Sony DSLR-A700 Manuel utilisateur

DSLR-A700 3-216-919-11 (1)

3-216-919-11 (1)

Printed on 70% or more recycled paper using VOC

(Volatile Organic Compound)-free vegetableoil based ink.

Additional information on this product and

answers to frequently asked questions can be

found at our Customer Support Website.

DSLR-A700

Digital Single Lens Reflex Camera

Read This First

Operating Instructions

Before operating the unit, please read this manual and “User’s Guide/Troubleshooting”

(separate volume) thoroughly, and retain them for future reference.

Checking the accessories supplied

The number in parentheses indicates the number of pieces.

• BC-VM10 Battery charger (1) • Video cable (1)

• Power cord (mains lead) (1) • Shoulder strap with eyepiece cover and

Remote Commander clip (1)

• Rechargeable battery pack NP-FM500H (1)

• Wireless Remote Commander (Remote

Commander) (1)

• USB cable (1)

• Body cap (1) (Attached on the camera)

• Accessory shoe cap (1) (Attached on the

camera)

• Eyecup (1) (Attached on the camera)

• CD-ROM (Application Software for α

camera) (1)

• Operating instructions: “Read This First” (this

manual) (1)

• Operating instructions: “User’s Guide/

Troubleshooting” (1)

Composition of the operating instructions

This manual

Explains the set-up and basic operations for shooting/playback with your camera.

Prepare the camera and shoot images easily.

Checking the accessories supplied ............................................................................ 2

1 Prepare the battery pack ......................................................................................... 4

2 Attach a lens ........................................................................................................... 6

3 Insert a memory card (not supplied)....................................................................... 8

4 Turn the camera on/set the clock .......................................................................... 10

5 Shoot images easily (Auto adjustment mode) ...................................................... 12

The number of images that can be recorded.................................................. 13

Holding the camera........................................................................................ 13

Super SteadyShot function ............................................................................ 14

Focus.............................................................................................................. 15

Using the flash ............................................................................................... 16

Adjusting the diopter ..................................................................................... 17

6 View/delete images............................................................................................... 18

“User’s Guide/Troubleshooting” (separate volume)

Get more friendly with your camera

•Shoot with your favorite settings tUsing the shooting functions

•Playback with your favorite settings tUsing the viewing functions

•Enjoy various shooting/playback functions using the menu tUsing the menu

Connect your camera to a PC or a printer

•Copy your images to a computer and enjoy editing them in various ways

tUsing your computer

•Print images by connecting your camera directly to a printer

(PictBridge compliant printers only) tPrinting images

Prepare the battery pack

• Connect the battery charger to an easily accessible wall outlet (wall socket) close by.

• Even if the CHARGE lamp is not lit, the battery charger is not disconnected from the AC power source

(mains) as long as it is connected to the wall outlet (wall socket). If some trouble occurs while using the

battery charger, immediately shut off the power by disconnecting the plug from the wall outlet (wall

socket).

• When charging is finished, disconnect the power cord (mains lead) from the wall outlet (wall socket), and

remove the battery pack from the battery charger.

• Time required to charge a fully depleted battery pack (supplied) at a temperature of 25°C (77°F). Charging

may take longer under certain circumstances or conditions.

Full charge Normal charge

Approx. 235 min. Approx. 175 min.

1Insert the battery pack.

Push the battery pack until it clicks.

2Connect the power cord (mains lead).

Power cord (mains lead) 3To wall

outlet (wall

socket)

Battery

charger

CHARGE lamp

Light on: Charging

Light off: Completed (Normal Charge)

If you continue charging the battery pack for approximately one more hour, until it is fully

charged (Full Charge), the battery life will be slightly longer.

4Insert the charged battery pack.

While sliding the battery

cover open lever, open

the battery cover.

Firmly insert the battery pack all

the way while pressing the lock

lever with the tip of the battery.

Close the cover.

Lock lever

Note on the battery pack

Use only an NP-FM500H battery pack. Note that the NP-FM55H, NP-FM50 and NP-FM30

cannot be used.

