SonicWALL CDP 3440i/4440i
Getting Started Guide
SonicWALL CDP 3440i/4440i Getting Started Guide Page 1
SonicWALL CDP 3440i / 4440i
Getting Started Guide
This Getting Started Guide contains installation procedures and configuration guidelines
for deploying a SonicWALL Continuous Data Protection (CDP) appliance into an existing
or new network.
The SonicWALL CDP appliance backs up data as changes occur and replicates them
first locally and then to a secure offsite location. This real-time data protection provides
the most current file and system backup possible. By combining the advantages of local
disk-based backup (fast recovery) with offsite backup*, the SonicWALL CDP appliance is
the first solution to eliminate - not just mitigate - exposure to threats of data loss.
Please read this entire Getting Started Guide before setting up your
SonicWALL CDP 3440i or SonicWALL CDP 4440i.
Note: For complete documentation, refer to the SonicWALL CDP Administrator’s Guide
and the SonicWALL CDP Agent Tool Guide at:
<http://www.sonicwall.com/support/documentation.html>.
*Offsite backup is offered as a subscription-based service.
Page 2
Contents
This getting started guide contains the following sections:
“Before You Begin” on page 3
• “Check Package Contents” on page 3
• “What You Need to Begin” on page 4
• “Record Configuration Information” on page 4
• “Overview of the SonicWALL CDP Appliance” on page 5
“Setting Up the SonicWALL CDP Appliance” on page 7
• “Registering Your SonicWALL CDP Appliance” on page 7
• “Configuring Time Zone and Network Settings” on page 10
• “Connecting The SonicWALL CDP Appliance to Your Network” on page 15
• “SonicWALL CDP Software Interfaces” on page 15
• “Downloading and Installing the SonicWALL CDP Software” on page 16
• “Activating Your SonicWALL CDP Appliance” on page 20
“Preparing the SonicWALL CDP Appliance for First Use” on page 24
• “SonicWALL Enterprise Manager Status Overview” on page 24
• “Changing Password and Administrator Settings” on page 26
• “Verifying SonicWALL CDP Operation” on page 26
1
2
3
SonicWALL CDP 3440i/4440i Getting Started Guide Page 3
Before You Begin
Check Package Contents
One SonicWALL CDP appliance
One Getting Started Guide document
One power cord*
One crossover cable (red)
One Ethernet cable (gray)
* The included power cord is intended for use in North America only. For European
Union (EU) customers, a power cord is not included.
* Das eingeschlossene Netzkabel ist für Gebrauch in Nordamerikas nur vorgehabt.
Für Europaïsche Union (EU) Kunden, ist ein Netzkabel nicht eingeschlossen.
1
Any Items Missing?
If any items are missing from your package,
contact:
SonicWALL Support
Web: <http://www.sonicwall.com/support/>
E-mail: [email protected]
1
2
3
4
5
Page 4
What You Need to Begin
• A computer that meets or exceeds the following requirements:
• Pentium III 450 MHZ processor
• 256 MB of RAM
• 40 MB of free disk space
• Windows XP, 2000, 2000 Server or 2003 Server
• A broadband Internet connection (DSL, cable, T1 or other)
• A 10/100 Base-T Ethernet hub / router
Record Configuration Information
Before continuing, record the following configuration information for your reference:
Networking Information
General Information
CDP IP Address: Select a free static IP address for your
SonicWALL CDP appliance that is within the
range of your local subnet.
CDP Subnet Mask: Enter the subnet mask for the local subnet
where you are installing your SonicWALL CDP
appliance.
Gateway IPAddress: Record the IP address of your network’s
gateway device (such as your perimeter
firewall/router).
DNS Server 1:
DNSServer2(optional): Record your DNS Server information.
Server Name: Select a friendly name for your SonicWALL
CDP appliance (maximum 32 characters).
Password: Select a password for your SonicWALL CDP
appliance (default is password).
Serial Number: Record the serial number found on the back of
your SonicWALL CDP appliance.
AuthenticationCode: Record the authentication code found on the
back of your SonicWALL CDP appliance.
