Sony Ericsson T610 Manuel utilisateur



Sony Ericsson T610

& Z600

Setup guide



                                   

                                                   

    ! " # $ % &  &  $      ' (       )  *     +         , 

              !                +         

'  (         (             - 



ETTING UP AN

RICSSON

T610

Z600

ANDSET

LIVE OVER

GPRS

Setting up the Internet Data

Account

It is important this data

account is created first.

This data account allows the

phone (when used with a PC)

to access the Internet via

Vodafone. The email client

also uses this.

•Scroll to Connectivity and press Select.

•Scroll to Data Comm. and press Select.

•Scroll to Data Accounts and press Select.

•Scroll to New Account and press Add.

•Scroll to GPRS Data and press Select.

•New Account, Name: will be displayed.

•Enter GPRS Internet and press Select.

•New GPRS Data will be displayed.

•Scroll to APN press Yes, enter www.vodafone.net.nz and press Select.

•Leave other settings as they are – blank or default settings.

•Scroll to Save? and press Select.

•New GPRS Data Account Created will be displayed.

Setting up V live Access

Please remember to switch

your phone off and back on

again after you have changed

any settings in the phone.

•Scroll to Connectivity and press Select.

•Scroll to Data Comm. and press Select.

•Scroll to Data Accounts and press Select.

•Scroll to New Account and press Add.

•Scroll to GPRS Data and press Select.

•New Account, Name: will be displayed.

•Enter VFNZ Gateway and press OK.

•New GPRS Data will be displayed.

•Scroll to APN press Edit,

•Enter live.vodafone.com and press OK.

•Leave other settings as they are – blank or default settings.

•Scroll to Save? and press Select.

•New GPRS Data Account Created will be displayed.

•Scroll to Connectivity and press Select.

•Scroll to WAP options and press Select.

•Scroll to WAP profiles and press Select.

•Scroll to New profile and press Add.

•Enter Vodafone Live and press OK.

•Scroll to Connect using, press Edit.

•Select VFNZ Gateway and press Select.

•Scroll to IP address and press Edit.

•Enter 172.030.038.003 and press OK

•Press Save.

•Scroll to Vodafone live press Edit.

•Scroll to Advanced press Select.

•Scroll to Change homepage press Select.

•Enter V live and press OK.

•Enter http://live.vodafone.com and press OK.

•Leave the Username and password blank.

•Scroll to Security and press Select. Select Off.

•Scroll to Show pictures and press Select. Select On.

•Press the Back button to return to Vodafone standby screen.

Special Note:

Your Ericsson

mobile may have been

preconfigured. If your phone

has Data Accounts already,

ignore the instructions on this

page.



ETTING UP AN

RICSSON

T610

Z600

OR USE WITH

LIVE OVER

GSM

ATA

Setting up a Data Account for

Vodafone live access via CSD

Using WAP via GSM Data

•Scroll to Connectivity and press Select.

•Scroll to Data Comm. and press Select.

•Scroll to Data Accounts and press Select.

•Scroll to New Account and press Add.

•Scroll to GSM Data and press Select.

•New Account, Name: will be displayed.

•Enter CSD WAP and press OK.

•Scroll to Phone number and press Edit.

•Enter +6421700747 press OK.

•Leave Username and password blank.

•Press Save.

•Scroll to Connectivity and press Select.

•Scroll to WAP options and press Select.

•Scroll to WAP profiles and press Select.

•Scroll to New profile and press Add.

•Enter WAP CSD and press OK.

•Scroll to Connect using, press Edit.

•Select CSD WAP and press Select.

•Scroll to IP address and press Edit.

•Enter 172.030.038.003 and press OK

•Press Save.

•Scroll to WAP CSD press Edit.

•Scroll to Advanced press Select.

•Scroll to Change homepage press Select.

•Enter Vodafone live and press OK.

•Enter http://live.vodafone.com and press OK.

