Sony Ericsson Z520i Manuel utilisateur

This is the Internet version of the user's guide. © Print only for private use. 1

Contents

Getting started . . . . . . . . . . . . . . . . . . 4

Assemble the phone, SIM card, battery, make a call,

replace covers.

Getting to know your phone . . . . . . . . 9

Phone overview, use the menus, enter letters, activity

menu, and file manager.

Calling . . . . . . . . . . . . . . . . . . . . . . . . 18

Calls, contacts, voice control, call options.

Messaging . . . . . . . . . . . . . . . . . . . . . 34

Text messaging, picture messaging, voice messaging,

email, My friends.

Imaging . . . . . . . . . . . . . . . . . . . . . . . 43

Camera, video recorder, pictures, PhotoDJ™.

Entertainment . . . . . . . . . . . . . . . . . . 48

Media player, PlayNow™, ringtones, MusicDJ™,

VideoDJ™, sound recorder, themes, games.

Connectivity . . . . . . . . . . . . . . . . . . . . 56

Internet and email settings, synchronizing, Bluetooth,

infrared, and optional USB cable.

More features . . . . . . . . . . . . . . . . . . . 65

Time and date, alarm clock, calendar, tasks, Java™

applications, SIM card lock, etc.

Troubleshooting . . . . . . . . . . . . . . . . . 73

Why doesn’t the phone work the way I want?

Important information . . . . . . . . . . . . 77

Sony Ericsson Consumer Web site, safe and efficient

use, warranty, declaration of conformity.

Icons . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Icon descriptions.

Index . . . . . . . . . . . . . . . . . . . . . . . . . 88

Sony Ericsson Z520i

This is the Internet version of the user's guide. © Print only for private use.

Sony Ericsson

GSM 900/1800/1900

This user guide is published by Sony Ericsson Mobile

Communications AB, without any warranty.

Improvements and changes to this user guide

necessitated by typographical errors, inaccuracies

of current information, or improvements to programs

and/or equipment, may be made by Sony Ericsson

Mobile Communications AB at any time and without

notice. Such changes will, however, be incorporated

into new editions of this user guide.

©Sony Ericsson Mobile Communications AB, 2005

Publication number: EN/LZT 108 8066 R1A

Please note:

Some of the services in this user guide are not

supported by all networks. This also applies

to the GSM International Emergency Number 112.

Please contact your network operator or service

provider if you are in doubt whether you can use

aparticular service or not.

Please read the Guidelines for safe and efficient

use and the Limited warranty chapters before you

use your mobile phone.

Your mobile phone has the capability to download,

store and forward additional content, e.g. ringtones.

The use of such content may be restricted

or prohibited by rights of third parties, including but

not limited to restriction under applicable copyright laws.

You, and not Sony Ericsson, are entirely responsible

for additional content that you download to or forward

from your mobile phone. Prior to your use of any

additional content, please verify that your intended

use is properly licensed or is otherwise authorized.

Sony Ericsson does not guarantee the accuracy,

integrity or quality of any additional content or any

other third party content. Under no circumstances will

Sony Ericsson be liable in any way for your improper

use of additional content or other third party content.

The Bluetooth word mark and logos are owned by

the Bluetooth SIG, Inc. and any use of such marks

by Sony Ericsson is under license.

QuickShare™, PlayNow™, MusicDJ™, VideoDJ™

and Style-Up™ are trademarks or registered

trademarks of Sony Ericsson Mobile

Communications AB.

Microsoft, Windows and PowerPoint are either

registered trademarks or trademarks of Microsoft

Corporation in the U.S and other countries.

Mac OS is a trademark of Apple Computer, Inc.,

registered in the U.S. and other countries.

T9™ Text Input is a trademark or a registered

trademark of Tegic Communications.

T9™ Text Input is licensed under one or more

of the following: U.S. Pat. Nos. 5,818,437, 5,953,541,

This is the Internet version of the user's guide. © Print only for private use.

5,187,480, 5,945,928, and 6,011,554; Canadian Pat.

No. 1,331,057, United Kingdom Pat. No. 2238414B;

Hong Kong Standard Pat. No. HK0940329; Republic

of Singapore Pat. No. 51383; Euro.Pat. No. 0 842

463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE,

GB; and additional patents are pending worldwide.

Java and all Java based trademarks and logos

are trademarks or registered trademarks of Sun

Microsystems, Inc. in the U.S. and other countries.

End-user license agreement for Sun™ Java™ J2ME™.

1Restrictions: Software is confidential copyrighted

information of Sun and title to all copies is retained

by Sun and/or its licensors. Customer shall not

modify, decompile, disassemble, decrypt, extract,

or otherwise reverse engineer Software. Software

may not be leased, assigned, or sublicensed,

in whole or in part.

