Sony DSC-HX60 Manuel utilisateur

4-529-918-11(1)

DSC-HX60/HX60V

Digital Still Camera

Instruction Manual

This camera is equipped with a built-in instruction guide.

In-Camera Guide

The camera displays explanations for MENU/Fn (Function) items and the

setting values.

1Press the MENU button or the Fn (Function) button.

2Select the desired item, then press the (In-Camera Guide) button.

Shooting Tip

The camera displays shooting tips for the shooting mode selected.

1Press the (In-Camera Guide) button in shooting mode.

2Select the desired shooting tip, then press zon the control wheel.

The shooting tip is displayed.

• You can scroll the screen using v/Vand change shooting tips using b/B.

English

Learning more about the camera (“Help Guide”)

“Help Guide” is an on-line manual. Refer to it for in-depth

instructions on the many functions of the camera.

1Access the Sony support page.

http://www.sony.net/SonyInfo/Support/

2Select your country or region.

3Search for the model name of your camera within the

support page.

• Check the model name on the bottom of your camera.

Viewing the Guide

(In-Camera Guide)

Fn (Function)

Owner’s Record

The model and serial numbers are located on the bottom. Record the serial number in the

space provided below. Refer to these numbers whenever you call your Sony dealer

regarding this product.

Model No. DSC-HX60/DSC-HX60V

Serial No. _____________________________

Model No. AC-UB10C/AC-UB10D

Serial No. _____________________________

To reduce fire or shock hazard, do not expose the unit to rain or

moisture.

IMPORTANT SAFETY INSTRUCTIONS

-SAVE THESE INSTRUCTIONS

DANGER

TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, CAREFULLY FOLLOW THESE

INSTRUCTIONS

If the shape of the plug does not fit the power outlet, use an attachment plug adaptor of the

proper configuration for the power outlet.

[Battery pack

If the battery pack is mishandled, the battery pack can burst, cause a fire or even chemical

burns. Observe the following cautions.

• Do not disassemble.

• Do not crush and do not expose the battery pack to any shock or force such as

hammering, dropping or stepping on it.

• Do not short circuit and do not allow metal objects to come into contact with the battery

terminals.

• Do not expose to high temperature above 60°C (140°F) such as in direct sunlight or in a

car parked in the sun.

• Do not incinerate or dispose of in fire.

• Do not handle damaged or leaking lithium ion batteries.

WARNING

CAUTION

• Be sure to charge the battery pack using a genuine Sony battery charger or a device that

can charge the battery pack.

• Keep the battery pack out of the reach of small children.

• Keep the battery pack dry.

• Replace only with the same or equivalent type recommended by Sony.

• Dispose of used battery packs promptly as described in the instructions.

[AC Adaptor

Use the nearby wall outlet (wall socket) when using the AC Adaptor. Disconnect the AC

Adaptor from the wall outlet (wall socket) immediately if any malfunction occurs while

using the apparatus.

[RECYCLING LITHIUM-ION BATTERIES

Lithium-Ion batteries are recyclable.

You can help preserve our environment by returning your used

rechargeable batteries to the collection and recycling location nearest

you.

For more information regarding recycling of rechargeable batteries,

call toll free

1-800-822-8837, or visit http://www.call2recycle.org/

Caution: Do not handle damaged or leaking Lithium-Ion batteries.

[Battery pack

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

CAN ICES-3 B/NMB-3 B

This equipment complies with FCC/IC radiation exposure limits set forth for an

uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines

in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules.

This equipment has very low levels of RF energy that are deemed to comply without

testing of specific absorption ratio (SAR).

For Customers in the U.S.A. and Canada

If you have any questions about this product, you may call:

Sony Customer Information Center

1-800-222-SONY (7669)

The number below is for the FCC related matters only.

[Regulatory Information

This equipment must not be co-located or operated in conjunction with any other antenna

or transmitter.

[CAUTION

You are cautioned that any changes or modifications not expressly approved in this manual

could void your authority to operate this equipment.

[Note:

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

The supplied interface cable must be used with the equipment in order to comply with the

limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules.

For Customers in the U.S.A.

Declaration of Conformity

Trade Name: SONY

Model No.: DSC-HX60V

Responsible Party: Sony Electronics Inc.

Address: 16530 Via Esprillo,

San Diego, CA 92127 U.S.A.

Telephone No.: 858-942-2230

This device complies with Part15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may cause

undesired operation.

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including interference that

may cause undesired operation of the device.

[Notice for the customers in the countries applying EU Directives

Manufacturer: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan

For EU product compliance: Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327

Stuttgart, Germany

Hereby, Sony Corporation, declares that this equipment is in compliance with the essential

requirements and other relevant provisions of Directive 1999/5/EC. For details, please

access the following URL:

http://www.compliance.sony.de/

[Notice

If static electricity or electromagnetism causes data transfer to discontinue midway (fail),

restart the application or disconnect and connect the communication cable (USB, etc.)

again.

This product has been tested and found compliant with the limits set out in the EMC

regulation for using connection cables shorter than 3 meters (9.8 feet).

The electromagnetic fields at the specific frequencies may influence the picture and sound

of this unit.

For Customers in Canada

For Customers in Europe

[Disposal of waste batteries and electrical and electronic

equipment (applicable in the European Union and other

European countries with separate collection systems)

This symbol on the product, the battery or on the packaging indicates that

the product and the battery shall not be treated as household waste. On

certain batteries this symbol might be used in combination with a

chemical symbol. The chemical symbols for mercury (Hg) or lead (Pb) are

added if the battery contains more than 0.0005% mercury or 0.004% lead.

By ensuring these products and batteries are disposed of correctly, you

will help prevent potentially negative consequences for the environment and human health

which could otherwise be caused by inappropriate waste handling. The recycling of the

materials will help to conserve natural resources.