Using the AC Adaptor/charger

You can connect the camera to a wall outlet (wall socket) using the AC-VQ900AM

AC Adaptor/charger (not supplied). t“User’s Guide/Troubleshooting” (page 165)

To check the remaining battery level

To remove the battery pack

Slide the lock lever in the direction of the arrow. Be careful not to drop the battery pack.

Before removing the battery pack, check that the power is turned off.

To use your camera abroad — Power sources

You can use your camera and the battery charger and the AC-VQ900AM AC Adaptor/charger

(not supplied) in any country or region where the power supply is within 100 V to 240 V AC,

50/60 Hz. Use a commercially available AC plug adaptor [a], if necessary, depending on the

design of the wall outlet (wall socket) [b].

Set the POWER switch to ON and check the level on

the LCD monitor. The level is indicated with the

percent figures.

• The displayed level may not be correct under certain

circumstances.

Battery level “Battery exhausted”

High Low You cannot shoot any more

pictures.

•Do not use an electronic transformer (travel

converter), as this may cause a malfunction.

LCD monitor

Lock lever

Attach a lens

1Remove the body cap from the camera and the rear cap from

the lens.

•Make sure not to leave the interior of the camera exposed to dust or water

droplets.

If dust enters the camera, perform [Cleaning mode] (t“User’s Guide/Troubleshooting” (page

125)) and brush the dust away using a commercially available blower brush.

2Attach the lens.

• When attaching a lens, do not press the lens release button.

• Do not use force when attaching a lens.

• When shooting without the flash, using a lens hood is recommended to prevent unnecessary

light from affecting your images. For details on attaching the lens hood, refer to the operating

instructions supplied with the lens.

Body cap Rear cap

Mount the lens by aligning the orange

index marks on the lens and camera.

Turn the lens clockwise until it

clicks into the locked position.

Orange index marks

To remove the lens

Press the lens release button all the way in and turn the lens counterclockwise until it stops.

• Replace the cap on the lens and attach the body cap (or another lens) to the camera after removing the lens.

Keep dust from getting inside the camera when changing lenses!

If dust or debris gets inside the camera and lands on the surface of the image sensor (the

part that acts as the film), it may appear on the image, depending on the shooting

environment.

The camera is equipped with an anti-dust function to prevent dust from landing on the

image sensor. However, take note of the following reminders when attaching/removing a

lens.

• Avoid changing lenses in a dusty location.

• When storing the camera, always attach a lens or the body cap.

• When attaching the body cap, remove all the dust from the cap before placing it on the camera.

If dust or debris gets inside the camera, select [Cleaning mode] in the Setup menu, and

use a commercially available blower brush to clean the image sensor. t“User’s Guide/

Troubleshooting” (page 125)

Lens release button

Insert a memory card (not supplied)

Available memory cards for the camera

You can use a “Memory Stick Duo”, CompactFlash card (CF card), or Microdrive as a

memory card.

• Before using a memory card, be sure to format it using this camera. Otherwise, satisfactory performance

may not be obtained. t“User’s Guide/Troubleshooting” (page 115)

• For more information about the memory card t“User’s Guide/Troubleshooting” (page 161)

Insert a memory card

• Be careful not to pinch your fingers when opening the cover.

• Straight insert a memory card by pressing the center of the memory card. Do not press the edges of the

memory card.

• Be careful about insertion direction of a memory card. Inserting a memory card in a wrong direction may

cause a malfunction.

“Memory Stick Duo” CompactFlash/

Microdrive

Insert a memory card all the way in until it

clicks.

Terminal side

Close the cover.

Front side

Open the memory card cover.

Terminal side

Insert a memory card from the terminal

side (the terminal side has a number of

small holes).

“Memory Stick Duo”

CompactFlash/Microdrive

Terminal side

Wrong directions

When shooting using a “Memory Stick Duo”

You must set [Memory card] to [Memory Stick] in the Setup menu. Follow the procedure

below after turning on the camera.

