Sony WEGA KLV 15SR1 Manuel utilisateur

Remote Control

RM-932 (1)

Coaxial cable (1)

Cleaning cloth (1)

Operating Instructions

(1)

To put the cables in the stand

You can put the aerial cable, AC power adapter cable and

Scart cable in the stand.

1Pull the upper edge of

the cable cover

toward you and

remove it.

2Pass the cables into

the stand.

3Replace the cable

cover while aligning

the claws on the cover

with the holes on the

stand.

Note

• The other cables may not be put in the stand.

To adjust the TV angle

You can adjust the angle of the TV for easy viewing.

Carrying the TV

• Before carrying the TV, disconnect all the cables from the

TV. If it drops, a serious injury may result.

• When you carry the TV for repair or moving, pack it

using the original carton and packing material.

• When you carry the TV by hand, hold it at the top and

bottom. Do not hold the rear cover only.

To play a video tape, press ton the remote.

Note

• For connecting a VCR to the t 2 connectors, see “Connecting optional

components” on page 11 of the Operating Instructions.

Connect the AC cable

To connect the TV to the mains, use the supplied AC power adapter

and AC cable.

Note

• Do not remove the ferrite core from the AC power adapter.

16.5V

/G/S/I

To remove the rear cover

1Hold the rear cover as

illustrated, and slide it

upward by about 10

mm.

2Pull the rear cover

toward you.

To replace the rear cover 1Hold the rear cover as

illustrated, and align

the four projections on

the rear cover with the

hook holes on the TV.

(The rear cover may

protrude from the TV

by about 10 mm.)

2While pushing the rear

cover toward the TV,

slide it downward.

Note

• When you carry the TV, do not hold the rear cover only, as the rear cover

can easily come off.

Batteries (R6 Type) (2)

AC Cable (Type C) (1)

• Use this AC cable

(with safety earth) if

you use the set

outside the United

Kingdom.

KLV-17HR1

KLV-15SR1

Quick Start Guide

Thank you for purchasing this Sony

product.

After following this step by step

guide you will be able to:

— Remove the Rear Cover.

— Connect the Aerial, VCR and AC

Cable to your TV.

— Insert Batteries into the Remote.

— Select the Language of the Menu

Screens.

— Select the Country in which You

Wish to Operate your TV.

— Tune your TV.

— Change the Programme Order of

the Broadcast Channels.

Now you are ready for viewing TV

programmes.

Removing the Rear Cover

Before connecting an aerial and cables, remove

the cover at the rear of your TV. Replace the

cover after all the connections are complete.

Connecting the Aerial,

VCR and AC Cable

Do not remove

ferrite cores.

Connect the aerial

CAUTION

Do not connect the power cord until all other connections are

complete; otherwise, a minimal current leakage through the aerial

and/or other terminals to the ground could occur.

Connect a VCR

: Signal flow

IEC connector

Aerial cable

(supplied)

Rear of TV

To 8(aerial)

Scart cable

(not supplied) : Signal flow

To i1/

VCR

Aerial cable

(supplied)

To aerial output

To 8(aerial)

Rear of TV

To 16.5 V

AC power adapter

(supplied)

AC cable

(supplied)

To mains

3° forward

Right side

15° backward

Note

• Do not use old batteries or different types of batteries together.

Pull here.

Cable cover

3Inserting Batteries into

the Remote

4-092-620-11 (1)

Printed in Japan

Checking the Supplied

Accessories 4

AC power adapter (1)

AC Cable (Type BF) (1)

• Use this AC cable (with

safety earth) if you use

the set in the United

Kingdom or Hong

Kong.

• See “NOTICE FOR

CUSTOMERS IN THE

UNITED KINGDOM”

on page 2 of the

Operating Instructions

when using the cable.

Rear of TV

578

Turning on your TV

1Connect the TV to the mains

socket (220 - 240 V AC, 50

Hz).

2Press = / 1 to turn on the TV.

Selecting the Language

of the Menu Screens and

the Country

When you turned on the TV for the first time,

a menu screen sequence appears on the TV

enabling you to set up your TV easily (Auto

Startup).

When you press = / 1 for the first time, the “LANGUAGE” menu

appears automatically for Auto Startup.

1Press vor Von the remote to

select the language, then press

OK.

Now, all the menus will appear

in the selected language.

The “COUNTRY” menu appears

automatically.

2Press Bor bto select the country

in which you will operate the TV,

then press OK.

If your country does not appear

in the options, select “– .”

The initial display appears.

Note

• To perform Auto Startup later, press 0on the rear panel of the TV.

Press Bor bto select “YES,” then

press OK.

The TV starts searching for

broadcast channels and stores all the

available channels.

When all the available channels are

stored, the “PROGRAMME

SORTING” menu appears.

a) If you want to keep the broadcast

channels in the tuned order:

Press MENU to return to the

normal screen.

Your TV is now ready for

use.

b) If you want to store the broadcast

channels in a different order:

1Press Bor bto select the

programme number of the

channel whose order you

want to rearrange, then press

OK.

2Press Bor bto select a new

programme number for the

selected channel, then press

OK.

Repeat steps 1and 2to

change the order of the other

channels.

3Press MENU to return to the

normal screen.

Your TV is now ready for

use.

Tuning the TV

Automatically

When you changed the country setting, you

need to tune the TV to receive channels (TV

broadcast). By following the instructions, the

TV automatically searches for broadcast

channels and stores all available channels.

v/ V/ B/ b

Changing the Programme

Order of the Broadcast

Channels

You can rearrange the order of the broadcast

channels which have been stored

automatically.

Supplied Remote Control

TVVIDEO

DVD

VCR

123

456

789

MENU REC

PROG

LANGUAGE

ENGLISH

EXIT : MENU

ENGLISH

DEUTSCH

ESPAÑOL

ITALIANO

FRANÇAIS

NEDERLANDS

PORTUGUÊS

COUNTRY

EXIT : MENU

AUSTRIA

EXIT : MENU

DO YOU WANT TO START

AUTOMATIC TUNING?

YES

EXIT : MENU

DO YOU WANT TO START

AUTOMATIC TUNING?

YES

AUTO SET–UP

EXIT : MENU

PROGRAMME 1

VHF–L

PROGRAMME SORTING

EXIT : MENU

PROGRAMME 1AAA

PROGRAMME SORTING

EXIT : MENU

PROGRAMME 1AAA

MEN

PROGRAMME SORTING

EXIT : MENU

PROGRAMME 1AAA

PROGRAMME SORTING

EXIT : MENU

OLD 1 AAA

NEW 2

MEN
