Sony Glasstron PLM-S700E Manuel utilisateur
3-862-917-21 (1)
Glasstron
Operating Instructions
Mode d’emploi
WARNING
YOUR FAILURE TO FOLLOW THESE OPERATING INSTRUCTIONS MAY RESULT IN EYE
FATIGUE, EYE DAMAGE, OR OTHER INJURY.
CAREFULLY READ THIS INSTRUCTION MANUAL AND BECOME FAMILIAR WITH ALL
SAFETY INSTRUCTIONS FOR THIS PRODUCT.
THIS PRODUCT SHOULD NOT BE USED BY CHILDREN AGE 15 OR YOUNGER.
IF YOU HAVE BEEN DIAGNOSED WITH EYE DISEASE OR EYE INJURY, CONSULT YOUR
DOCTOR BEFORE USE AND DO NOT USE WITHOUT YOUR DOCTOR’S APPROVAL.
AVERTISSEMENT
LE NON-RESPECT DES PRESENTES INSTRUCTIONS D’UTILISATION IMPLIQUE DES
RISQUES DE FATIGUE, DE BLESSURE OU AUTRES AUX YEUX.
LISEZ ATTENTIVEMENT LE PRESENT MODE D’EMPLOI ET FAMILIARISEZ-VOUS AVEC
TOUTES LES INSTRUCTIONS DE SECURITE AFFERENTES.
CET APPAREIL NE PEUT ETRE UTILISE PAR DES ENFANTS AGES DE 15 ANS OU MOINS.
SI VOUS SOUFFREZ DE MALADIES OU D’AFFECTIONS OCULAIRES, CONSULTEZ
VOTRE MEDECIN AVANT D’UTILISER CET APPAREIL ET NE L’UTILISEZ PAS SANS
L’AUTORISATION DE VOTRE MEDECIN.
PLM-S700E
© 1998 by Sony Corporation
GB
FR
2-GB
WARNING
Precautions
• The nameplate is located on the bottom
exterior.
• Picture/sound distortion may occur if the
model PLM-S700E is positioned in close
proximity to any equipment emitting
electromagnetic radiation.
To prevent fire or shock hazard,
do not expose the unit to rain or
moisture.
To avoid electrical shock, do not
open the cabinet. Refer servicing
to qualified personnel only.
This product conforms with the following
European Directives:
73/23/EEC, 93/68/EEC (Low Voltage
Directive)
89/336/EEC, 92/31/EEC (EMC Directive)
This equipment complies with EN55022
Class B for use in following areas:
residential, business and light-industrial.
The supplied interference cable must be
used with the equipment in order to comply
with the limits for a digital device pursuant
to EN55022.
•IBM PC/AT and VGA are registered trademarks of IBM Corporation of the U.S.A.
•Microsoft, MS, MS-DOS and Windowsare registered trademarks of Microsoft Corporation in the
United States and other countries.
•Macintosh is a trademark licensed to Apple Computer, Inc., registered in the U.S.A. and other
countries.
•VESA is a trademark of Video Electronics Standard Association.
•All other product names mentioned herein may be the trademarks or registered trademarks of
their respective companies. Furthermore, “” and “" are not mentioned in each case in this
manual.
3-GB
Table of Contents
GB
SAFETY INSTRUCTIONS ....................................................................................... 5
About the Glasstron ............................................................................................... 10
Getting Started
Checking the supplied accessories....................................................................... 12
Locating the parts and controls ............................................................................ 13
Connecting the Glasstron
Connecting the PC ............................................................................................ 14
Connecting the video equipment ................................................................... 17
Connecting the power source.......................................................................... 19
Wearing the Glasstron ........................................................................................... 20
Turning on the Glasstron
Checking the display unit position ................................................................ 22
Checking the screen position alignment........................................................ 24
Setting the password .............................................................................................. 27
Operations
Using the Glasstron ................................................................................................ 29
Checking the display indication ..................................................................... 31
Screen warnings against overuse of the Glasstron ...................................... 32
Viewing the surrounding environment .............................................................. 33
Adjusting the sound and picture
Signal compatibility .......................................................................................... 34
Adjusting the sound/picture .......................................................................... 35
Adjusting the RGB signal................................................................................. 38
Adjusting the video signal............................................................................... 39
Resetting the adjustment to the factory preset level .................................... 39
Using the optional battery pack ........................................................................... 40
Additional Information
Precautions .............................................................................................................. 42
Error messages ........................................................................................................ 44
Troubleshooting...................................................................................................... 45
Specifications........................................................................................................... 47
Index ......................................................................................................................... 48
4-GB
Glasstron is a brand-new concept in
visual display
Note on the LCD (Liquid Crystal
Display)
The LCD screen is made with high-
precision technology. However, black
points or bright points of light (red, blue,
or green) may appear constantly on the
LCD screen. This is not malfunction.
