AXS-R7

Introduction

This document describes how to update the AXS-R7

firmware to the latest version.

You will need to save the update data to a USB storage

device before performing update.

Preparation

Preparing the USB Storage Device

Use a USB storage device with a capacity of 4 GB to

32 GB.

Format the USB storage device on a computer, for

example.

The format conditions are as follows.

• File system: FAT32

• Allocation unit size: 32 KB

Version update cannot be performed under conditions

other than the above.

Save the update data to the root directory of the

formatted USB storage device.

Do not store any other data on the USB storage

device.

Precautions for Version Update

Use the recommended AC-DN10 or AC-DN2B AC

adapter.

Note

Updating the Firmware

Performing Version Update

Do not perform the following while update is in progress.

Failure to obey may result in interruption of the update

procedure and malfunction.

• Disconnection/connection of the USB storage device

• Disconnection of the AC adapter

For details on the unit or the camcorder, refer to their

respective operating instructions.

Remove the two screws securing the plate on the

bottom of the unit.

Connect the AC adapter’s DC power supply to the

unit.

Version update is possible without the camcorder.

When performing version update with the unit

connected to the camcorder, turn the camcorder off.

Insert the USB storage device on which the update

data is stored into the USB port on the bottom of the

unit.

Press the update button using a narrow, pointed

object.

Hold the button for at least 5 seconds or until the

TALLY lamp blinks.

When the update button is pressed, the TALLY lamp

and POWER indicator light and the unit turns on. The

TALLY will blink after about 3 seconds and then

remain steadily lit again when version update starts.

The TALLY lamp will remain lit while update is in

progress.

Version update is complete when the TALLY lamp

begins to blink at 1-second intervals.

Update takes about 15 minutes to complete.

If the unit does not turn on

If the POWER indicator does not light and the unit

does not turn on, the following is possible.

• The AC adapter is not connected.

• Power is not being supplied to the connected AC

adapter.

In such cases, connect the AC adapter properly, and

perform the update procedure again.

If the USB storage device is not recognized

or the update data is not found

If the USB storage device is not recognized or the

update data is not found, the TALLY lamp will blink

faster than at 1-second intervals. The following is

possible in such cases.

• The USB storage device is not fully inserted.

• The USB storage device is not formatted in the

specified file system or allocation unit size.

In such cases, disconnect the DC power supply and

turn the unit off, check for the above, and then

perform the update procedure again according to the

instructions.

If the update procedure is interrupted or fails

If there is a problem with the update data, the TALLY

lamp will blink faster than at 1-second intervals.

In such cases, disconnect the DC power supply and

turn the unit off, and then perform the update

procedure again according to the instructions.

If the update procedure still fails to properly

complete, the recorder may be malfunctioning.

Note

TALLY lamp

POWER indicator

Update button

Disconnect the DC power supply after version update

is complete, and turn the unit off.

Remove the USB storage device, and secure the plate

to the bottom of the unit with the screws.
