Sony NEX-5T Manuel utilisateur

4-472-074-11(1)

NEX-6/NEX-5R/NEX-5T

Interchangeable

Lens Digital Camera

αHandbook

About the NEX-5T

Index (NEX-5T)

Table of contents

Sample photo

Index

iGB

About the

NEX-5T

Index

(NEX-5T)

About the NEX-5T

The NEX-5T is equipped with all the functions of the NEX-5R.

This section, “About the NEX-5T,” describes the added functions of the NEX-5T, the

procedure for using them, and the differences between the NEX-5R and the NEX-5T.

For shared functions among the NEX-5R and the NEX-5T, refer to sections other than

“About the NEX-5T.”

Also, refer to the instruction manual of the NEX-5T and the flyer “Wi-Fi Connection/

One-touch (NFC) Guide.”

Added functions of the NEX-5T

The following functions have been added to the NEX-5T compared to the NEX-5R.

Added functions Description

One-touch functions With just one touch, the camera automatically sets the SSID and

the password to connect to an NFC-enabled Android

Smartphone or tablet computers.

One-touch sharing

(Send to Smartphone)

When the camera is in playback mode, you can connect the

camera and an NFC-enabled Android Smartphone with one

touch, and send images to the Smartphone.

Smart Remote Embedded You can use your Smartphone as a remote controller for the

camera. Use the factory preset application [Smart Remote

Embedded] on the camera.

If you use an NFC-enabled Android Smartphone, you can

connect the camera and the Smartphone with a one-touch

operation (One-touch remote).

One-touch(NFC) You can call up an application installed on the camera by

touching an NFC-enabled Android Smartphone to the camera.

Airplane Mode When you board an airplane, etc., you can turn off all Wi-Fi and

NFC functions temporarily.

zAbout NFC

NFC is a technology that enables short-range wireless communication between various

devices, such as mobile phones or IC tags, etc. NFC makes data communication simpler

with just a touch on the designated touch-point.

• NFC (Near Field Communication) is an international standard of short-range wireless

communication technology.

iiGB

About the

NEX-5T

Index

(NEX-5T)

Renamed functions on the

NEX-5T

On the NEX-5T, the following functions have been renamed from the NEX-5R, but the

features are the same.

To search for these functions in this handbook, use the NEX-5R function names.

One-touch sharing (Sending an

image to a Smartphone)

With just one touch, you can connect the camera and an NFC-enabled Android

Smartphone, and send an image displayed on the camera screen directly to the

Smartphone.

Download and install the application “PlayMemories Mobile” from your Smartphone’s

application store.

If “PlayMemories Mobile” is already installed on your Smartphone, be sure to update it

to the latest version.

For details on “PlayMemories Mobile,” refer to the support page (http://www.sony.net/

pmm/).

To send images to an iPhone, or to an Android Smartphone without the NFC function,

refer to “Sending images without using the NFC function”.

NEX-5R function name NEX-5T function name

Object Tracking Tracking Focus

Reset View on Smartphone SSID/PW Reset

View on Smartphone Send to Smartphone

1Play back a single image to be sent on the

camera.

2Activate the NFC function of the Smartphone.

• Refer to the instruction manual of the Smartphone on how to activate the NFC function.

Continued r

iiiGB

About the

NEX-5T

Index

(NEX-5T)

• When the camera plays back images in index mode, you cannot send images using One-touch sharing.

• When [Airplane Mode] is set to [On], you cannot connect the camera and the Smartphone. Set [Airplane

Mode] to [Off].

• RAW images are converted to JPEG format when they are sent.

• You cannot send AVCHD format movies.

3Touch the Smartphone to the camera,

aligning both N marks.

The camera and the Smartphone are connected, and

“PlayMemories Mobile” automatically launches on the

Smartphone, and then the displayed image is sent to the

Smartphone.

• The NFC function is available only when the (N mark) is displayed on the camera.

• Touch the Smartphone to the camera for more than two seconds until “PlayMemories Mobile”

launches.

• If you cannot find an N mark on the Smartphone, confirm the touch-point referring to the instruction

manual of the Smartphone.

• You can select an image size to be sent to the Smartphone from [Original], [2M] or [VGA].

To change the image size: For Android, select [Image quality] from the “PlayMemories Mobile”

menu, and for iPhone, select the setting menu t“PlayMemories Mobile” t[Image quality].

Notes

zTraveling to the download website of “PlayMemories

Mobile” with one touch

When you touch an NFC-enabled Android Smartphone to the N mark on the camera, and if

“PlayMemories Mobile” is not installed on that Smartphone, the web browser launches and

displays the application store to enable you to download “PlayMemories Mobile.”

ivGB

About the

NEX-5T

Index

(NEX-5T)

Selecting the desired mode and

sending images (Send to

Smartphone)

Set the image selection mode and then send images to a Smartphone.