(Effective dots: more than 99.999%)
Congratulations on your purchase of a Sony
Glasstron Personal Viewer. The Glasstron,
using current technology in small,
lightweight visual displays, provides a
television viewing experience similar to
watching a 30-inch television from a
distance of approximately 4 feet in SVGA
mode. (Viewing experience may differ
according to individual perception.)
The Glasstron Personal Viewer creates an
image through two separate liquid crystal
displays, in close proximity to your eyes.
To insure your safe use of the Glasstron,
please become familiar with its basic
operations, including proper fitting
instructions, and be aware of any symptoms
of eye fatigue or other discomfort you may
experience.
WARNING
YOUR FAILURE TO FOLLOW THESE
OPERATING INSTRUCTIONS MAY
RESULT IN EYE FATIGUE, EYE
IMPAIRMENT, OR OTHER EYE INJURY,
PROPERTY DAMAGE OR DEATH.
WARNING
THIS PRODUCT SHOULD NOT BE USED
BY CHILDREN AGE 15 OR YOUNGER.
THE EYES OF CHILDREN ARE STILL
DEVELOPING AND MAY BE ADVERSELY
AFFECTED FROM USE OF THIS
PRODUCT.
5-GB
SAFETY INSTRUCTIONS
THE SONY GLASSTRON PERSONAL VIEWER SHOULD BE USED IN
STRICT ACCORDANCE WITH ALL INSTRUCTIONS TO PREVENT EYE OR
OTHER INJURY, LOSS OF VISUAL FUNCTIONS, PROPERTY DAMAGE, OR
DEATH.
USE RESTRICTIONS
Warning: No Use by Children Age 15 or Younger.
This product is designed for adult use.
The eyes of children are still developing and may be adversely affected by use of
this product, and it may cause eye fatigue, eye damage, or loss of visual
functions.
In addition, this product may not be adjusted to fit a child’s head.
Safety Password: To prevent use by children age 15 or younger, this product
has been equipped with a safety password protection system.
For instructions on the use of the password protection system,
see page 27.
Warning: Eye Disease/Eye Injury/Glaucoma.
If you have been diagnosed with or are susceptible to eye disease, eye injury, or
glaucoma, consult your doctor before use and do not use without your doctor’s
approval. Use of this product by individuals with conditions such as glaucoma
may cause these conditions to worsen.
Caution: Heart Disease/High Blood Pressure.
If you have a history of heart disease or high blood pressure, consult your doctor
before use and do not use without your doctor’s approval. Use of this product
allows the viewer to feel they are in the action, which may result in increased
anxiety or heart injury. If during viewing any increased anxiety is experienced,
stop using the product immediately and rest. If the symptoms persist after rest,
consult your doctor.
Caution: Seizures.
If you have a history of temporary spasms, unconsciousness, or epileptic
seizures from light stimulation, consult your doctor before use and do not use
without your doctor’s approval. Use of this product by such individuals may
cause spasms, unconsciousness, or seizures. If you experience such symptoms
during use, stop using the product immediately and consult your doctor.
ADDITIONAL SAFETY INFORMATION.
A. Health Concerns. See pages 6 through 7.
B. Instructions for Safe Fit. See page 8.
C. Warnings for Electronic Products. See page 9.
6-GB
SAFETY INSTRUCTIONS (continued)
Health Concerns
Warning: Eye Fatigue/Eye Damage/Loss of Visual Functions.
Misuse or overuse of this product may result in eye fatigue, eye damage, or loss
of visual functions. Stop using if you feel tired or experience headaches or
discomfort.
Warning: No Use by Children Age 15 or Younger.
This product is designed for adult use.
The eyes of children are still developing and may be adversely affected by use of
this product, and it may cause eye fatigue, eye damage, or loss of visual
functions.
In addition, this product may not be adjusted to fit a child’s head.
Caution: Sickness/Headache/Nausea.
If during use you experience any of the following symptoms, stop using this
product immediately and rest. These symptoms may indicate that you are
misusing or overusing the product (see “Instructions for Safe Fit,” page 8) or that
you should not use the product for health reasons. If the following symptoms
persist after rest, consult your doctor.
- sore eyes, eye fatigue, or double vision
- headache
- inability to focus on the screen
- nausea or motion sickness
- stiff or sore shoulders or neck
After six hours the product automatically turns off to prevent eye fatigue or eye
damage. For instructions on these functions, see page 32.
Caution: Motion Sickness from Viewing Programmes.
Some viewers may experience motion sickness, headache, or nausea from
viewing movies or video programmes, especially those with intense action and
movement. If you feel any of these symptoms, stop using the product
immediately. To avoid personal injury or injury to others, do not drive a car or
motorcycle, nor do anything that requires concentration until the symptoms
disappear.
7-GB
Health Concerns
Caution: Motion Sickness from External Motion.
Do not use this product while subject to external motion –– for example, as a
passenger in a car. Use of this product under these conditions may cause motion
sickness.
Caution: Accidents.
Do not use this product while walking, skating, bicycling, operating a motor
vehicle or other power equipment, or while engaged in any other similar
activity.