1Press MENU.

2Set up using the multi-selector.

3Press MENU to turn off the menu.

To remove the memory card

CompactFlash/Microdrive

We have checked the operations, however, we cannot guarantee proper operation of all CF

cards/Microdrives.

• The Microdrive is a compact and lightweight hard disk drive that complies with CompactFlash Type II

standards. For more information about the CompactFlash/Microdrive t“User’s Guide/

Troubleshooting” (page 162)

1Open the memory card cover.

2 “Memory Stick Duo”:

Push the “Memory Stick Duo” once.

CompactFlash/Microdrive:

Push down the CF card eject lever.

• The memory card may be hot just after it has been used. Be

careful when you handle it.

When the access lamp is lit

Never remove the memory card or the battery pack, or turn

off the power. The data may be corrupted.

Multi-selector

MENU button

Move the multi-selector to the right to select

[]t[2], then press the center.

Move the multi-selector up and set [Memory

card] to [Memory Stick], then press the

center.

Access lamp

CF card eject lever

Turn the camera on/set the clock

1Set the POWER

switch to ON by

sliding it in the

direction of the

arrow.

2Set the clock with the multi-

selector.

1Verify that [OK] is selected, then press the center of

the multi-selector.

2Select each item with b/Band set the numeric value

with v/V.

3Repeat Step 2 to set other items.

• [YYYY/MM/DD] represents the order of year, month, and

day. You can change this order with v/V.

4Press the center of the multi-selector.

5After checking whether [OK] is selected, press the

center of the multi-selector.

• To cancel, press MENU.

The direction in which the multi-selector is moved is

expressed as v/V/b/B.

v: Move up

V: Move down

b: Move to the left

B: Move to the right Press the center

to execute.

• If you want to set the clock

later, select [Cancel] with V,

then press the center of the

multi-selector.

Autres manuels pour DSLR-A700

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sony Appareil photo numérique

Sony

Sony Cyber-shot DSC-T20 Manuel utilisateur

Sony

Sony Cyber-shot DSC-RX100 Manuel utilisateur

Sony

Sony DCR-SR220 Handycam® Manuel utilisateur

Sony

Sony DSC-W55BDL - Cyber-shot Digital Still Camera Manuel utilisateur

Sony

Sony ?9 Manuel utilisateur

Sony

Sony Cyber-shot DSC-S600 Manuel utilisateur

Sony

Sony DSLR-A390 - alpha; Digital Single Lens Reflex... Manuel utilisateur

Sony

Sony DSC-T7 Fall 2005 Manuel utilisateur

Sony

Sony Cyber-shot DSC-F828 Manuel utilisateur

Sony

Sony DSLR-A100 Manuel utilisateur

Sony

Sony Cyber-shot DSC-S600 Manuel utilisateur

Sony

Sony Cyber-shot DSC-WX800 Guide de référence

Sony

Sony FD Mavica MVC-FD200 Manuel utilisateur

Sony

Sony Cyber-shot DSC-T70 Manuel utilisateur

Sony

Sony DCR-HC65 - Digital Handycam Camcorder Manuel utilisateur

Sony

Sony DSC-WX60 Manuel utilisateur

Sony

Sony DXC-S500 Dessin dimensionnel

Sony

Sony Cyber-shot DSC-T110 Manuel utilisateur

Sony

Sony SRG-300SE Manuel utilisateur

Sony

Sony DSC S730 - Cyber-shot Digital Camera Manuel utilisateur

Sony

Sony PXW-FS7 Manuel utilisateur

Sony

Sony DSC-RX0M2 Manuel utilisateur

Sony

Sony DSC-TX1 Cyber-shot® Manuel utilisateur

Sony

Sony ZV-E1 Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur

Nikon

Nikon Coolpix 100 Manuel utilisateur

Samsung

Samsung SCC-C4253 Manuel utilisateur

JVC

JVC GT-HM890 Manuel utilisateur
