SOL paragliders FUN Manuel utilisateur

Manual

Ground Handling

version 2 05/2019

Fun

2 3

Sumario

WELCOME TO THE SOL TEAM .................................................................... 4

Symbols.......................................................................................... 4

IMPORTANT NOTES..................................................................................... 5

FUN - THE PROJECT ..................................................................................... 6

Recommendaon .......................................................................... 6

Cercaon ................................................................................... 6

Special characteriscs.................................................................... 6

Accessories .................................................................................... 6

Technology..................................................................................... 8

Overview Fun............................................................................... 10

Overview risers ............................................................................ 11

Line plan ...................................................................................... 12

PACKING .................................................................................................... 14

Storing.......................................................................................... 16

TIPS FOR CARE........................................................................................... 18

INSPECTION............................................................................................... 19

REPAIRS...................................................................................................... 19

WARRANTY ................................................................................................ 20

ENVIRONMENT AND RECYCLING............................................................. 21

TECHNICAL DATA....................................................................................... 22

Weight, measure and data........................................................... 22

Parts and materials ...................................................................... 24

Lines............................................................................................. 24

Line lengths.................................................................................. 26

Line lengths individually .............................................................. 28

Fun

4 5

You have just acquired a high-quality product, manufactured under one of the most

demanding industry standards worldwide. We are certain that this equipment will

allow you to learn, increase and amplify your knowledge and technique for your

ights.

We hope your FUN will provide you with many happy moments and that you’re

experiencing moments that will last forever in your memory. This way our philosophy

will proof right: security, performance, easy handling and innovation.

Please, read this manual carefully. All necessary information you’ll need for your new

equipment is right here.

In case of questions or doubts regarding your paraglider or in case you simply are

interested in our new products - we are at your dispose.

Thank you very much for choosing SOL PARAGLIDERS.

Warnings and important notes - pay attention and read carefully

Notes regarding environment protection

Additional information

WELCOME TO THE SOL TEAM IMPORTANT NOTES

- This is an equipment for your training on the ground. It wasn’t made for ight. You

alone are responsible for all risks that come with his use. The inappropriate and/or

abusive use of your equipment increases this risk.

- It’s not possible to transfer this responsibility of risks, using this equipment, to the

producer, distributor or seller.

- A regular training, whenever possible, especially on the ground, is indispensable

and necessary. A poor handling and control of the glider, especially on the ground,

is one of the most frequent causes of accidents.

- It is in your responsibility as a pilot to know what your insurance covers.

- We recommend that every new or reviewed paraglider will be inated and veried

on the ground.

- Always use your safety equipment (helmet, hand-gloves and boots).

- Check all your equipment before each training. Never use inappropriate or damaged

equipment.

- All pilots has to follow the rules of the sport required in each country.

- Before each training check your physical and mental state. Are you t for training?

- Before training choose the right equipment and environment, check the weather

conditions, if you have any doubt - don’t train.

- Never inate your FUN during rain, snow, strong wind, turbulent conditions or if

thunderstorm clouds are in the sky.

- If you are always training with conscious - you’ll be able to train for many years

your FUN.

Symbols

Fun

6 7

Ground-handling is one of the most important aspects of paragliding progression.

With the FUN, pilots can progress and learn the most basic or most advanced aspects

of groundhandling even in strong winds safely and easily.

The FUN is an equipment for your training on the ground. It wasn’t made for ight.

You alone are responsible for all risks that come with his use. The inappropriate and/

or abusive use of your equipment increases this risk.

Don’t take any risk! Never y this equipment! Always be accompanied during training

by your instructor.

Read this manual before using your equipment.

Compact - Resistant - Easy control

Along with your FUN you receive:

The FUN is not certied, because he isn’t a paraglider for ight, but only an equipment

for training on the ground.

The FUN is destined to all pupils or pilots who are seeking to improve their domain

over the paraglider. We recommend the use of safety equipment during the training.

- Bag Fun.