Use of this product under these conditions may result in an accident, injury, or
death to yourself or others.
Caution: Sound Volume.
Avoid using headphones at high volume. Hearing experts advise against
continuous, loud, and extended play. If you experience a ringing in your ears,
reduce volume or discontinue use.
8-GB
SAFETY INSTRUCTIONS (continued)
Instructions for Safe Fit
Warning: Proper Fit.
Each time this product is used adjustment screens will appear, requiring the
viewer to properly fit the product. Proper fit means that an asterisk (*) will
appear in each corner of the display. Failure to properly fit the product each
time may result in eye fatigue, eye damage, or loss of visual functions and may
result in accident or injury. For instructions on how to properly fit this product,
see pages 22 through 26.
Warning: No Use by Children Age 15 or Younger.
This product is designed for adult use.
The eyes of children are still developing and may be adversely affected by use of
this product, and it may cause eye fatigue, eye damage, or loss of visual
functions.
In addition, this product may not be adjusted to fit a child’s head.
Safety Password: To prevent use by children age 15 or younger, this product
has been equipped with a safety password protection system.
For instructions on the use of the password protection system,
see page 27.
9-GB
Warnings for Electronic Products
Caution: Electric Shock.
Failure to observe all operating and maintenance instructions may cause damage
to your product and may result in property damage or injury or death from
electric shock, fire, or other cause.
Caution: Do Not Disassemble.
Any required service on this product should be performed by a trained
authorised servicer. Failure to comply with this warning may result in property
damage or personal injury or death from electric shock, fire, or other cause.
Caution: Avoid Wet, Humid, Dusty and Smoky
Environments.
This product may be adversely affected by wet, humid, dusty, and smoky
conditions which may result in property damage, personal injury or death. Do
not use this product near or around water. Avoid using or storing this product
under these conditions.
Caution: Avoid High Temperature or Direct Sunlight/Avoid
Mechanical Shock.
This product may be deformed by high temperature or direct sunlight and also
by dropping the product or other mechanical shock. Avoid these conditions, as
the screens may loose proper alignment and it may cause eye fatigue or eye
damage.
Caution: Unplug the Product When Not in Use.
Always unplug this product when it will not be in use for extended periods of
time or during vacations.
10-GB
About the Glasstron
Caution: The screen is always right in front of you.
The Glasstron is a head-mounted display. With this type of display, the screen is always in front
of you even if you move your head. Because of this feature, you can concentrate on the screen
more easily compared with ordinary TVs, and you have a sense of being in the action.
• It is easy to adjust the Glasstron to your eyes. You can use the display unit even while
wearing glasses.
• Every time you use the Glasstron, the adjustment screen appears to help you adjust the
display unit properly. You can also check whether the left and right screen positions are
properly aligned or not.
• Cautions appear on the screen about every two hours to remind you to check for eye fatigue.
The power will automatically turn off if you do not press the PUSH DISPLAY jog dial. If you
keep using the Glasstron continuously for six hours, a warning appears on the screen and the
power will turn off automatically.
The Glasstron consists of the following items:
Power supply box
You can supply power using the
supplied AC power adapter or the
optional Sony rechargeable battery
pack.
When using with the Glasstron,
connect your video equipment or
PC to the connector on the power
supply box.
You can adjust the sound volume.
You can also use the SEE-
THROUGH control in order to see
the surrounding environment.
Personal Computer
VCR Laser disc player,
DVD player Camcorder
Display unit
The display unit is equipped with
two small (left and right) LCDs.
Autres manuels pour Glasstron PLM-S700E
1
Table des matières
Langues :
Autres manuels Sony Moniteur
Sony
Sony SDM-S75EB Manuel utilisateur
Sony
Sony S75F Manuel utilisateur
Sony
Sony StylePro SDM-S51R Manuel utilisateur
Sony
Sony SDM-HS95 - 19" LCD Monitor Manuel utilisateur
Sony
Sony BVM-L230 Trimaster Manuel utilisateur
Sony
Sony PR711 Manuel utilisateur
Sony
Sony Trinitron PVM-14L1MDE Manuel utilisateur
Sony
Sony HMD-A240R Manuel utilisateur
Sony
Sony BKM-21D Guide de démarrage rapide
Sony
Sony Trinitron PVM-14M2MDU Manuel utilisateur
Sony
Sony Multiscan CPD-E100 Manuel utilisateur
Sony
Sony LMD-1510W Manuel utilisateur
Sony
Sony XVM-80 Manuel utilisateur
Sony
Sony Multiscan CPD-420GS Manuel utilisateur
Sony
Sony Trinitron GDM-200PST9 Manuel utilisateur
Sony
Sony TRINITRON PVM-D14L5A Manuel utilisateur
Sony
Sony SSM-930 Manuel utilisateur
Sony
Sony Trinitron PVM-2130QM Manuel utilisateur
Sony
Sony Multiscan SDM-M51 Manuel utilisateur
Sony
Sony FWD-S42E1 Manuel utilisateur