•Leave the Username and password blank.

•Scroll to Security and press Select. Select Off.

•Scroll to Show pictures and press Select. Select On.

•Press the Back button to return to Vodafone standby screen.



ONFIGURING THE

ONY

RICSSON

T610

Z600

PXT



Setting up a Data Account for

PXT access via GPRS

•Scroll to Connectivity and press Select.

•Scroll to Data Comm. and press Select.

•Scroll to Data Accounts and press Select.

•Scroll to New Account and press Add.

•Scroll to GPRS Data and press Select.

•New Account, Name: will be displayed.

•Enter VFNZ PXT and press OK.

•New GPRS Data will be displayed.

•Scroll to APN press Edit,

•Enter live.vodafone.com and press OK.

•Leave other settings as they are – blank or default settings.

•Press Save.

•New GPRS Data Account Created will be displayed.

•Scroll to Messaging and press Select.

•Scroll to Picture and press Select.

•Scroll to Options and press Select.

•Scroll to WAP profile and press Select.

•Scroll to Create new and press Select.

•Enter Vodafone PXT and press OK.

•Scroll to Connect using and press Edit.

•Select VFNZ PXT

•Scroll to IP address and press Edit.

•Enter 172.030.038.003 and press OK

•Press Save.

•Press the Back button to return to the Options menu

•Scroll to message server and press select

•Enter http://pxt.vodafone.net.nz/pxtsend and press OK

•Press the Back button to return to Vodafone standby screen



ETTING UP THE

MAIL

LIENT

N AN

RICSSON

T610

Z600

Setting up a Data Account for

access to an ISP by dialup

access

This data account allows the

phone to directly call into an

ISP.

•With a POP and SMTP client built in, the Sony Ericsson is capable for sending

& receiving email directly.

•The first step is to set-up a data account but this time rather than configuring it

for Vodafone, you put in your Internet Service Provider’s (ISP.)

•Account Name : Your ISP’s name

•Phone Number : Your ISP’s dial-up number (include the area code)

•User ID : Your normal user name for your ISP

•Password : Your normal password for your ISP

•Once the Data Account is set-up, return to the main screen.

Setting up and using the

Email Client

•Scroll to Messaging and press Select.

•Scroll down to Email and press Select.

•Scroll down to Options and press Select.

•Scroll down to Edit Account and press Select.

•Select New Account and press Add.

•Enter a name for you Mail Account and press OK.

•Connect Using : Select the GPRS Internet Data Account

•Protocol : Select POP3

•Incoming Server : Contact your ISP if you are unsure

•Incoming Port : 110

•Mailbox : User Mail Accounts username

•Password : User Mail Accounts password

•Outgoing Server : Contact your ISP if you are unsure

•Outgoing Port : 25

•Email Address : Enter your full email address

•Download : Select Headers & Text or Headers Only

•From Name : Enter your full name

•Signature : No signature

•Copy Outgoing : Off

•Check interval : Off - Do not turn this on

•For Outgoing Server you can use smtp.vodafone.net.nz

•Once the Email settings are completed, go to Email (under Messages) and

from here you can compose new messages and check for new mail.

Using the E-mail Client GSM

Data

Use your ISP data account to

access the Internet – to then

access your ISP’s servers.

   .                     

           /      .   

           0    +       

1            (         

    .     2 

•If you wish to use GSM Data with the Email Client, it is simply a matter of

changing the Data Account – details are listed below.

•Scroll to Messaging and press Select.

•Scroll down to E-mail and press Select.

•Scroll down to Options and press Select.

•Scroll down to Edit Account and press Select.

•Select your Mail Account and press Select.

•Select Connect Using and change it to the data account for your ISP.

•If you are unable to communicate with the POP or SMTP servers, try changing

the addresses to their IP addresses instead.

Special Note:

Your Ericsson

mobile may have been

preconfigured. If your phone

has Data Accounts already,

ignore the instructions on