- Packing strap.

- Protection sack for the risers.

- Manual.

- Windsock M.

- Little bonus surprise.

FUN - THE PROJECT

Special characteristics

Certication

Recommendation

Accessories

Fun

8 9

The 3 Riser System guarantees stability, 25%

less lines, better weight distribution and less

deformation throughout the years.

Technology

Fabrics composed out of dierent materials

assure long life and more resistance with less

deformation and weight.

Cutting edge technology laser equipments

prepare all molds and parts of the canopy.

Fun

10 11

1. Trailing edge

2. Top

3. Leading edge

4. Bottom

5. Stabilo

6. Lines

7. Risers

Overview Fun

1. Riser A.

2. Riser B.

3. Riser C.

4. Brake lines.

5. Toggle connection.

6. Taggle.

7. Connection to harness.

Overview risers

123

Fun

12 13

The suspension point design was developed for an ideal weight distribution and long

life. During all consideration and calculation, security always is our rst goal.. The

used material mix for the lines of the FUN forms an ideal combination: long life with

little deformation and aerodynamic drag.

Line plan

10A

11A

12A

13A14A

4B 5B 6B 7B 8B 9B 10B 11B 12B 13B 14B

12C 3C

4C5

C6C7C8C9C10C

11C12C13C14C

17D

8D9D

10D

11D

12D13D14D

BR1 BR2

BR3

RISER B

BM1

2BM

3BM 4BM

5BM 6BM

AM1

2AM

3AM

4AM

5AM

6AM

AR1

AR2

AR3

CM1

2CM

3CM

4CM

5CM

6CM

CR1

CR2

CR3

3F 4F 5F 6F

F8F 9F

FM1 FM1

FM2 FM2

FUN

RISER A

RISER CBRAKEHANDLE

Never and under no circumstances the line length can be altered!

Fun

14 15

PACKING

Step 1: Bundle up your FUN in form of a

cabbage. This way you’re avoiding that

the FUN drags over the ground during

folding.

Step 2: Begin with the center of the

trailing edge. Put one prole over the

other. Each side separate.

Step 3: Now do it in the same way

with the leading edge proles. Put the

reinforcements of top and bottom in the

right way, don’t close the cell openings

and push out the fabric.

Step 4: Fold the wing like an accordion from both sides and put one side over the

other. Now all reinforcements are laying side-wise one above the other.

Step 5: Fold the sack as shown in the

photo. This method is very gentle to the

more stier parts of the FUN.

Fun

16 17

Step 6: At last put the FUN into the protection bag.

Storing

Most part of the FUN fabric is Nylon. As all other synthetic materials it suers and

deteriorates under the inuence of ultraviolet radiation (UV). It looses his stiness

and gets more porous. Whenever it is possible avoid to submit your FUN to the sun

light, it has a high UV rate, especially in heights. It is recommended to store your FUN

very well whilst it not in use. It should be stored dry in a dry place, protected from UV

rays, distant from chemical products. Avoid to store the FUN in hot places like the

trunk of a car.

Fun

18 19

TIPS FOR CARE

- Over-stressing of individual lines, more than normal load in training, should be

avoided. An excessive deformation is irreversible and can’t be undone. For the same

reason avoid stepping on the lines, bending or folding them, especially the main

lines.

- Always open the FUN on clean ground, otherwise dirt could penetrate the fabric,

shorten the lines or damage the canopy. Lines should not be entangled to objects

during the phase of ination, otherwise they could be deformed or damaged. Never

step on the canopy, especially not on hard ground.

- Training with strong wind conditions could force the FUN to crash uncontrolled with

high velocity on the ground, the crash could damage fabric and sewings.

- In case of a Line Over the brake lines could wear of or a main line could be cut by

a brake line or crack by friction.

- Handling the FUN on a earthy ground under strong wind conditions accelerates the

aging process of your equipment.

- After a water or tree landing the FUN must be sent for inspection to an authorized

dealer’s workshop.

