3-862-563-21 (1)

1998 by Sony Corporation

CDP-CX240

CDP-CX220

Compact Disc

Player

Operating Instructions

Mode d’emploi

Manual de instrucciones

2EN

Welcome!

Thank you for purchasing the Sony

Compact Disc Player. Before operating

the unit, please read this manual

thoroughly and retain it for future

reference.

About This Manual

The instructions in this manual are for

models CDP-CX240 and CDP-CX220.

The CDP-CX240 is the model used for

illustration purposes.

Any difference in operation is clearly

indicated in the text, for example,

“CDP-CX240 only.”

Conventions

• Instructions in this manual describe

the controls on the player.

You can also use the controls on the

remote if they have the same or

similar names as those on the player.

• The following icons are used in this

manual:

Indicates that you can do the

task using the remote.

Indicates hints and tips for

making the task easier.

This equipment is intended for home

entertainment purposes only. The

warranty shall be invalidated if used

in commercial environments, such as

by disc jockeys, etc., even within the

Warranty Period.

WARNING

To prevent fire or shock

hazard, do not expose the unit

to rain or moisture.

To avoid electrical shock, do

not open the cabinet. Refer

servicing to qualified

personnel only.

The laser component in this product

is capable of emitting radiation

exceeding the limit for Class 1.

This appliance is classified as a CLASS 1

LASER product. The CLASS 1 LASER

PRODUCT MARKING is located on the

rear exterior.

The following caution label is located

inside of the unit.

WARNING

To prevent shock hazard, do not insert

the plug cut off from the mains lead into

a socket outlet. This plug cannot be used

and should be destroyed.

For the customers in Canada

CAUTION

TO PREVENT ELECTRIC SHOCK,

DO NOT USE THIS POLARIZED AC

PLUG WITH AN EXTENSION

CORD, RECEPTACLE OR OTHER

OUTLET UNLESS THE BLADES

CAN BE FULLY INSERTED TO

PREVENT BLADE EXPOSURE.

3EN

TABLE OF CONTENTS

Getting Started

Unpacking............................................................................................................................ 4

Hooking Up the System..................................................................................................... 4

Connecting Another CD Player (CDP-CX240 only) ...................................................... 6

Inserting CDs....................................................................................................................... 7

Playing a CD......................................................................................................................... 10

Playing CDs

Using the Display ............................................................................................................ 12

Locating a Specific Disc .................................................................................................. 13

Specifying the Next Disc to Play ................................................................................... 15

Locating a Specific Track or a Point in a Track ............................................................ 15

Playing Repeatedly........................................................................................................... 16

Playing in Random Order (Shuffle Play) ...................................................................... 16

Creating Your Own Program (Program Play).............................................................. 17

Playing Using a Timer (CDP-CX240 only) .................................................................... 19

Controlling Another CD Player (Advanced Mega Control) (CDP-CX240 only)..... 20

Fading In or Out (CDP-CX240 only).............................................................................. 21

Playing Alternately (No-Delay Play/X-Fade Play) (CDP-CX240 only) ................... 22

Storing Information About CDs (Custom Files)

What You Can Do With the Custom Files .................................................................... 23

Labeling Discs (Disc Memo)............................................................................................ 23

Storing Custom File Information Using a keyboard (CDP-CX240 only).................. 26

Storing Specific Tracks (Delete Bank) ............................................................................ 26

Grouping Discs (Group File)........................................................................................... 27

Storing Your Favorite Tracks (Hit List) (CDP-CX240 only) ....................................... 28

Additional Information

Precautions ........................................................................................................................ 30

Notes on CDs..................................................................................................................... 30

Troubleshooting ................................................................................................................ 31

Specifications ..................................................................................................................... 31

Index.......................................................................................................................................... 32

Getting Started

4EN

Getting Started

Hooking Up the System

Overview

This section describes how to hook up the CD player to

an amplifier. Be sure to turn off the power of each

component before making the connections.

Unpacking

Check that you received the following items:

• Audio cord (1)

• Monaural (2P) mini-plug cord (connecting cord for

CONTROL A1) (1) (supplied for Canadian models

only)

• Remote commander (remote) (1)

• Sony SUM-3 (NS) batteries (2)

• CD booklet holders (2) and label (1)

How to use the CD booklet holder

The CD booklet holder helps you locate the disc easily.

