SonicWALL TZ 190

Getting Started Guide

SonicWALL TZ 190 Getting Started Guide Page 1

SonicWALL TZ 190

Getting Started Guide

This Getting Started Guide contains installation procedures and configuration guidelines

for deploying a SonicWALL TZ 190 appliance on your network.

SonicWALL TZ 190 provides a flexible, total Internet security platform for wired and

wireless users over Wireless Wide Area Networks (WWAN). This easy to configure

appliance delivers the office-on-a-park-bench mobility and convenience of WWAN

technology along with the powerful protection of true layered security, integrating

gateway anti-virus, gateway anti-spyware, intrusion prevention and content filtering

capabilities in an easy-to-use, low cost platform.

This Getting Started Guide provides instructions for basic installation and configuration of

the SonicWALLTZ 190 appliance using a SonicWALL approved WWAN PC card and

service from a third-party wireless provider. After you complete this guide, you will have

secure Internet access (WAN / WWAN) and a secure Local Area Network (LAN).

The SonicWALLTZ 190 appliance requires the use of a SonicWALL approved WWAN

PC card along with a data account from a supported third-party wireless service provider.

For an updated list of SonicWALL approved WWAN cards and service providers, visit the

SonicWALL TZ 190 product page at:

<http://www.sonicwall.com/us/tz190cards.html>

Alert: DO NOT INSERT YOUR WWAN PC CARD INTO ANY DEVICE UNTIL YOU

HAVE READ THIS GUIDE.

INSERTING YOUR WWAN PC CARD INTO A DEVICE BEFORE PROPER

SETUP AND PROVISIONING HAS TAKEN PLACE CAN RESULT IN

CONNECTIVITY ISSUES.

Note: SonicWALL makes no warrants, representations or claims that the user of this

product will experience continuous broadband-like speeds. The speed of the

WWAN connection will vary depending on available wireless technology (GPRS/

HSDPA/EV-DO), WWAN card, wireless service area and other factors.

Page 2

Important Information Regarding WWAN Service Providers

It is important to understand that not all WWAN service providers operate in the same

way, nor do they all support the same feature sets. Because of this, there exists some

inherent “service provider-specific” variances in service area and more importantly, in

supported features. Along with feature limitations may also come certain restrictions

such as bandwidth constraints and networking limitations. Before purchasing a WWAN

PC card and service plan, check to make sure that the WWAN service provider offers

support for the features you need.

Before committing to a service contract with a WWAN service provider, it may be

helpful to ask these questions:

• What types of traffic are allowed over the WWAN network?

• Do they offer “static” or “dynamic” IP addressing?

• Are there any inbound connection limitations?

• Are single or multiple hosts allowed?

• Do they support VPN traffic?

• What are the data transfer limits (inbound and outbound)?

• What are common data transfer speeds and how much of the coverage area

supports 3G or faster technology?

Document Contents

This document contains the following sections:

Completing Pre-Configuration Tasks

Preparing Your WWAN PC Card

Registering Your SonicWALL TZ 190 Appliance

Setting Up Your SonicWALL TZ 190 Appliance

Using the SonicWALL Configuration Wizard

Verifying Your WWAN Connection

Connecting the SonicWALL TZ 190 to Your Network

SonicWALL TZ 190 Getting Started Guide Page 3

Completing Pre-Configuration Tasks

This section contains the following sub-sections:

• “Before You Begin” on page 3

• “Checking Package Contents” on page 4

• “Recording Configuration Information” on page 5

• “Recording Internet Service Provider (ISP) Information” on page 6

• “Overview of the SonicWALL TZ 190 Appliance” on page 7

Before You Begin

Before you begin the setup process, check to ensure that you have the following

required components available:

• A SonicWALL approved WWAN Wireless PC Card and a service contract with a

WWAN service provider

• Your WWAN service provider’s installation software

• A laptop computer with:

• Windows XP or Windows 2000

• One available PC card slot

• 40MB of disk space available

• A Web browser supporting Java and HTTP uploads. Internet Explorer 6.0 or higher,

Netscape Navigator 4.7 or higher, Mozilla 1.7 or higher, or Firefox are recommended

Note: For an updated list of SonicWALL approved WWAN cards and service providers,

visit the SonicWALL TZ 190 product page at:

<http://www.sonicwall.com/us/tz190cards.html>

Page 4

Checking Package Contents

One SonicWALLTZ 190 appliance

One standard power adaptor*

One DB9 -> RJ45 (CLI) Cable

One Ethernet Cable

One SonicWALL Resource CD

One Getting Started Guide Document

One Release Notes Document

* The included power cord is intended for use in North America only. For European

Union (EU) customers, a power cord is not included.

* Das eingeschlossene Netzkabel ist für Gebrauch in Nordamerikas nur vorgehabt.

Für Europaïsche Union (EU) Kunden, ist ein Netzkabel nicht eingeschlossen.

Any Items Missing?

If any items are missing from your

package, please contact SonicWALL

support. A listing of the most current

support options is available online at:

<http://www.sonicwall.com/us/support.html>

SonicWALL

Release Note

COMPREHENSIVE INTERNET SECURITY

link/act

10/100

signal

link/act

wan optwwan

TZ 190

SonicWALL

Resource CD

SonicWALL

Getting Started Guide

COMPREHENSIVE INTERNET SECURITY

SonicWALL TZ 190 Getting Started Guide Page 5

Recording Configuration Information

Before continuing, record the following configuration information for your reference:

WWAN Connection Information

Registration Information

Networking Information

WWANServiceProvider:

(Cingular, Verizon, etc.) Record the name of your WWAN service

provider.

WWAN Plan Type:

(Standard, Acceleration, VPN, etc.) Record the type of plan you have with

your WWAN service provider. If you are

not sure what your plan type is, ask your

service provider.

Serial Number:

(xxxxxxxxxxxx) Record the serial number found on the

bottom panel of your SonicWALL TZ 190

appliance.

Authentication Code:

(xxxx-xxxx) Record the authentication code found on

the bottom panel of your

SonicWALLTZ 190 appliance.

TZ190LANIPAddress: Select a static IP address for your

SonicWALLTZ 190 appliance that is within

the range of your local subnet.

TZ190 Subnet Mask: Record the subnet mask for the local

subnet where you are installing your

SonicWALLTZ 190 appliance.

EthernetWANIPAddress:

(optional) Select a static IP address for your Ethernet

WAN. This setting only applies if you are

already using an ISP that assigns a static

IP (as in the case of a landline T1/E1

connection, where the WWAN is a

failover).

DNS Server 1 :

(optional)

DNS Server 2 :

(optional)

In most cases, DNS server information is

automatically provided by your WAN

service provider upon connection. Record

your DNS server information here if your

network requires it. If for example, you

make use of internal DNS servers.

Page 6

Administrator Information

Recording Internet Service Provider (ISP) Information

If you already have an Internet connection and are using the WWAN connection as a

backup or “failover”, collect the following information about your current Internet service:

Note: You do not need to complete this information if you are using the WWAN PC

Card as your only connection to the Internet.

TZ190 AdminUser: Select an administrator account name for

your SonicWALL TZ 190 appliance

(default is admin).

TZ190AdminPassword: Select an administrator password for your

SonicWALL TZ 190 appliance

(default is password).

If you connect via You probably use Please record

Cable modem,

DSL with a router DHCP No Internet connection information is usually required.

Some service providers require a host name. Check

with your ISP.