In case of products that for safety, performance or data integrity reasons require a

permanent connection with an incorporated battery, this battery should be replaced by

qualified service staff only. To ensure that the battery and the electrical and electronic

equipment will be treated properly, hand over these products at end-of-life to the

applicable collection point for the recycling of electrical and electronic equipment. For all

other batteries, please view the section on how to remove the battery from the product

safely. Hand the battery over to the applicable collection point for the recycling of waste

batteries. For more detailed information about recycling of this product or battery, please

contact your local Civic Office, your household waste disposal service or the shop where

you purchased the product or battery.

The number in parentheses indicates the number of pieces.

• Camera (1)

• Rechargeable Battery Pack NP-BX1 (1)

• Micro USB Cable (1)

• AC Adaptor AC-UB10C/UB10D (1)

• Power Cord (mains lead) (not supplied in the USA and Canada) (1)

• Wrist Strap (1)

• Shoe Cap (1) (Attached on the camera)

• Instruction Manual (this manual) (1)

• Wi-Fi Connection/One-touch (NFC) Guide (1)

This guide explains the functions that require a Wi-Fi connection.

For Customers in Singapore

Checking the supplied items

AExposure compensation dial

BON/OFF (Power) button

CShutter button

DFor shooting: W/T (zoom) lever

For viewing: (Index) lever/

(Playback zoom) lever

ESelf-timer lamp/AF illuminator

FMode dial

(Intelligent Auto)/

(Superior Auto)/

(Program Auto)/

(Aperture Priority)/

(Shutter Priority)/

(Manual Exposure)/

(Memory recall)/

(Movie)/ (iSweep

Panorama)/ (Scene

Selection)

GMulti interface shoe*

HFlash

• Press the (Flash pop-up)

button to use the flash. The flash

does not pop up automatically.

• When not using the flash, press it

back into the camera body.

IMicrophone

JSpeaker

KLens

A(Flash pop-up) button

B(N Mark)

• Touch the mark when you

connect the camera to a

smartphone equipped with the

NFC function.

• NFC (Near Field

Communication) is an

international standard of the

short-range wireless

communication technology.

CLCD screen

DMOVIE (Movie) button

E(Playback) button

FControl wheel

GGPS receiver (built-in, DSC-

HX60V only)

HCharge lamp

IMulti/Micro USB Terminal*

• Supports Micro USB compatible

device.

JWi-Fi sensor (built-in)

KHook for Wrist Strap

Identifying parts

LMENU button

M(In-Camera Guide)/

(Delete) button

NFor shooting: Fn (Function)

button

For viewing: (Send to

Smartphone) button

ABattery insertion slot

BMemory card slot

CAccess lamp

DBattery eject lever

EBattery/Memory card cover

FHDMI micro jack

GTripod socket hole

• Use a tripod with a screw less

than 5.5 mm (7/32 inches) long.

Otherwise, you cannot firmly

secure the camera, and damage to

the camera may occur.

* For details on compatible accessories

for the multi interface shoe and the

Multi/Micro USB Terminal, visit the

Sony web site, or consult your Sony

dealer or local authorized Sony

service facility. You can also use

accessories that are compatible with

the accessory shoe. Operations with

other manufacturers’ accessories are

not guaranteed.

Inserting the battery pack

1Open the cover.

2Insert the battery pack.

• While pressing the battery eject lever, insert the battery pack as

illustrated. Make sure that the battery eject lever locks after insertion.

• Closing the cover with the battery inserted incorrectly may damage the

camera.

Battery eject lever

Autres manuels pour DSC-HX60

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sony Appareil photo numérique

Sony

Sony DSC S730 - Cyber-shot Digital Camera Manuel utilisateur

Sony

Sony DSC-WX300 Manuel utilisateur

Sony

Sony DSC-P2 - Cyber-shot Digital Still Camera Manuel utilisateur

Sony

Sony MVC-CD300 Manuel utilisateur

Sony

Sony Alpha NEX-6 Manuel utilisateur

Sony

Sony Cyber-shot DSC-W730 Manuel utilisateur

Sony

Sony BKP-5976 Manuel utilisateur

Sony

Sony Cyber-shot DSC-TF1 Manuel utilisateur

Sony

Sony Cyber-shot DSC-TX9 Manuel utilisateur

Sony

Sony Cybershot,cyber-shot dsc-tx100v Manuel utilisateur

Sony

Sony DSC-W350 Cyber-shot® Manuel utilisateur

Sony

Sony Cyber-shot DSC-W510 Manuel utilisateur

Sony

Sony Cyber-shot DSC-S600 Manuel utilisateur

Sony

Sony FD Mavica MVC-FD75 Manuel utilisateur

Sony

Sony Cyber-shot DSC-W370 Manuel utilisateur

Sony

Sony Handycam DCR-SX22E Manuel d'instructions d'installation

Sony

Sony Cyber-Shot DSC-P32 Manuel utilisateur

Sony

Sony DSLR-A200 (DSLR-A200) Manuel utilisateur

Sony

Sony Cyber-shot DSC-W730 Manuel d'instructions d'installation

Sony

Sony RX100 VI Guide d'installation

Sony

Sony MHS-FS1 Manuel utilisateur

Sony

Sony Cyber-shot DSC-HX10 Manuel utilisateur

Sony

Sony Cybershot,cyber-shot dsc-w570 Manuel utilisateur

Sony

Sony ILCE-3000K Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur

Nikon

Nikon Coolpix 100 Manuel utilisateur

Samsung

Samsung SCC-C4253 Manuel utilisateur

JVC

JVC GT-HM890 Manuel utilisateur