2Export Regulations: Software, including technical

data, is subject to U.S. export control laws, including

the U.S. Export Administration Act and its associated

regulations, and may be subject to export or import

regulations in other countries. Customer agrees

to comply strictly with all such regulations and

acknowledges that it has the responsibility to obtain

licenses to export, re-export, or import Software.

Software may not be downloaded, or otherwise

exported or re-exported (i) into, or to a national

or resident of, Cuba, Iraq, Iran, North Korea, Libya,

Sudan, Syria (as such listing may be revised from

time to time) or any country to which the U.S.

has embargoed goods; or (ii) to anyone

on the U.S. Treasury Department’s list of Specially

Designated Nations or the U.S. Commerce

Department’s Table of Denial Orders.

3Restricted Rights: Use, duplication or disclosure

by the United States government is subject to the

restrictions as set forth in the Rights in Technical

Data and Computer Software Clauses in DFARS

252.227-7013(c) (1) (ii) and FAR 52.227-19(c)

(2) as applicable.

Part of the software in this product is copyright

©SyncML initiative Ltd. (1999-2002). All rights

reserved.

Other product and company names mentioned herein

may be the trademarks of their respective owners.

Any rights not expressly granted herein are reserved.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

Assemble the phone, SIM card, battery,

make a call, replace covers.

More information and downloads are available

at www.SonyEricsson.com/support.

Instruction symbols

The following instruction symbols appear

in this user guide:

Assembling the phone

Before you can use your phone you need to:

• Insert the SIM card.

• Attach and charge the battery.

SIM card

When you register as a subscriber with a network

operator, you get a SIM (Subscriber Identity Module)

card. The SIM card contains a computer chip that

keeps track of your phone number, the services

included in your subscription, and names and

numbers in your contacts, among other things.

SIM card and battery

information

Always turn off the phone and detach the charger

before you insert or remove a SIM card.

Note

Indicates that a service or function is network-

or subscription-dependent. Contact your

network operator for details.

% See also page ...

} Use the selection keys or the navigation key to

scroll and select, %11 Keys and navigation.

Press the navigation key centre.

Press the navigation key up.

Press the navigation key down.

Press the navigation key to the left.

Press the navigation key to the right.

If you have been using a SIM card in another phone,

make sure that your information is saved to the SIM

card before you remove it from the other phone.

For example, contacts may have been saved in the phone

memory.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

To insert SIM card and battery

1Remove the battery cover by sliding it as shown

in the picture. You may need to apply significant

pressure the first time you remove the back cover.

2Slide the SIM card into its holder. Make sure

that the gold contacts of the SIM card are facing

down, and the cut off corner is correctly aligned.

3Place the battery on the back of the phone with

the label side up and the connectors facing each

other.

4Place the battery cover as shown in the picture

and slide it into place.

To charge the battery

1Connect the charger to the phone. The symbol

on the charger plug must face upwards.

2It may take up to 30 minutes before the battery

icon appears on the screen.

3Wait approximately 4 hours or until the battery

icon indicates that the battery is fully charged.

If you do not see the battery icon after this time,

press a key to activate the screen.

4Remove the charger by pulling it straight out.

It may take up to 30 minutes before the battery

icon appears when charging.

≈30 min.

≈4 h.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

You may need a PIN (Personal Identity Number)

to activate the services in your phone. The PIN

is associated with your SIM card, and not with

the phone. Your PIN is provided by your network

operator. When you enter your PIN, each digit

appears as *, unless your PIN starts with the same

digits as an emergency number, for example 112.

This is so that you can see and call an emergency

number without entering a PIN.

If you make a mistake while entering your PIN,

delete the number by pressing .

Turning on the phone

and making calls

Make sure that the phone is charged and your SIM

card is inserted before you turn it on. When you have

turned the phone on, you can use the setup wizard

to quickly and easily prepare your phone for use.

To turn on the phone

1Open the flip.

2Press and hold .

3Enter your SIM card PIN, if requested.

4At first start-up, select the language you want

for your phone menus.

Some functions use more battery power than others

and may cause a need for more frequent re-charging.

However, talk-time or standby time may become

noticeably shorter due to wear and you may have

to replace your battery. Only use approved batteries

from Sony Ericsson %80 Battery use and care.

If you enter the wrong PIN three times in a row,

the SIM card is blocked and the message PIN blocked

appears. To unblock it, you need to enter your PUK

(Personal Unblocking Key), %70 SIM card lock.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

5}Yes if you want the setup wizard to help you

get started, and follow the instructions that

appear. You can start the wizard from the menu

system at any time, }Settings }the General

tab }Setup wizard.

To make and receive calls

Enter the phone number (with international prefix

and area code if applicable) }Call to make the call.

}End call to end the call. When the phone rings

}Answer.

Replacing Style-Up™ covers

To replace the front cover

1Locate the notches along the sides of the front

cover, as shown.

2Use you thumbnail to lift the front cover

off the phone. It may be necessary to lift

up on both sides of the front cover.