Host Name:

Home DSL PPPoE User Name:

Password:

Note: Your ISP may require your user name in the

format: name@ISP.com

T1/E1,

Static broadband,

Cable or DSL

with a static IP

Static IP IP Address:

Subnet Mask:

Default Gateway

(Router IP Address):

Primary DNS:

Secondary DNS (optional):

Dial-in to a server PPTP Server Address:

User Name:

Password:

SonicWALL TZ 190 Getting Started Guide Page 7

Overview of the SonicWALL TZ 190 Appliance

*For an updated list of SonicWALL approved WWAN cards and service providers, visit the

SonicWALL TZ 190 product page at: <http://www.sonicwall.com/us/tz190cards.html>

link/act

10/100

signal

link/act

wan optWWAN

TZ 190

PC Card Slot Power LED

Test LED

WWAN Signal/Act WAN LED

OPT LED Link/Act 1-8

10/100 1-8

SonicWALL TZ 190 Appliance Front

Feature Description

PC Card Slot Location to insert your WWAN PC Card modem. For use only with

SonicWALL approved PC cards.*

Power LED Indicates the SonicWALL TZ 190 appliance is powered on.

Test LED Solid: Indicates that the SonicWALL TZ 190 appliance is in test mode.

Blinking: The unit is first booting up, or restarting. This can also indicate

that the unit is in safe mode.

WWAN Indicates WWAN signal or link activity through your WWAN PC Card.

WAN Indicates a device link, activity and connection speed on your WAN port.

OPT Indicates a device link, activity and connection speed on your OPT port.

LAN Ports 1-8 Indicates a device link, activity and connection speed on individual LAN

ports.

Signal Indicates availability and strength of a signal (WWAN port only).

Link/ACT Solid: Indicates a device is connected to the specified port(s).

Blinking: Indicates activity on the specified port(s).

10/100 Green: Indicates 10M connection on the specified port(s).

Amber: Indicates 100M connection on the specified port(s).

Page 8

Preparing Your WWAN PC Card

This section provides instructions to set up your WWAN PC card for use in the

SonicWALL TZ 190 appliance.

This setup process differs depending on you service provider. Choose your service

provider from the list below and follow the instructions on how to set up your WWAN PC

Card. If your service provider is not listed here, you must still complete the setup and

activation for your PC Card modem using the documentation that came with it before it

can be used in the SonicWALL TZ 190 appliance.

Alert: DO NOT insert your PC Card into the SonicWALL TZ 190 appliance until

you have completed the setup process for your card as described in this

section.

Tip: If your WWAN PC Card is already registered and activated with your service

provider and you are able to access the Internet through your PC using this card,

you may skip this section and continue to “Setting Up Your SonicWALL TZ 190

Appliance” on page 23.

Choose one of the PC card setup options below:

General WWAN PC Card Setup

This section provides general instructions for setting up most WWAN PC cards:

• “WWAN PC Card Setup” on page 9

Specific PC Card Setup

The following sections provide specific instructions for setting up specific cards:

• “Sprint Wireless PC Card Setup” on page 11

• “Cingular Wireless PC Card Setup” on page 14

• “Verizon Wireless PC Card Setup” on page 17

SonicWALL TZ 190 Getting Started Guide Page 9

WWAN PC Card Setup

Complete the following steps to set up and provision your WWAN PC Card Modem.

Before continuing, check to make sure that your WWAN PC card and service provider

are supported by the SonicWALL TZ 190 appliance by visiting the SonicWALL TZ 190

product page at: <http://www.sonicwall.com/us/tz190cards.html>

Contact your PC card vendor for troubleshooting help with this section.

Alert: DO NOT insert your PC Card modem into the computer until you have

completed the setup process for your card as described in this section and

successfully accessed the Internet through your PC using the PC Card

modem.

Installing PC Card Software

The following steps are general prerequisites necessary to set up most WWAN PC card

modems to work with the TZ 190.

1. Install the software that came bundled with your WWAN PC card modem before

activating the card.

2. When prompted, insert the WWAN PC card modem into an available Type II PC card

slot on the Windows PC you are using for card configuration.

3. Check for updates and install updates to your WWAN PC card (if available).

4. Activate your PC Card modem (if required).

Verifying Your Connection

After the card has been set up on your PC, you can view your connection type and verify

that the WWAN PC Card is transferring data.

