. Installation Space (External dimensions) .................................................... 1-2
1-3-1. DVS-9000 .................................................................................. 1-2
1-3-2. DVS-9000SF .............................................................................. 1-3
1-4. Installing the Options .................................................................................. 1-4
1-4-1. Installing the Plug-in Boards ...................................................... 1-4
1-4-2. Installing the Connector Board .................................................. 1-6
1-4-3. Installing the HK-PSU04 ........................................................... 1-7
1-5. Rack Mounting ............................................................................................ 1-8
1-6. Matching Connectors ................................................................................ 1-11
1-7. Input/Output Signals of Connectors .......................................................... 1-12
1-8. Checks on Completion of Installation ....................................................... 1-14
1-8-1. Description of On-board Switches and LEDs .......................... 1-14
1-9. System Connection.................................................................................... 1-26
2. Service Overview
2-1. Troubleshooting .......................................................................................... 2-1
2-2. Periodic Inspection and Maintenance ......................................................... 2-2
2-2-1. Cleaning ..................................................................................... 2-2
2-3. About the Data Backup Capacitor ............................................................... 2-3
3
DVS-9000/9000SF
Purpose of this manual
This manual is the installation manual of Switcher Processor Pack DVS-9000-C/
DVS9000SF-C and their optional boards and units.
This manual is intended for use by trained system and service engineers, and
describes the information on installing the DVS-9000-C/DVS9000SF-C system.
Related manuals
The following manuals are prepared for DVS-9000-C/DVS9000SF-C and their
optional boards and units.
..
..
.Operation Manual (Supplied with DVS-9000-C/DVS9000SF-C)
This manual describes the application and operation of DVS-9000-C/
DVS9000SF-C system.
..
..
.Maintenance Manual (Available on request)
This manual describes the detailed service information.
If this manual is required, please contact your local Sony Sales Office/Service
Center.
..
..
.“Semiconductor Pin Assignments” CD-ROM (Available on request)
This “Semiconductor Pin Assignments” CD-ROM allows you to search for
semiconductors used in B&P Company equipment.
Semiconductors that cannot be searched for on this CD-ROM are listed in the
maintenance manual for the corresponding unit. The maintenance manual contains
a complete list of all semiconductors and their ID Nos., and thus should be used
together with the CD-ROM.
Part number: 9-968-546-XX
Contents
This manual is organized by following sections.
Section 1 Installation
This section describes the operating environment, power supply, installation space,
installation of optional boards and units, rack mounting, connectors, input and
output signals of connectors, checking upon completion of installation, and system
configuration.
Section 2 Service Overview
This section describes the troubleshooting and periodic inspection and maintenance.
Manual Structure
1-1
DVS-9000/9000SF
Section 1
Installation
1-1. Operating Environment
Operating guaranteed temperature : +5 dC to +40 dC
Performance guaranteed temperature : +10 dC to +35 dC
Operating humidity : 10 % to 90 %
(relative humidity)
Storage temperature : _20 dC to +60 dC
Mass (when all options are installed) :
DVS-9000 : Approx. 43 kg
DVS-9000SF : Approx. 25 kg
Prohibited locations for installation
.Areas where the unit will be exposed do direct sunlight
or any other strong lights.
.Dusty areas
.Areas subject to vibration.
.Areas with strong electric or magnetic fields.
.Areas near heat sources.
.Areas subject to electrical noise.
.Areas subject where is subjected to static electricity.
Ventilation
The inside of the DVS-9000-C/DVS9000SF-C (DVS-9000
series hereafter) is cooled by a fan (both sides).
The power supply can be damaged if the exhaust vent
(both sides) and air intake (front panel) are blocked or the
fan is stopped.
Therefore, leave a blank space of more than 10 cm in the
front and both sides of the DVS-9000 series).
1-2. Power Supply
1-2-1. Power Specifications
A switching regulator is used for the power supply of this
unit. The voltage within the range of 100 V to 240 V can
be used without changing the supply voltage.
Power requirements : AC 100 to 240 V ±10 %
Power frequency : 50/60 Hz
Current consumption (when all options are installed) :
DVS-9000 : 8.6 to 4.2 A
DVS-9000SF : 5.5 to 2.5 A
m
.As the inrush current at turn-on is a maximum 60 A (at
100 V)/110 A (at 230 V), the capacity of the AC power
source must be commensurate with this load.
If the capacity of the AC power is not adequately large,
the AC power source braker will operate or the unit will
abnormally operate.
.The DVS-9000 contains the two power supply units as
the standard configuration. A maximum of four power
supply units may be installed. When starting up the
DVS-9000, be sure to turn on the power of two or more
power supply units.
.The DVS-9000SF contains the single power supply unit
as the standard configuration. A maximum of two power
supply units may be installed. When starting up the
DVS-9000, be sure to turn on the power of one or more
power supply units.
1-2-2. Recommended Power Cord
w
.The power cord is not supplied with the DVS-9000
series.
Be sure to use the power cord that is applicable to places
in the area.
To avoid a fire or an electric shock, be sure to use the
designated power cord.
.Do not damage the power cord otherwise a fire or
electric shock may result.
For customers in the U.S.A. and Canada
1Power cord, 125 V 10 A (2.4 m) : !1-557-377-11
AC inlet
1
For customers in the all European countries
1Power cord, 250 V 10 A (2.4 m) : !1-782-929-21
1
AC inlet
1-2 DVS-9000/9000SF
1-3. Installation Space (External dimensions)
Unit : mm
1-3. Installation Space (External dimensions)
1-3-1. DVS-9000
35
7
520
375
61 370
144.5 115.5 115.5
35
279.4
354(8U)
37.6
17.5
482
339
465
440