3Locate the notches on the bottom of the front

cover and the slots on the bottom of the frame

of the phone.

4Place the notches into the slots and snap

the cover in place.

The setup wizard function is operator-dependent.

Some kits may include additional Style-Up™ covers.

Follow these intructions to replace covers.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

To replace the back cover

1Apply pressure with the heel of one hand while

pushing away with the thumb of your other hand.

You may need to apply significant pressure

the first time you remove the back cover.

2Slide the back cover away from the hinge.

3Remove the back cover.

4Locate the notches along each side of the phone.

Using the notches as a guide, slide the back

cover upward applying pressure with the heel

of your hand until it clicks in place.

This is the Internet version of the user's guide. © Print only for private use.

Getting to know your phone

Getting to know

your phone

Phone overview, use the menus, enter letters,

activity menu, and file manager.

Phone overview

12 13 14

15 16 17

1Ear speaker

2Screen

3, 5 Selection keys

4Navigation key

6Back key

7Clear key

8Power on/off

9Internet key

10 Microphone

11 Stereo headset and charger connector

12 Camera/video button

13 Vo l u m e

14 Infrared port

15 External display

16 Camera

17 Loudspeaker

This is the Internet version of the user's guide. © Print only for private use.

Getting to know your phone

Overview, menu

1. PlayNow™*

2. Internet services*

3. Entertainment

Games

VideoDJ™

PhotoDJ™

MusicDJ™

Remote control

Record sound

Demo tour

4. Camera

5. Messaging

Write new

Inbox

My friends*

Call voicemail

Drafts

Outbox

Sent messages

Saved messages

Templates

Settings

6. Media player

7. File manager

Pictures

Videos

Sounds

Themes

Web pages

Games

Applications

Other

8. Contacts**

Contacts**

Options:

Speed dial

My business card

Groups**

SIM contacts**

Special numbers

Advanced

New contact

9. Alarms

Alarm

Recurrent alarm

Alarm signal

10. Calls*

11. Organizer

Applications

Calendar

Tasks

Notes

Synchronization

Timer

Stopwatch

Calculator

Code memo

12. Settings

General

Profiles

Time & date

Language

Voice control

New events

Phone status

Shortcuts

Locks

Setup wizard

Tips and tricks

Master reset

Sounds & alerts

Ring volume

Ringtone

Silent mode

Increasing ring

Vibrating alert

Message alert

Light effects

Key sound

Display

Main wallpaper

External wallpaper

Themes

Start-up screen

Screen saver

Brightness

Sleep mode clock

Edit line names*

Calls

Divert calls

Switch to line 2*

Manage calls

Time & cost

Show or hide no.

Handsfree*

Connectivity

Bluetooth

Infrared port

Synchronization

Device mgmt.

Mobile networks

Data comm.

Internet settings

Streaming settings

Settings for Java™

Accessories

* Please note that some

menus are operator-, network-

and subscription-dependent.

** The menu depends

on which contacts application

is selected as default.

Autres manuels pour Z520i

Table des matières

Autres manuels Sony Ericsson Téléphone portable

Sony Ericsson

Sony Ericsson P900 Manuel utilisateur

Sony Ericsson

Sony Ericsson K800 Guide de référence rapide

Sony Ericsson

Sony Ericsson K510i Manuel utilisateur

Sony Ericsson

Sony Ericsson P990i Manuel utilisateur

Sony Ericsson

Sony Ericsson W800i Manuel utilisateur

Sony Ericsson

Sony Ericsson STICK MICRO W995 Manuel utilisateur

Sony Ericsson

Sony Ericsson Cyber-shot C905 Manuel utilisateur

Sony Ericsson

Sony Ericsson Cell Phone Manuel de service

Sony Ericsson

Sony Ericsson P1 Guide de référence rapide

Sony Ericsson

Sony Ericsson T280i Manuel utilisateur

Sony Ericsson

Sony Ericsson T616 Manuel utilisateur

Sony Ericsson

Sony Ericsson W660 Guide de référence rapide

Sony Ericsson

Sony Ericsson T200 Manuel utilisateur

Sony Ericsson

Sony Ericsson W700i Manuel utilisateur

Sony Ericsson

Sony Ericsson P800 Manuel utilisateur

Sony Ericsson

Sony Ericsson Z320 Manuel utilisateur

Sony Ericsson

Sony Ericsson S600 Guide de référence rapide

Sony Ericsson

Sony Ericsson W760 Manuel utilisateur

Sony Ericsson

Sony Ericsson K330 Manuel utilisateur

Sony Ericsson

Sony Ericsson G700 Manuel utilisateur

Sony Ericsson

Sony Ericsson G502c Manuel utilisateur

Sony Ericsson

Sony Ericsson Z712 Manuel utilisateur

Sony Ericsson

Sony Ericsson T300 Manuel utilisateur

Sony Ericsson

Sony Ericsson Aspen Mli Guide de référence rapide

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