- It must be avoided that sand, stones or snow enter in the cells, otherwise the weight

on the trailing edge could brake the glider and cause a full-stall. Besides, the sharped

edges could damage the sail’s fabric.

- Training be careful, avoid crashing the leading edge on the ground. Otherwise the

material and sewings of the cell openings could be damaged.

- In case the FUN gets in contact with salty water, he must be washed with sweet

water and dry in the shadow. Never use tools to accelerate the drying process. Salty

water could reduce the line resistance and increase the porosity of the fabric, even

washed out with sweet water.

- After any kind of accident: the equipment must be sent for inspection to an

authorized dealer’s workshop or to the manufacturer.

- Keep up to the required inspection data, to assure that your equipment is always

save for use.

REPAIRS

INSPECTION

Repairs must only be made by an authorized dealer’s workshop or to the

manufacturer.

This equipment wasn’t made for ight, nevertheless, keep him well maintained is

very important for a correct functionality. We recommend an annual revision.

Table des matières

Autres manuels SOL paragliders Aéronef

SOL paragliders

SOL paragliders Prymus 2 Manuel

SOL paragliders

SOL paragliders Flexus LOTUSOne Manuel utilisateur

SOL paragliders

SOL paragliders SPEEDUP Manuel utilisateur

SOL paragliders

SOL paragliders SQUAD LIGHT Manuel utilisateur

SOL paragliders

SOL paragliders Spring 2 Manuel utilisateur

SOL paragliders

SOL paragliders HARPIA Manuel utilisateur

SOL paragliders

SOL paragliders ELLUS Series Manuel

SOL paragliders

SOL paragliders Hercules 2 240 Manuel utilisateur

SOL paragliders

SOL paragliders Sonic 15 Manuel

SOL paragliders

SOL paragliders Ellus 5 Manuel utilisateur

SOL paragliders

SOL paragliders Kangaroo 3 Manuel

SOL paragliders

SOL paragliders Flexus 2 Manuel utilisateur

SOL paragliders

SOL paragliders Runner XC Series Manuel utilisateur

SOL paragliders

SOL paragliders Prymus 5 Manuel utilisateur

SOL paragliders

SOL paragliders Hercules 380 Manuel utilisateur

SOL paragliders

SOL paragliders ATMUS 2 Manuel utilisateur

SOL paragliders

SOL paragliders TR27 Manuel utilisateur

SOL paragliders

SOL paragliders LT 1 Manuel utilisateur

SOL paragliders

SOL paragliders ELLUS 2 Manuel

SOL paragliders

SOL paragliders KANGAROO 2 Manuel

SOL paragliders

SOL paragliders Attak Manuel utilisateur

Manuels Aéronef populaires d'autres marques

Cessna

Cessna U206G STATIONAIR Manuel du propriétaire

Cirrus

Cirrus SR22 Manuel utilisateur

Schleicher

Schleicher ASK 21 Instructions d'installation

Aircraft

Aircraft REIMS F152 Caractéristiques techniques

Skywalk

Skywalk Tequila 2 Manuel utilisateur

MAULE

MAULE M-7-235B Caractéristiques techniques

Ozone

Ozone Indy Manuel

Tecnam

Tecnam P92 Echo Super Manuel utilisateur

Wills Wing

Wills Wing HP II Mode d’emploi

Ozone

Ozone Roadster Manuel

Cirrus

Cirrus SR20 Manuel utilisateur

Niviuk

Niviuk KOYOT 3 Manuel utilisateur

Pipistrel

Pipistrel ALPHA Trainer Manuel utilisateur

REVELL

REVELL SnapTite BLUE ANGELS F-18 HORNET Manuel utilisateur

Cessna

Cessna 172 Series 1973 Manuel utilisateur

Sky

Sky EOLE Manuel utilisateur

Sabfoil

Sabfoil Surf Foil Manuel utilisateur

Cessna

Cessna 182S Skylane Guide de configuration rapide
