Installation Guide
MS-W02
Wall Mount
Revision: 1.0 - April 2022
02
support@m4sol.com |www.m4sol.com
MS-W02 USER GUIDE
What’s Included
Not Included
Pieces Item
1 Wall Mount
1Cross recessed, pan head with tail machine teeth
screw, UNC 1/4’’-20*8
5Cross recessed, pan head with dielectric flat tail
machiend screws, PWM3*6
Pieces Item
4 *M5 Expansion screws
* These screws need to be provided by the installer based on the thickness of the ceiling.
Caution: It is the responsibility of the installer to ensure the camera and its mounting hardware are firmly
secured, so that the camera does not fall. Anchoring hardware appropriate to the wall type must be selected
and provided by the installer.
MS-W02 USER GUIDE
03
support@m4sol.com |www.m4sol.com
Installation
Step 1.
a) Position on wall and mark wall for anchor placement.
b) Pre-drill holes in wall.
c) Secure mount to wall using M5 expansion screws (not included).
NOTE: Check depth of the mounting holes by inserting a straw or toothpick, and measure against the length
of screws.
Step 2.
a) Attach camera to mount.
b) Secure using PMW3*6 screws.
www.m4sol.com