After you have inserted discs into the player, you can put

the CD booklet (which comes with a CD) into the

supplied holder. Put two CD booklets facing back to back

into a pocket. Stick the number label on each pocket,

matching the number of the disc slot where you have

inserted the disc. You can put up to 200 CD booklets into

the holders.

Inserting batteries into the remote

You can control the player using the supplied remote.

Insert two size AA (R6) batteries by matching the +

and – on the batteries to the diagram inside the battery

compartment.

Insert the negative (–) end first, then push in and down

until the positive (+) end clicks into position.

When using the remote, point it at the remote sensor g

on the player.

What cords will I need?

Audio cord (1) (supplied)

White

(L)

Red

(R)

White

(L)

Red

(R)

When to replace batteries

With normal use, the batteries should last for about six

months. When the remote no longer operates the player,

replace all the batteries with new ones.

Notes

• Do not leave the remote near an extremely hot or humid

place.

• Do not drop any foreign object into the remote casing,

particularly when replacing the batteries.

• Do not expose the remote sensor to direct sunlight or

lighting apparatuses. Doing so may cause a malfunction.

• If you do not use the remote for an extended period of time,

remove the batteries to avoid possible damage from battery

leakage and corrosion.

CD player

DIGITAL OUT

(OPTICAL)

COMMAND

MODE

S-LINK/

CONTROL A1

Amplifier

To line output (L) To line output (R)

To an AC outlet

: Signal flow

To audio input

To an AC outlet

Playing CDsGetting Started

Getting Started

5EN

Hookups

When connecting the audio cord, be sure to match the

color-coded cord to the appropriate jacks on the

components: Red (right) to Red and White (left) to

White. Be sure to make connections firmly to avoid

hum and noise.

CD player Amplifier

• If you have a digital component such as a digital

amplifier, D/A converter, DAT or MD

Connect the component via the DIGITAL OUT (OPTICAL)

connector using an optical cable (not supplied). Take off the

cap and plug in the optical cable.

POC-15

Optical cable (not supplied)

CD player Digital component

Note

When you connect via the DIGITAL OUT (OPTICAL)

connector, noise may occur when you play CD software

other than music, such as a CD-ROM.

If you have a Sony component with the CONTROL A1

jack

Connect the component via the CONTROL A1 jack. You

can simplify the operation of audio systems composed of

separate Sony components. For details, refer to the

supplementary “S-LinkTM/CONTROL-A1 Control

System” instructions.

When using another Sony CD player together with

this player

You can make the supplied remote effective only for this

player.

• When using the player equipped with the

COMMAND MODE selector:

Set the COMMAND MODE selector of this player to

CD 1 and that of another player to CD 2 or CD 3. Then

set the CD 1/2/3 switch on the remote supplied for

each player accordingly.

• When using the player not equipped with the

COMMAND MODE selector:

The command mode of the player without the

COMMAND MODE selector is set to CD 1. Set the

COMMAND MODE selector of this player to CD 2,

and set the CD 1/2/3 switch on the remote to CD 2.

Setting the voltage selector (voltage

selector equipped models only)

Check that the voltage selector on the rear panel of the

player is set to the local power line voltage. If not, set

the selector to the correct position using a screwdriver

before connecting the AC power cord to a wall outlet.

Connecting the AC power cord

Connect the AC power cord to a wall outlet.

Note on placement

Be sure to place the player on a horizontal place.

If the player is slanted, it may cause malfunction or

damage the player.

220 - 240 V110 - 120 V

LINE2ND CD

IN OUT

INPUT

DIGITAL OUT

OPTICAL

DIGITAL INPUT

OPTICAL

Getting Started

6EN

What cords will I need?

• Audio cord (1) (Use the cord supplied with the player to be

connected.)

• Monaural (2P) mini-plug cord (1) (supplied for Canadian

models only)

1Connect the players with an audio cord (see also

“Hookups” on page 5).

2Connect the players with a monaural (2P) mini-

plug cord.

Connecting Another CD Player

(CDP-CX240 only)

If you have a Sony CD player equipped with the

CONTROL A1 jack and the command mode of that

player can be set to CD 3, you can control that player as

the second player with this unit. After connecting this

unit and an amplifier, follow the procedure below.

Be sure to turn off the power of each player before

making this connection.