Download and install the application “PlayMemories Mobile” from your Smartphone’s

application store.

If “PlayMemories Mobile” is already installed on your Smartphone, be sure to update it

to the latest version.

For details on “PlayMemories Mobile,” refer to the support page (http://www.sony.net/

pmm/).

1MENU t[Playback] t[Send to Smartphone] tdesired mode.

• When you press (Send to Smartphone) on the camera, proceed to step 1of [Select on This

Device].

Connecting the camera and a Smartphone using

One-touch connection

Select on This Device Selects images to be sent to the Smartphone from the camera.

1Select a mode from [This Image], [All Images on This

Date], [All Movie(MP4) on Date], or [Multiple Images].

2[OK] tzon the control wheel

If you select [Multiple Images], select the desired images

using zon the control wheel, then press [OK] tz.

Select on Smartphone Displays all images recorded on the camera’s memory card

on the Smartphone.

When the camera is ready for the connection, the

information screen appears.

2Activate the NFC function of the Smartphone.

3Touch the Smartphone to the camera,

aligning both N marks.

The camera and the Smartphone are connected, and

“PlayMemories Mobile” launches on the Smartphone,

and then the selected images are sent to the Smartphone.

Continued rContinued r

vGB

About the

NEX-5T

Index

(NEX-5T)

• When [Airplane Mode] is set to [On], you cannot connect the camera and the Smartphone. Set [Airplane

Mode] to [Off].

• RAW images are converted to JPEG format when they are sent.

• You cannot send AVCHD format movies.

1MENU t[Playback] t[Send to Smartphone] tdesired mode.

• When you press (Send to Smartphone) on the camera, proceed to step 1of [Select on This

Device].

• The NFC function is available only when the (N mark) is displayed on the camera.

• Touch the Smartphone to the camera for more than two seconds until “PlayMemories Mobile”

launches.

• If you cannot find an N mark on the Smartphone, confirm the touch-point by referring to the

instruction manual of the Smartphone.

• You can select an image size to be sent to the Smartphone from [Original], [2M] or [VGA].

To change the image size: For Android, select [Image quality] from the “PlayMemories Mobile”

menu, and for iPhone, select the setting menu t“PlayMemories Mobile” t[Image quality].

Notes

Sending images without using the NFC function

Select on This Device Selects images to be sent to the Smartphone from the camera.

1Select a mode from [This Image], [All Images on This

Date], [All Movie(MP4) on Date], or [Multiple Images].

2[OK] tzon the control wheel

If you select [Multiple Images], select the desired images

using zon the control wheel, then press [OK] tz.

Select on Smartphone Displays all images recorded on the camera’s memory card

on the Smartphone.

When the camera is ready for the connection, the

information screen appears.

2Connect the Smartphone and the camera using the SSID and password

on the information screen.

• You can select an image size to be sent to the Smartphone from [Original], [2M] or [VGA].

To change the image size: For Android, select [Image quality] from the “PlayMemories Mobile”

menu, and for iPhone, select the setting menu t“PlayMemories Mobile” t[Image quality].

[For Android]

[For iPhone]

Continued r

viGB

About the

NEX-5T

Index

(NEX-5T)

Connecting an Android Smartphone to the camera

Connecting an iPhone to the camera

1Launch “PlayMemories Mobile” on your

Smartphone.

2Select the model name of this camera

(DIRECT-xxxx:NEX-5T).

3Input the password that is displayed on the

camera.

The Smartphone is connected to the camera.

1Select the model name of this camera

(DIRECT-xxxx:NEX-5T) on the Wi-Fi setting

screen of your Smartphone.

2Input the password that is displayed on the

camera.

The Smartphone is connected to the camera.

3Launch “PlayMemories Mobile” on the

Smartphone.

Continued r

viiGB

About the

NEX-5T

Index

(NEX-5T)

• When [Airplane Mode] is set to [On], you cannot connect the camera and the Smartphone. Set [Airplane

Mode] to [Off].

• RAW images are converted to JPEG format when they are sent.

• You cannot send AVCHD format movies.

Notes

viiiGB

About the

NEX-5T

Index

(NEX-5T)

Smart Remote Embedded

You can use a Smartphone as the remote controller for the camera, and shoot still

images. Still images shot via remote control are sent to the Smartphone from the camera.

Download and install the application “PlayMemories Mobile” from your Smartphone’s

application store.