Note: In order for the connection testing to be valid, it is important that you first disable

all other network connections, such as a Wi-Fi or LAN connection, before

continuing. Leave only your PC card connection enabled.

5. Use the software that came with your WWAN PC card modem to initialize a

connection with your service provider.

6. In the Windows interface, select Start > Run.

7. Enter “cmd” in the Open field and click the OK button.

8. At the prompt, type the command “ipconfig” and press Enter on the keyboard.

9. Your network device status will display. Verify that you have obtained an IP Address

for your Ethernet adaptor, and that all other Local Area Network Connections display

“Media disconnected” as their status.

Autres manuels pour TZ 190

Table des matières

Autres manuels SonicWALL Pare-feu

SonicWALL

SonicWALL TZ 170 Manuel utilisateur

SonicWALL

SonicWALL NSA 2600 Manuel utilisateur

SonicWALL

SonicWALL PRO 2040 Manuel utilisateur

SonicWALL

SonicWALL NSA 2600 Manuel d'installation et d'exploitation

SonicWALL

SonicWALL SuperMassive 9800 Manuel utilisateur

SonicWALL

SonicWALL NSA E7500 Manuel utilisateur

SonicWALL

SonicWALL TZ 180 Manuel utilisateur

SonicWALL

SonicWALL NSA 2400 Manuel utilisateur

SonicWALL

SonicWALL Email Security 6000 Manuel utilisateur

SonicWALL

SonicWALL TZ 180 Manuel utilisateur

SonicWALL

SonicWALL Email Security 800 Manuel utilisateur

SonicWALL

SonicWALL TZ 170 SP Manuel utilisateur

SonicWALL

SonicWALL TZ500 Manuel utilisateur

SonicWALL

SonicWALL 2100 CF Manuel utilisateur

SonicWALL

SonicWALL PRO 200 Manuel utilisateur

SonicWALL

SonicWALL ESA 5000 Manuel utilisateur

SonicWALL

SonicWALL TZ570 Manuel utilisateur

SonicWALL

SonicWALL TZ 200 Series Manuel utilisateur

SonicWALL

SonicWALL TZ 170 Manuel utilisateur

SonicWALL

SonicWALL ESA 4300 Manuel utilisateur

SonicWALL

SonicWALL SSL-IA Instructions d'installation

SonicWALL

SonicWALL SonicOS Enhanced 2.2 Manuel de service

SonicWALL

SonicWALL NSa 6700 Manuel utilisateur

SonicWALL

SonicWALL SMA 210 Guide de référence rapide

Manuels Pare-feu populaires d'autres marques

Cisco

Cisco S190 Manuel utilisateur

Fortinet

Fortinet FortiGate Voice Series Manuel utilisateur

ADTRAN

ADTRAN NetVanta 2300 Manuel utilisateur

SecureLogix

SecureLogix ETM System Manuel utilisateur

NETGEAR

NETGEAR ProSafe FVX538 Manuel utilisateur

Lanner

Lanner FW-8877 Manuel utilisateur

Huawei

Huawei USG6000 Series Manuel d'installation et d'exploitation

H3C

H3C SecPath F5000-AI-15 Manuel utilisateur

Nexcom

Nexcom DNA 1150 Manuel utilisateur

Fortinet

Fortinet FortiGate-60 series Manuel utilisateur

Cisco

Cisco 3110 Manuel

Draytek

Draytek Vigor2860 Series Manuel utilisateur

Lanner electronics

Lanner electronics FW-7650 Series Manuel utilisateur

Swisscom

Swisscom Internet Backup Manuel utilisateur

DPtech

DPtech FW1000 SERIES Manuel utilisateur

FEITIAN

FEITIAN MultiPass FIDO Manuel utilisateur

EBLOCKER

EBLOCKER PRO Manuel utilisateur

GTA

GTA GB-200 Manuel utilisateur
