Sony UPD-X100 Manuel utilisateur

3-207-362-12 (1)

Printer Driver

Installation Guide

This guide describes installation and use of the Windows XP

printer driver.

Before using the printer driver, be sure to read the “ReadMe”

file located on the CD-ROM.

Before Using this Software

UP-DX100

Table of Contents

Confirming the Operating Environment ............. 3

Explanations in this Guide ................................... 3

Before Installing the Printer Driver .................... 4

About Version Upgrades .................................... 4

About Driver Signing Options ........................... 4

Installing the Printer Driver ................................. 4

Removing the Printer Driver ................................ 6

Using the Printer Driver ....................................... 6

[Paper] Tab ......................................................... 6

[Graphics] Tab .................................................... 7

Microsoft and Windows are registered trademarks of

Microsoft Corporation.

Other company names and product names mentioned in

this guide are also trademarks and registered

trademarks.

Confirming the Operating Environment / Explanations in this Guide 3

Confirming the

Operating Environment

To use the Windows XP printer driver, the computer you

are using must satisfy the following requirements:

• The operating system must be Microsoft Windows XP.

Note

If you connect the UP-DX100 to your computer when

the printer is on, make sure that the operation of your

computer is not suspended or that it is not on stand-by.

Connecting the UP-DX100 to your computer when it is

in one of the states above may make operation erratic.

Explanations in this

Guide

All the explanations requiring the use of [Control Panel]

assume that you are using it in Classic View. To switch

to Classic View, on the [Start] menu, click [Control

Panel]. On the left side of the window, under [Control

Panel], click [Switch to Classic View].

Before Installing the Printer Driver / Before Installing the Printer Driver

Before Installing the

Printer Driver

About Version Upgrades

If you are upgrading a printer driver, remove the

previous printer driver before beginning the installation.

For details on the procedure to remove the printer driver,

refer to the section “Removing the Printer Driver” in this

guide.

If the installation fails or is cancelled, restart your

computer before attempting the installation again.

Note

Be sure to restart your computer after installing or

uninstalling the printer driver. Unless you reboot,

unstable operation may result.

About Driver Signing Options

The present printer driver has not passed Windows Logo

testing, therefore when you install the driver an error

message may appear, preventing you from installing the

driver.

In the [Driver Signing Options] dialog box, select

[Ignore] or [Warn] in the [What action do you want

Windows to take?] group box. If you select [Block], you

cannot install the printer driver.

Open the [Driver Signing Options] dialog box as

follows:

On the [Start] menu, click [Control Panel].

Double-click [System].

The [System Properties] dialog box opens.

Click the [Hardware] tab.

Click the [Driver Signing] button.

All the explanations in this guide assume that the setting

in this dialog box is [Warn].

Installing the Printer Driver 5

Installing the Printer

Driver

Connect the UP-DX100 to your computer.

Turn on the UP-DX100.

Turn on the computer and log on as the system

administrator.

The [Found New Hardware Wizard] dialog box

opens.

If the [Found New Hardware Wizard] dialog box

does not open, perform one of the following

procedures.

On the [Start] menu, click [Control Panel].

[Control Panel] opens.

Double-click [System].

The [System Properties] dialog box opens.

Click the [Hardware] tab, and then click the

[Device Manager] button.

The [Device Manager] window opens.

Double-click [Universal Serial Bus controllers].

Select [USB Printing Support], and on the

[Action] menu, click [Uninstall].

Restart your computer.

When Windows XP restarts, the [Found New

Hardware Wizard] dialog box opens.

Select [Install from a list or specific location

(Advanced)], and then click the [Next] button.

The screen changes as follows.

Insert the provided “SONY DIGITAL COLOR

PRINTER UP-DX100” CD-ROM into the

CD-ROM drive.

Select [Search for the best driver in these locations],

and then select the [Include this location in the

search] check box.

Click the [Browse] button, select the [Driver] folder

in the [Win2X] folder on the CD-ROM, and then

click the [Next] button.

The screen changes as follows.

Removing the Printer Driver / Removing the Printer Driver

Click the [Continue Anyway] button.

The screen changes as follows.

Click the [Finish] button.

Restart the computer.

This completes the installation of the printer driver.

Removing the Printer

Driver

Open the [Printers and Faxes] folder in [Control

Panel], right-click the UP-DX100 printer driver

icon, and click [Delete] on the shortcut menu.

Repeat this operation for all the UP-DX100 icons in

the window.

Select [Server Properties] from the [File] menu of

the [Printers and Faxes] folder.

Click the [Drivers] tab, select [Sony UP-DX100]

from the [Installed printer drivers] list, and then

click the [Remove] button.

When the confirmation of deletion message

appears, click the [Yes] button.

Restart your computer.

This completes the removal of the printer driver.

Note

Performing this procedure completely deletes the

UP-DX100 printer driver from your computer.

Using the Printer Driver 7

Using the Printer Driver

You can use the printer driver’s printing preferences to

set the default paper size, orientation, and make other

important settings.

Double-click [Printers and Faxes] in [Control Panel],

right-click [Sony UP-DX100], and then click [Printing

Preferences].

The [Sony UP-DX100 Printing Preferences] dialog box

opens and contains the following tab and items.

[Paper] Tab

Paper Type

Select the paper type from [UPC-X46] , [UPC-X34]

and [UPC-X45].

Orientation

Select [Portrait] or [Landscape] for the print orientation.

Copies

Select the number of copies to print (1 to 9).

Scaling

Select the rate of enlargement or reduction

(10% to 400%).

[Graphics] Tab

Make settings related to the color, brightness, and

image. From the [Color Adjust] list, select [Digital

Camera Correction], [Color Balance], and [Lightness]

and change each of their settings.

Digital Camera Correction

From the [Color Adjust] list, select [Digital Camera

Correction].

If you select the [Use Digital Camera Correction] check

box, digital camera correction is enabled.

• If you select [Auto], optimal correction is performed.

• When [Custom] is selected, you can drag the sliders

left or right to adjust the [Brightness], [Contrast], and

[Saturation]. Furthermore, you can also adjust these

settings by entering numbers in the input boxes.

Using the Printer Driver

Color Balance

From the [Color Adjust] list, select [Color Balance].

Adjust the color balance by dragging the sliders left or

right or entering numbers in the input boxes.

Lightness

From the [Color Adjust] list, select [Lightness].

Adjust the lightness by dragging the sliders left or right

or entering numbers in the input boxes.