CDP-CX200, etc.

CDP-CX240

CDP-CX200, etc.

To an AC outlet

: Signal flow

To audio input

To LINE OUT

Amplifier

CDP-CX240

CDP-CX200, etc.

CDP-CX240

For details on this connection, refer to the

supplementary “S-LinkTM/CONTROL-A1 Control

System” instructions.

3Set the COMMAND MODE selector of each

player.

Set the COMMAND MODE selector of this player

to CD 1 or CD 2, and set that of the second player

to CD 3.

To an AC outlet

For details on how to operate the second player,

see “Controlling Another CD Player” on page 20

and “Playing Alternately” on page 22.

4Connect the AC power cord of both players to AC

outlets.

Notes

• Do not connect a player other than that you use as the

second player to the 2ND CD IN jacks of this player.

• When connecting a second CD player, do not connect the

DIGITAL OUT (OPTICAL) connector of this unit to the

amplifier.

COMMAND

MODE

To 2ND CD IN

To S-LINK/CONTROL A1

To audio output

LINE2ND CD

IN OUT

LINE OUT

CONTROL A1

S-LINK

CONTROL A1

COMMAND MODE

132

To CONTROL A1

Playing CDsGetting Started

Getting Started

7EN

Inserting CDs

You can insert up to 200 discs into this player.

I/u§OPEN/CLOSE JOG

1Press I/uto turn on the player.

2Open the front cover by pressing §OPEN/

CLOSE.

Rotary table

Loading position

Playing position

Disc slot at the loading position

Disc number

The disc number at the loading position appears in

the display.* If the disc has the Disc Memo (see

page 23), the Disc Memo appears instead of the

disc number. As you turn the JOG dial, the disc

number or the Disc Memo changes.

Disc number or the Disc Memo

You can classify discs into eight groups by using

the Group File function. This feature lets you easily

find the disc you want to play. For details, see

“Grouping Discs” on page 27.

* If you have already inserted discs, the disc number at

the playing position appears. When you turn the JOG

dial, the displayed disc number changes to the one at

the loading position.

ALL

*DISC-20*

DISCS

CD1

DISC

3Turn the JOG dial until you find the disc slot

where you want to insert a disc, while checking the

disc number (written beside every slot and also

indicated in the display).

(Continued)

Getting Started

8EN

The rotary table turns and the disc slot at the

loading position is set to the playing position.

Always close the front cover except when you

insert or remove discs.

5Repeat Steps 3 and 4 to insert more discs.

6Close the front cover by pressing §OPEN/

CLOSE.

With the label side

facing right

After inserting the disc, you can input the original

disc titles instead of the disc numbers (see

“Labeling Discs” on page 23) to locate it easily

when you start playing.

4Insert a disc with the label side facing right.

ALL DISCS

CD1

DISC

SONYHITS

The supplied CD booklet holders help you locate a

disc

You can store up to 200 CD booklets. Insert a booklet and

stick the number label on the film of a pocket and the

booklet so that you can locate the disc easily.

Notes

•Do not insert an empty 8 cm (3-inch) CD adaptor (CSA-8). It

may damage the player.

• Do not attach anything such as seals or sleeves to CDs. It

may damage the player or the disc.

• If you drop a disc into the player and the CD won’t go

into the slot correctly, consult your nearest Sony dealer.

• When transporting the player, remove all discs from the

player.

• Make sure you have inserted the disc into each slot at a

right angle to the rotary table. If the disc is not put in

straight, it may damage the player or the disc.

• Make sure the rotary table comes to a complete stop

before inserting or removing discs.

The front panel closes automatically when you press

·. Be careful not to put your hand into the player after

pressing ·otherwise your hand may be caught in the

front panel.

Playing CDsGetting Started

Getting Started

9EN

Removing CDs

After following Steps 1 to 3 of “Inserting CDs” on page

7, remove the discs. Then close the front cover.

Basic Operations

10EN

Playing a CD

•See pages 4 – 5 for the hookup

information.

•Make sure you have inserted the

discs correctly as indicated on

pages 7 – 8.

•You can play all the tracks on a

disc in the original order

(Continuous Play). You can also

play up to 200 discs

consecutively.

You can turn on the player

by pressing I/uon the

remote Z

Turn on the amplifier and select the CD player position.

Press I/uto turn on the player.