Registration Code: __________________ Record the registration code that is generated
in mysonicwall.com. See “Registering Your
SonicWALL CDP Appliance” on page 7.
SonicWALL CDP 3440i/4440i Getting Started Guide Page 5
Overview of the SonicWALL CDP Appliance
Feature Description
HDD LED
(Hard Disk Drive) Indicates data transfer to and from the hard disk.
Power LED Indicates the SonicWALL CDP appliance is powered on.
Reset Button Allows reboot of the SonicWALL CDP appliance.
Power Button Allows the SonicWALL CDP appliance to power on (one
press) or power off.
Cooling Fan Allows optimal air circulation.
AC Power Allows the SonicWALL CDP appliance to connect to AC
power using the supplied power cable.
LAN Port Allows the SonicWALL CDP appliance to connect to your
local area network.
SonicWALL CDP 3440i
* Pressing the reset button for several seconds will result in a reboot of
the SonicWALL CDP appliance.
** Do not plug devices into any ports (other than those indicated) unless
explicitly instructed to do so by a SonicWALL technical support
representative. Doing so may void your warranty.
Page 6
Feature Description
HDD LED
(Hard Disk Drive) Indicates data transfer to and from the hard disk.
Power LED Indicates the SonicWALL CDP appliance is powered on.
Reset Button Allows reboot of the SonicWALL CDP appliance.
Power Button Allows the SonicWALL CDP appliance to power on (one
press) or power off.
Cooling Fan Allows optimal air circulation.
AC Power Allows the SonicWALL CDP appliance to connect to AC
power using the supplied power cable.
LAN Port Allows the SonicWALL CDP appliance to connect to your
local area network.
SonicWALL CDP 4440i
* Pressing the reset button for several seconds will result in a reboot of
the SonicWALL CDP appliance.
** Do not plug devices into any ports (other than those indicated) unless
explicitly instructed to do so by a SonicWALL technical support
representative. Doing so may void your warranty.
SonicWALL CDP 3440i/4440i Getting Started Guide Page 7
Setting Up the SonicWALL CDP Appliance
This section contains the following subsections:
• “Registering Your SonicWALL CDP Appliance” on page 7
• “Configuring Time Zone and Network Settings” on page 10
• “Connecting The SonicWALL CDP Appliance to Your Network” on page 15
• “SonicWALL CDP Software Interfaces” on page 15
• “Downloading and Installing the SonicWALL CDP Software” on page 16
• “Activating Your SonicWALL CDP Appliance” on page 20
Registering Your SonicWALL CDP Appliance
The SonicWALL CDP appliance must be registered with the software license key before
first use. Perform the following steps to register your SonicWALL CDP appliance:
Note: You need a mySonicWALL.com account to register the SonicWALL CDP
appliance. If you do not have a mySonicWALL.com account, create an account at
the http://www.mysonicwall.com Web site.
1. Open a Web browser on the computer you are using to manage the
SonicWALL CDP appliance.
2. Enter http://www.mysonicwall.com in the location or address field.
3. The mySonicWALL.com login page is displayed.
4. Enter your mySonicWALL.com account username and password in the appropriate
fields and click the submit button.
5. Navigate to My Products in the left-hand navigation bar.
2
Page 8
6. Complete the fields as described in the table below:
The message Please select an offsite backup location displays.
Field Description
Serial Number Enter the serial number, found on the back of your
SonicWALL CDP appliance.
Friendly Name Enter a friendly name for your SonicWALL CDP appliance.
Authentication Code Enter your authentication code, found on the back of your
SonicWALL CDP appliance (just below the serial number).
SonicWALL CDP 3440i/4440i Getting Started Guide Page 9
7. From the Location drop-down menu, select your offsite data backup location, either
Europe or North America.
Alert: You cannot change the offsite data backup location once it is selected.
8. Click the Register button. A confirmation window is displayed.
9. Record your Registration Code from the confirmation window.
Activating Offsite Data Backup Service
1. If you purchased optional Offsite Data Backup Service and have an activation key,
scroll down to Applicable Services. If you do not have an Offsite Data Backup
Service activation key, click Buy or contact your SonicWALL vendor. Next to Offsite
Data Backup Service, click Enter Key.