If “PlayMemories Mobile” is already installed on your Smartphone, be sure to update it

to the latest version.

For details on “PlayMemories Mobile,” refer to the support page (http://www.sony.net/

pmm/).

To send images to an iPhone, or to an Android Smartphone without the NFC function,

refer to “Launching [Smart Remote Embedded] without using One-touch remote.”

With a one-touch operation, you can connect the camera to an NFC-enabled Android

Smartphone, and operate the camera and shoot still images remotely using the

Smartphone as a controller (One-touch remote).

• When [Airplane Mode] is set to [On], you cannot connect the camera and the Smartphone. Set [Airplane

Mode] to [Off].

Launching [Smart Remote Embedded] using

One-touch remote

1Activate the NFC function of the Smartphone.

2Switch the camera to shooting mode.

3Touch the Smartphone to the camera,

aligning both N marks.

The Smartphone and the camera are connected, and

“PlayMemories Mobile” launches. On the camera,

[Smart Remote Embedded] launches.

• The NFC function is available only when the (N mark) is displayed on the camera.

• Touch the Smartphone to the camera for more than two seconds until “PlayMemories Mobile”

launches.

• If you cannot find an N mark on the Smartphone, confirm the touch-point by referring to the

instruction manual of the Smartphone.

• If [Smart Remote Embedded] does not launch, first select [Smart Remote Embedded] under MENU

t[Setup] t[One-touch(NFC)].

Notes

Continued r

ixGB

About the

NEX-5T

Index

(NEX-5T)

Check the composition of the image on the Smartphone screen, and then press the shutter

button (A) on the Smartphone to shoot an image.

• Use button (B) to change the [EV], [Self-Timer] and [Review Check] settings.

• [Smart Remote Embedded] is available when the shooting mode is set to [Intelligent Auto], [Scene

Selection], [Manual Exposure], [Shutter Priority], [Aperture Priority] or [Program Auto]. When the

shooting mode is set to a mode other than the modes above, it is automatically switched to [Intelligent

Auto].

• [Smart Remote Embedded] is not available for movie shooting.

• When [Quality] is set to [RAW] or [RAW & JPEG], it is automatically changed to [Fine].

• If a memory card is not inserted in the camera, you can shoot still images and send them to a Smartphone.

However, the images shot will not be saved on the camera.

Launching [Smart Remote Embedded] without

using One-touch remote

1MENU t[Application] t[Smart Remote Embedded].

2When the camera is ready for the

connection, an information screen appears

on the camera. Connect the Smartphone

and the camera using that information.

[For Android]

[For iPhone]

Operating the camera using [Smart Remote

Embedded]

Notes

Autres manuels pour NEX-5T

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sony Appareil photo numérique

Sony

Sony CD Mavica MVC-CD500 Manuel utilisateur

Sony

Sony Cyber-shot DSC-S600 Manuel utilisateur

Sony

Sony Cyber-shot DSC-TX20 Manuel utilisateur

Sony

Sony a6600 Guide de l'utilisateur

Sony

Sony PXW-FS7 Manuel utilisateur

Sony

Sony Cyber-shot DSC-W730 Manuel d'instructions d'installation

Sony

Sony Cyber-shot DSC-RX1RM2 Manuel utilisateur

Sony

Sony Cyber-shot DSC-S600 Manuel utilisateur

Sony

Sony DSC-T2/B Manuel utilisateur

Sony

Sony DSC-TX30 Manuel utilisateur

Sony

Sony DSLR-A100K - alpha; Digital Single Lens Reflex... Manuel utilisateur

Sony

Sony Alpha 6600 Manuel utilisateur

Sony

Sony Alpha 7RV Manuel utilisateur

Sony

Sony MVC-CD350 - Digital Still Camera Mavica Cd... Manuel utilisateur

Sony

Sony Cyber-shot DSC-HX10 Manuel utilisateur

Sony

Sony Cyber-shot DSC-HX10 Manuel utilisateur

Sony

Sony DSC-W120/P Manuel utilisateur

Sony

Sony PXW-FS7 Manuel utilisateur

Sony

Sony Cyber-shot AC-UB10 Manuel utilisateur

Sony

Sony a7 RV Guide de l'utilisateur

Sony

Sony HVL-S3D Manuel d'instructions d'installation

Sony

Sony DSC-HX400 Manuel utilisateur

Sony

Sony Cyber-shot DSC-S600 Manuel utilisateur

Sony

Sony DSC-W35 Cyber-shot® Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur

Nikon

Nikon Coolpix 100 Manuel utilisateur

Samsung

Samsung SCC-C4253 Manuel utilisateur

JVC

JVC GT-HM890 Manuel utilisateur