Press CONTINUE to select ALL DISCS or 1 DISC Continuous

Play mode.

Each time you press CONTINUE, “ALL DISCS” or “1 DISC”

appears in the display.

When you select

ALL DISCS

1 DISC

The player plays

All discs in the player consecutively in the order of

disc number. Empty disc slots are skipped.

Only one disc you have selected

Turn the JOG dial until the disc number or the Disc Memo (see

page 23) you want appears in the display to select the first disc

(ALL DISCS) or the disc you want (1 DISC).

4/5

ALL DISCS

CD1

DISC

*DISC-20*

STANDBY

I/ u

TIMER

OFF PLAY

KEY BOARD

KEYBOARD

CONTINUE

GROUP 1

GROUP 5

SHUFFLE

GROUP 2

GROUP 6

PROGRAM

GROUP 3

GROUP 7

REPEAT

GROUP 4

GROUP 8

TIME/TEXT

HIT LIST

GROUP FILE

MEGA CONTROL

FADER NO DELAY

X-FADE

MEMO SEARCH

INPUT

DISC/CHARACTER

PUSH ENTER

OPEN/CLOSE

AMS

CHECK CLEAR

Autres manuels pour CDP-CX220 - 200 Disc Cd Changer

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Sony Lecteur CD

Sony

Sony CDX-52RF Guide produit

Sony

Sony CFD-980 Operating Instructions (English,... Manuel utilisateur

Sony

Sony CD Walkman D-EJ100 Manuel utilisateur

Sony

Sony CDX-S2210 - Fm/am Compact Disc Player Guide produit

Sony

Sony CDP-C515 Manuel utilisateur

Sony

Sony VGP-XL1B - Vaio Digital Living System Media... Manuel utilisateur

Sony

Sony CDX-838 - Compact Disc Changer System Manuel utilisateur

Sony

Sony CFD-G35 - Cd Radio Cassette-corder Manuel utilisateur

Sony

Sony D-SJ01 - Sports Discman Manuel utilisateur

Sony

Sony CDP-XB630 Manuel utilisateur

Sony

Sony CDX-2500R Manuel utilisateur

Sony

Sony DVP-F5 - Portable Cd/dvd Player Manuel utilisateur

Sony

Sony CDX-3103 Guide produit

Sony

Sony Discman D-265 Manuel utilisateur

Sony

Sony MZ-R50 - MD Walkman MiniDisc Recorder Manuel utilisateur

Sony

Sony DVP-FX980 Manuel utilisateur

Sony

Sony Walkman D-E885 Manuel utilisateur

Sony

Sony CDP-XA20ES Manuel utilisateur

Sony

Sony D-NS921F ATRAC Guide Manuel utilisateur

Sony

Sony SCD-XE800 Manuel utilisateur

Sony

Sony CD Walkman D-EQ550 Manuel utilisateur

Sony

Sony DVP-FX1021 - Portable Dvd Player Manuel utilisateur

Sony

Sony CDP-391 - Compact Disc Player Manuel utilisateur

Sony

Sony CDX-656 - Compact Disc Changer System Manuel utilisateur

Manuels Lecteur CD populaires d'autres marques

RCA

RCA RP-7923 Manuel utilisateur

Pioneer

Pioneer DEH-P3550MP XM Manuel utilisateur

Philips

Philips AZ1207 Manuel utilisateur

Philips

Philips CD582 Manuel utilisateur

Philips

Philips AZ 6821 Manuel utilisateur

Lasonic

Lasonic MSU-2020 Manuel utilisateur

THOMSON

THOMSON RCD150 Manuel utilisateur

Denon

Denon DCD-1420 Manuel utilisateur

Panasonic

Panasonic SJ-MR100 Manuel utilisateur

Onkyo

Onkyo DX-7210 Manuel utilisateur

Denon

Denon DVM-4800 Manuel utilisateur

JBL

JBL MR-32 Manuel utilisateur

RCA

RCA RCD152 Manuel utilisateur

Technics

Technics SL-PS770A Manuel utilisateur

Clarion

Clarion compact disc Manuel utilisateur

Philips

Philips Expanium AZ 1538 Manuel utilisateur

Rotel

Rotel RCD 975 Manuel utilisateur

Pioneer

Pioneer CLD-D790 Manuel utilisateur
